Professional printing - Extrusion - Converting, Universal
Converters and Professional printers can now have the best of the Pillar Universal corona treating station. This advanced technology features a patented design of interchageable magazines to allow operation as a bare roll (conductive substrates); covered roll (non-conductive substrates); or dual dielectric (delicate substrates) sytem.
Patented Modular Interchangeable Industrial electrode
Magazine Electrodes on the Universal station can be replaced or interchanged in a matter of seconds. Industrial slide the segmented stainless steel magazine out and the ceramic tube magazine in, now you are ready to run with a dual dielectric configuration. Take out the covered roll and replace with a bare roll, now you can run conductive substrates.
This patented modular magazine approach makes cleaning and changeover effortless with minimal downtime.
Interchangeable Electrode Assemblies
Stainless Steel Segmented Electrodes
(available in 12.5mm, 6mm, 3mm sizes)
Stainless Finned Electrodes
are used in conjuction with dielectric covered ground rolls for efficiently treating difficult to treat, non-conductive materials with a fixed or stripe treat width requirement.
Ceramic Round or Square Electrodes
are designed for converters looking to treat metallized, thin or sensitive substrates.
Special Electrode Mounting of the Electrode Assemblies
The Universal magazine design enables each material to thermally expand at its own rate without causing electrode warping or changes in gap, ensuring even treatment across the web. |
|
Blown Extrusion - Cast Extrusion
Split Box
The Split Box in an economical system promoting ease of thread-up
Easy Installation
Standard mounting brackets and lifting eyes make installation quick and easy. The hight industrial voltage transformer is mounted directly to the station with all high voltage connections factory wired and tested.
Quick Start-Up
The easy-thread, "drop through" design enables operators to thread the web through the station in seconds.
Durable
- Stainless steel electrodes for reduced contamination and easy cleaning.
- In order to protect the treater rolls, a zero speed switch automatically shuts down the supplier of power supply when the web achieves low line speeds.
Versatile
With Pillar`s stainless steel segmented industrial electrode design and removable electrode styles, users can alter the treat width or lane treat according to application.
Safe
- Safety interlocks prevent operation of power supply of access covers are removed or if station is in the thread-up position.
- Electrode area is completely covered by lightweight aluminium panels. |
|
NARROB WEB STATION
for Tag&Professional label, Printing, Coating and Laminating Industries.
Pillar´s patented technology in narrow web corona treating allows professional printers to produce hight-quality print on various substrates. The unitized or non-unitized versions easily mount to most press configurations.
Increase Productivity
Combined with the industry proven P6000 power supply the narrow web corona treater maximizes power efficiency across the web resulting in consistent wettability and ink adhesion with increased productivity. Integrated industrial power supplies range from 0.5 to 3.5 kW.
(Larger sizes available upon request).
Quick Install
The user-friendly design includes an adjustable mounting arrangement which easily adapts to a wide variety of professional presses and frame widths. The front access single point gap adjustment enables users to quickly set the gap between the roll and the industrial electrode, reducing set-up time.
Easy Operation
Removable electrode magazine with hands-free high voltage connection for safe, simple cleaning and maintenance.
Faster Press Speeds
Magazine design optimizes the electrode area delivering twice as much power to the web for maximum performance...even at today´s demanding line speeds.
Affordable
Unitized design saves on the expense of installing a separate corona treating station and power supplly, incorporating your needs into one compact unit.
Available Options
- Computer interface control
- Proportional speed control
- Web cleaner and static control
- Electrode gap dial readout
- Conductive ceramic
- Dual Dielectric
- Hard coat
- Watt densitiy control
- Loss of treatment alarm/beacon
- Remote operator station |
|
Corona treater model BHSN ( BOPP-PET industry).
The field of BOPP-PET film has always been for years a key-field for ME.RO. Only an history and a very long experience can allow you to manufacture treaters able to guarantee a complete reliability as these big producing plants require. It is not by chance that nowadays ME.RO can be considered the most important mufacturer for this application. This is demonstrated by the fact that the most important producers of BOPP film around the world have joined our technology to reach important treatment results with no stops of production for years.
MAIN CHARACTERISTICS:
- Web width up to 10.500 mm.
- Specific power (energy density) kept strictly constant during running.
- Special electrode design to give the best transfer of power on the film and to maintain it clean during running.
- Special electrodes in AISI 316 stainless steel able to heat expand without modification of the pre setted air gap (easy heat expand system). |
|
The two sides unit called COROFLEX, with pneumatically operated cylinders, has been conceived to improve and increase production processes and it is suitable for extrusion. The unit is connected to professional generators with IGBT, 30 kHz work frequency, high performance modules. E.C. certification.
Technical Features:
- Available power is between 3kVa and 18kVa.
- Tables between 1000 mm and 1800 mm.
- Cylinders diameter 100 mm.
- 4 Multiple-discharge points, aluminium electrodes in function of the power density required by any line or material. |
|
The P6000 Series features IGBT (Insulated Gate Bi-Polar Transistors) technology providing the most versatile corona treater suppliers of power supply on the market today. This compact unit incorporates a circuit design that enables instant and efficient power. The P6000 automatically adjusts itself to match into any industrial electrode style or dielectric material and offers the operator better than 4 to 1 load matching.
The versatility of the P6000 Series Corona Treater Power Supply provides for a nominal turn down ratio of 20 to 1, allowing the operator to precisely turn the power up or down to achieve the desired treat level. The specially designed power measurement circuit guarantees that the power specified is the power being delivered and the feedback circuit automatically maintains constant output power regardless of minor changes in load conditions, humidity and temperature.
Benefits of the P6000 Series Power Supply
Easy to install
Accurate output power
Small, compact design
Low maintenance
Superior "load match" for a wide range of applications
Best available "turn down ratio" in the industry
Economical design, improved cost savings
User friendly "touch" control pad
Features of the P6000 Series Power Supply
Start/Stop contactor for safe, dependable operation
CE or ETL certified
Digital Light emitting diode displays Power, Voltage, Current, Frequency
Microprocessor controlled
Power supply diagnostic indicators
Loss of treatment indicator
Humidity compensation control |
|
High performances are now assured by the 30,000 Hz frequency supplied by the "IGBT" modules equpping our new generatros.
Special construction now guarantees complete protection system includes front panel LED's signaling any failure that may affect or damage the electronic elements. |
|
