Transformer without primary
Insulation: Dry, in the air
Casing: self-extinguishing
Frequency: 50 60 Hz
Insulation reference voltage : 600 Volt (2500 Vac x 1 min)
|
|
|
An extensive range of high quality current transformers offering comprehensive measuring and protection class accuracies. The range provides accurate measurement of high primary currents and ratio matching to a consistent 5 or 1 Amp secondary current, proportional to the main current. To suit the requirements of every application, the range offers moulded case, miniature, core balanced, tape wound and split core current transformers and integral transducers in a wide range of system current ratings, busbar sizes, case widths and apertures, with various mounting options.
|
|
|
The ASR, ASK and WSK current measuring transformers are used for measuring AC currents. The secondary current is 5A, rated frequency from 50 Hz to 60 Hz. The accuracy class is 1.
|
|
|
Providing both quality and experience the Setzermann division of REO INDUCTIVE COMPONENTS AG produces toroidal current-transformers from with power ratings from 10 VA up to 500 VA. These are available in either standard or custom designs, built to specification and proved in our own test laboratory. The toroidal current-transformers conform to all relevant standards whilst double-isolation and the use of UL approved encapsulation materials are always incorporated in their design. The Setzermann range of current-transformers includes many different styles from those for pcb-mounting to panel-mounting types. We offer our customers a prototyping service before commitment to a final design. Details of all products can be downloaded from our website. Setzermann current-transformers have a good reputation for high-protection and longevity.
|
|
Current transformer
M2000
Heater current monitoring:
1 Phase current transformer M2000 to operate with:
- R2400
- R2500
- R2000N
- R2000
- R2100
- R2200
For each phase only one current transformer
M2000 is necessary.
# Monitoring: Heater current (detects current reduction)
# Heater current failure (open circuit)
# Load partly missing
# Circuit partly interrupted
# SSR with short circuit
# Technical data:
VDE 0414 EN 50178 (VDE0156)
Input current 50A
Output current 50mA
Transformation ratio 1:1000
Max. measuring overload. 20%
Easy installing
# 2 x 6,3mm flat connectors
|
|
|
NK Technologies can supply current transformers, both the specialized ProteCT low voltage output design, and the industry standard five amp output designs.
|
|
Resin moulded ring core Current transformers for several applications.Please contact us for quotations.
Applications:
* Protection
|
|
We manufacture an extensive range of indoor current transformers for metering and relaying applications. All of our current transformers have a 105°C or higher insulation system and most models are UL recognized.
Applications
600V Indoor Commercial Grade Toroid
600V Indoor Commercial Grade Bar
600V Indoor Instrument Grade Toroid
600V Indoor Rectangular Window
600V Indoor Three Phase
600V Indoor Multi-Ratio Toroid
600V Indoor Split Core
600V Indoor Wound Primary/Auxiliary
5kV - 34.5kV Class Indoor
720V Indoor IEC Rated
|
|
Measurement transformers
Current sensors and voltage transformers
Current transformers, for 50/60 Hz and High Frequency.
- with nanocrystalline and amorphous cores with low linearity and phase errors, “DC tolerant” versions too
- types for high frequency with ferrite core
- built-in primary winding on some product types.
- usually supplied encapsulated in epoxy resin, wired or for PCB assembly
- toroidal and linear design
Transformers designed for voltage measurement with good linearity and galvanic insulation, up to 10KV dielectric strenght.
|
|
|
Toroid Corporation offers two low cost standard design current transformers. Both are used in applications where you want to detect or measure AC-currents with no need for tight tolerances. Typical applications include power limiting controllers for air conditioning equipment, electrical heating systems, electrical furnaces, and motor drives.
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Gaotune Techonologies is a manufactory of amorphous and nanocrystalline cores as following:
1.Current Transformer cores (Solid CT cores and Split CT cores);
2.Nanocrystalline core;
3.Amorphous c-core;
4.RCCB rectangle core;
5.Common mode choke core;
|
|
OMICRON's CT Analyzer is a unique lightweight electronic multifunctional instrument designed to meet the highest standards for performing excitation, ratio, polarity and winding resistance tests on current transformers (CTs) as well as burden-impedance measurement.
Applications
- Burden measurement
- CT Winding resistance measurement
- CT Excitation characteristic recording
- CT transient behavior measurement (IEC60044-6)
- CT ratio measurement with consideration of connected burden
- CT phase and polarity measurement
- Determination of accuracy limiting factor (ALF), instrument security factor (FS), secondary time constant (Ts), remanence factor (Kr), transient dimensioning factor (Ktd), knee point voltage/current, class, saturated and non saturated inductance
- Assessment according to defined standards: IEC60044-1, IEC60044-6, IEEE C57.13-1993
|
|
The manual desktop operating terminal OT 276 allows manual, easy control of an AC test system.
The device is primarily intended as low cost, stand-alone solution for small AC source, which do not require an embedded control.
|
|
he DCT ReporteR instrument automatically tests Current Transformers reducing testing time from hours to minutes. Results can be printed out by the 40-character-wide built-in printer, or easily transferred to a PC via RS-232 and USB ports or memory-stick.
Digital Current Transformer ReporteR Features
* Tests turns ratio, polarity and phase angle
* Measures excitation values and presents results in a table or as a graph
* Calculates saturation voltage
* Tests winding resistance
* Tests insulation resistance
* Provides option to design and save customized Test Plans
* Features a built-in current source for secondary injection testing
* Outputs up to 2,000 Vac
* Easily transfer stored data to memory stick or PC via USB port
* ReporteR Software (included) makes report preparation fast and easy
* A large, color multi-language LCD screen and a keyboard
* Extensive memory for test results
* A 40-character-wide built-in printer
* Compatible with Microsoft Excel® and Microsoft Word®
|
|
OMICRON's CT Analyzer is a unique lightweight electronic multifunctional instrument designed to meet the highest standards for performing excitation, ratio, polarity and winding resistance tests on current transformers (CTs) as well as burden-impedance measurement.
Applications
- Burden measurement
- CT Winding resistance measurement
- CT Excitation characteristic recording
- CT transient behavior measurement (IEC60044-6)
- CT ratio measurement with consideration of connected burden
- CT phase and polarity measurement
- Determination of accuracy limiting factor (ALF), instrument security factor (FS), secondary time constant (Ts), remanence factor (Kr), transient dimensioning factor (Ktd), knee point voltage/current, class, saturated and non saturated inductance
- Assessment according to defined standards: IEC60044-1, IEC60044-6, IEEE C57.13-1993
|
|
The manual desktop operating terminal OT 276 allows manual, easy control of an AC test system.
The device is primarily intended as low cost, stand-alone solution for small AC source, which do not require an embedded control.
|
|
he DCT ReporteR instrument automatically tests Current Transformers reducing testing time from hours to minutes. Results can be printed out by the 40-character-wide built-in printer, or easily transferred to a PC via RS-232 and USB ports or memory-stick.
Digital Current Transformer ReporteR Features
* Tests turns ratio, polarity and phase angle
* Measures excitation values and presents results in a table or as a graph
* Calculates saturation voltage
* Tests winding resistance
* Tests insulation resistance
* Provides option to design and save customized Test Plans
* Features a built-in current source for secondary injection testing
* Outputs up to 2,000 Vac
* Easily transfer stored data to memory stick or PC via USB port
* ReporteR Software (included) makes report preparation fast and easy
* A large, color multi-language LCD screen and a keyboard
* Extensive memory for test results
* A 40-character-wide built-in printer
* Compatible with Microsoft Excel® and Microsoft Word®
|
|
|
|
