M-200 Series: Inclined Belt Conveyors, Painted Steel M-300 Series: Horizontal Belt Conveyors, Painted Steel
M200/M300 Series Conveyors
Standard features include color to your specification, 12 gauge steel frames, fixed 4" high steel slide rails, 3" diameter pulleys with welded 1" shafts, USDA/FDA approved belts, 1" bore heavy duty flange bearings, 4" wide adjustable legs with floor mount pads, AC motor gearbox, 1/8HP and up, single or three-phase, NEMA 1 control with plug and overload protection, and fixed speed.
|
|
4 types:
• Mesh belt conveyors standard L (1)
• Mesh belt conveyor standard U (2)
• Mesh belt conveyor standard U with breaks (3)
• Mesh belt conveyor standard U curves (4)
This range of conveyors answers, thanks to a vast choice of modular bands, to all the needs for transport of parts, for draining, drying and cooling functions. The positive drive, by toothed wheels, guarantees a precise positioning, as well as a sure passage on the level of the breaks and curves. (Maintenance and cleaning fulfill the requirements of the food mediums).
Possibility of replacing links insulated without disassembling of the conveyor, of changing partially or completely the band without dismounting the conveyor, to regulate the “tension” (play) of the band, to reverse the walk’s direction (consult us).
|
|
|
|
|
|
Flexible Conveying
The unique AmbaVeyor represents an economical and low cost solution for conveying products from A to B with a minimum of transfers.
The AmbaVeyor is a modular conveyor that can be installed either on a turnkey basis or in modules for on-site assembly. The conveyor integrates curves, inclines and straight segments between its drive and tail unit. Configurations with one continuous belt can achieve a length of over 50 metres using a single drive. The belt comes in a width range of 200-600 mm.
Endless flexibility at unbeatable prices
With its combination of durability and limitless versatility, the Ambaveyor represents real value for money. Where complicated manoeuvres are involved, traditional systems can be up to four times more expensive for comparable functionality. The favorable AmbaVeyor modules prices prove unbeatable overall track prices.
24 hours stock supply
AmbaVeyor modules are stocked at several distribution centres around the world. This ensures short delivery times and ready availability. If you order stocked parts before noon, they will be on their way the same day.
Unique modular conveyor system
The AmbaVeyor frame modules can be assembled into a complete conveyor in no time at all. Once the slide strips and belt have been snapped into place and the slat belt has been pulled in, the conveyor is ready to run. Modules are available in kit form or, if preferred, they can be supplied in standard lengths that can easily be cut to size on site. Bring sufficient parts on site and install as simply as you would do the wiring.
|
|
Logistex MB200 Modular Belt Conveyor
Simple transportation with minimal maintenance and quick
installation
Features:
Robust construction ensures longer life and heavy load handling ability
Simple cam adjustment of snub roller and easy-to-remove pulleys
Standard gear/motor options to meet global requirements
Benefits:
Provides easy and accurate belt tracking
Direct drives reduce parts requirements
Increased energy efficiency
Design minimizes mainlenance lime
|
|
mk conveyor technology
A comprehensive, standardised range of belt conveyors, chain and table top chain conveyors as well as roller conveyors.
The configurability of the modules enables them to be adapted to customers' specific requirements and integrated in complex systems. At the same time, the basic principle of optimum standardisation ensures process security, fast availability and reasonable prices.
Module belt conveyor:
- Conveyor lengths: 400 to 10000 mm
- Conveyor widths: 210 to 1010 mm
- Conveyor load max.: 150 kg
|
|
Stainless Steel is often specified when sanitation requirements are a primary concern. The hard, flat and smooth surface of the belt is easy to clean with steam or chlorinated water. Corrosive cleaning solutions will not harm the belt material. In food applications, the belts provide a stable material that will not absorb natural odors or effect the tastes of materials being transported.
|
|
|
Metal belts feature a high strength-to-weight ratio , which is an advantage in nearly every application where high strength, light weight, or both are required. Low mass offers high acceleration and rapid deceleration, with minimal motor sizes.
|
|
mk conveyor technology
A comprehensive, standardised range of belt conveyors, chain and table top chain conveyors as well as roller conveyors.
The configurability of the modules enables them to be adapted to customers' specific requirements and integrated in complex systems. At the same time, the basic principle of optimum standardisation ensures process security, fast availability and reasonable prices.
Drive belt conveyor:
- Conveyor lengths: 500 to 6000 mm
- Conveyor widths: 200 to 1000 mm
- Conveyor load max.: 100 kg
|
|
mk INOX high-grade steel-promote
mk INOX high-grade steel promoters are adapted to the special requirements of far mA and foodstuffs industry to sterile working environments.
|
|
MSE
FLAT INCLINABLE BELTS
Characterised by the minimum floor space, they are suitable for small injection moulding machines. Light and sturdy construction (anodised aluminium profiles with a steel frame). Belt has an automatic tension adjustment device, while traction is made by extruded aluminium wheels.
|
|
The Model PCH parts conveyor with hinged steel belt is ideal for carrying hot, oily parts from punch presses, forging machines, etc., to drums, hoppers, or other operations. Configurations range from straight to Z type units.
- Bed - 8-5/8" deep x 10 ga. powder painted formed steel channel.
- Belt - 12 ga. metal piano hinge
- Belt Speed - 30 FPM
- Overhead Drive
- Overall Widths: 10-3/8", 12-3/8, 16-3/8", 22-3/8", & 28-3/8"
- Motor - 1 HP standard, 2 HP max.
- Adjustable Floor Supports Available
- Capacity - 35 lbs. per linear foot
|
|
|
|
|
|
The angled belt conveyor GAL-25-K-W has a frame with only 25 mm height. It can therefore be used even in very confined spaces.
The very rigid TorsioDur frame gives a high resistance against torsion which results in high reliability in spite of very small dimensions.
Equipped with a corrugated edge belt it can handle even the smallest parts without any danger of jamming or damaging them.
The angle of inclination can be infinitely adjusted between 40 and 60° from the ground.
The frame has grooves for sliding blocks with M-6 threads on both sides, where additional accessories can be fixed . An overview of accessories available in our standard programme can be found on page 45 and onwards.
The length of the horizontal and the rising section of the conveyor can be adapted to the specific needs of each application. The total length however should not exceed 3 metres.
Hoppers and side rails can be added to the GAL-25-K-W when needed. They will ensure a safe transport of the goods.
In standard configuration the horizontal section has small casters, so the conveyor can easily be moved. A double support is fixed to the rising section, as shown in the picture above. An H-shaped support on wheels with security brakes, as shown on page 11, can also be used.
|
|
MT
FLAT INCLINED BELTS
Composed by an horizontal and an inclined section, they are the most complete and flexible solution, thanks to the regulation of the height and of the slope without tools. Light and sturdy construction (anodised aluminium profiles with a steel frame). Belt has an automatic tension adjustment device, while traction is made by extruded aluminium wheels.
|
|
For many years now, we have
been developing innovative and
successful solutions for our
partners in the assembly and
automation technology sector.
Uncompromising support, sound knowledge, unsurpassable
quality and a self-confident approach in addressing challenges
are the key to our success.
Assisted by a well-tried network of specialists, we offer
holistic solutions from one source.
This makes us both flexible and cost-efficient.
Conveyor with directly flanged motor
|
|
|
|
|
|
Automotion manufactures two types of belt conveyor: roller bed and slider bed. The slider bed is a typical full-pan construction while the roller bed uses a a hidden roller configuration to prevent product from getting caught between rollers.
Belt conveyor is available in a wide variety of pre-configured figures including: entry, intermediate, and exit conveyor beds, drive and belt take- up beds, and power feeder and nose over beds.
- Available in a slider or roller bed design. Slider bed is a typical full-pan construction. Roller bed uses a hidden roller configuration to prevent product from getting caught between rollers.
- All terminal ends, drives, supports, guard rail, and belting are interchangeable between (SB) slider bed and (RB) roller belt models.
- Widths of 18", 24", 30" and 36" are standard; 42" and 48" widths are options. Live load capacity of 130 lbs. / ft.
- Automatic belt take-up is standard.
- List of pre-engineered figures include: entry, intermediate, and exit beds, drive and belt take-up beds, and power feeder and nose-over beds.
|
|
BELT CONVEYOR
Technical Characteristics
- Bed in painted steel or stainless steel, 2mm thick
- Cylindroconical drum mounted on bearing
- Different drives possible
- By gear motor with drive
- By sprocket and chain
- By gear motor mounted or in direct drive
- By motor drum
- Diverse adaptable belts
- Automatic tension regulator optional
- These conveyors are also used to create specific functions such as: inclines/declines, conveyor retracts, etc.
Fonction
The belt conveyors enable the transport of unit or packed products on straight, curved or elevated paths.
|
|
Features:
Fixed
motorization : 230 V - 50/60 Hz HP 0,12
Ribbon : PVC
On demand:
-speed variator.
-ribbon for food.
|
|
Bag Handling Conveyors:
Perfect For Your Bag Packaging and Handling Needs
From our 35 years experience, Westfalia has learned that general purpose conveyors do not provide the service and reliability required in the harsh environment of industrial bagged products industries. Our conveyors are durable, reliable, and customizable as your application requires. These conveyors can drive increased revenue for your business.
|
|
|
The belt conveyor is characterised by careful and extremely low-noise conveying. It can be used with either a head drive or a central drive depending on its length. The belt conveyor can deal with slopes and Inclines of up to 18 ° and of course, it conveys even the smallest transported goods.
|
|
|
The success of the B-Flex B SERIES conveyor belts (B032-B045-B090) stems for the great experience acquired by Bett Sistemi in the field of conveyor belt construction systems. Available in 3 versions (overhead, intermediate or transmission motor), the B-Flex B Series belts feature high quality, original Bett Sistemi components, a full range of accessories and an excellent quality/price ratio.
|
|
DCM-H1-C-S-S/G-F - Modular Conveyor, Heavy Duty W/ Center Drive, Single Belt, Full Dia Rollers
The Heavy duty Series conveyor provides a wide range of speeds and widths suitable for most heavy duty applications. The center drive is compactly located below the conveying surface. Full diameter rollers allow for cleated belting designs.
DCM-L1-C-D-A - Modular Conveyor, Light Duty W/ Center Drive & Dual Belts
The Light Duty conveyor series handles small to medium sized parts with a compact variable speed drive. The center drive can be placed anywhere along the conveyor's length. The double belt provides the ability to process parts from below by cutting access holes in the chassis.
DCM-M1-C-D-A - Modular Conveyor, Medium Duty W/ Center Drive & Double Belt
Medium Duty Conveyors cover a wide array of part sizes and weights. In addition they can be used for conveyor systems. The double belt provides the ability to process parts from below by cutting access holes in the chassis.
|
|
Flat conveyor belt with a 25mm high frame made of anodised, fluted rigid, torsion-free, extruded aluminium profiles.
The grooves running along the full length of the profiles are designed for M 6 sliding blocks and are used to attach the various accessories belonging to the modular system.
This conveyor belt is also available as a magnetic conveyor belt up to belt widths of 200mm. In this case, however, the drive and deflector rollers are not magnetic.
For this type of conveyor belt, there are two different systems of uprights. For belt width over 150mm, extruded aluminium double uprights, adjustable in height, and for width under 150mm, pivoting single column uprights, adjustable in height.
For belt lengths up 1000mm, one single column upright is needed, for longer belts more uprights have to be used.
Both systems of uprights are equipped with vertical locking.
More at www.geppert-band.com
|
|
The MayTec conveyor system provides optimal adaptation to the required task. Belt material, drive type and profile design can be combined in any number of combinations to best suit the application.
Simple handling, reliable technology and solid construction guarantees the problem free operation and long life of the system. Along with the huge range of standard sizes and designs, special sizes and custom designs are available on request.
For self assembly, individual components and assemblies can be delivered along with parts lists and assembly instructions as required.
MayTec offers a conveyor system for rapid implementation with short delivery times.
|
|
|
Sandvik has a highly skilled projects division specializing in the design, manufacture, installation and commissioning of complete conveyor systems for use in mining, power generation, port systems, grain handling and the full range of conveyor applications. In addition to designing new systems from scratch, we undertake upgrading projects to expand or optimize and modernize existing conveyor systems. Examples of turnkey installations delivered by Sandvik are given below.
|
|
|
|
|
|
2200 Series Low Profile Belt Conveyors
• High performance conveying
• Streamlined machine interface
• Small parts transfers
• Efficient use of space
• Aesthetics
• Low maintenance
MPB Series Modular Plastic Belt Conveyors
• Accumulation
• High Temperatures
• Sharp parts
• Low maintenance
3200 Series Heavy Duty Belt Conveyors
• High performance conveying
• Long lengths
• Heavy duty
• Fast belt speeds
• Aesthetics
• Low maintenance
LPZ Series Angular Belt Conveyors
• Inclined and elevating
• High performance conveying
• Long lengths
• Heavy duty
• Fast belt speeds
• Low maintenance
4100 Series Low Profile Belt Conveyors
• Tight space
• Rugged Environment
• Low maintenance
6200 Series Low Profile Belt Conveyors
• Tight space
• Rugged Environment
• Low maintenance
7200 & 7300 Series Low Profile Stainless Steel Conveyors
• Wash-down & sanitary environments
• Clean rooms
• Chemical Resistance
• Low maintenance
7400 Series Curve & Straight Plastic Belt Conveyors
• Curves & Straights
• Opens in Seconds for easy cleaning
• No Tools Required
• Welded construction
|
|
Technical Facts
Transport Height: 950 mm +/- 25 mm
Dimensions: 500-2,500 x 900 x 1,300 mm
Handling Time: Approx. 2.5-5 seconds/500 mm
Transport rate: 12 m/min
Pneumatic Connection: Provided by an intelligent line component
Width adjustment: 50-400 mm
Sequence Control System: Provided by an intelligent line component
Electrical Connections: Provided by an intelligent line component
|
|
|
|
|
|
Processing and packaging often require belt conveyors to elevate, decline, or transport product. As part of Key's integrated solutions, we offer belt conveyors specifically designed for your industry, specializing in food and pharmaceutical industrial applications.
Sanitary and robust, Key's belt conveyors are available in many widths, lengths, designs, and materials. They complement Key's Smart Shaker® solutions and industry leading automated inspection products.
Modular belt conveyors are manufactured in a wide variety of configurations that share common components and construction and may use one of several belt types including Intralox® and KVP®.
Features and Benefits:
- Sanitary design-easy cleaning
- Most constructed with T304 stainless steel components
- Drive components to the side of product flow
- USDA approved belts, cleated and non-cleated
· Fabric
· Plastic (polypropylene or polyethylene)
- Standard-profile designs for proper application fulfillment
- Modular designs with pre-manufactured standard components
- Handles steeper incline/decline angles than flat-pan conveyors
- Easy to Install
· Floor mounted
· Suspended
· Mounted on casters
· Complement other Key material handling and optical inspection components
Common Product Applications:
- Bulk products
- Cereal
- Fresh cut meat and poultry
- Nuts
- Pet food
- Potato products
- Processed fruit and vegetables
- Snacks
|
|
|
|
|
|
Flat conveyor belt GES - 25: hygienic solution for confined spaces
Flat conveyor belt GES - 25 - MK with knife edge
Flat conveyor beltGES - 50: For horizontal transport with completely closed frame for highest hygienical demands
Flat conveyor belt GES - 80: For horizontal transport of higher loads in food an pharmaceutical industry, with a robust construction made from perforated profiles
Inclined Conveyor Belt GKES - 80: 80 mm high frame in stainless steel
for food processing or in pharmaceutical and chemical industry.
Flexible conveyor belt GES - 50 KW: First horizontal, then rising with white belt with corrugated edges and FDA approval
Flexible conveyor belt GES - 80 KW: First horizontal, then rising with white
belt with corrugated edges and FDA approval, for higher loads and in larger widths
Z-shaped conveyor GES - 50 ZW: 50 mm high stainless steel frame, for highest hygienic demands, with slatted belt with corrugated edges in FDA-quality.
Z-shaped conveyor GES - 80 ZW: Perforated stainless steel frame, 80 mm high, for use with higher loads or in larger sizes in food processing or pharmaceutical and chemical industry.
|
|
- Strong and thick product supports allow more load without breakage
- Various surface openings available for drainage and airflow
- Special wear resistant materials increase belt life
- High tensile strength with reinforced side flexing belts
- Easy to clean Roller Top belt for crate/box accumulation
- More load/longer conveyors with unique sprocket engagement
- F.D.A. approved materials and U.S.D.A. accepted
|
|
|
|
