Integrated Systems combine and interface a Cold Jet Pelletizer with one or more Cold Jet blasting systems and provide for continuous, uninterrupted, completely automated operations. Each Cold Jet Integrated System is custom engineered to meet specific customer requirements.
Features:
- Ability to run multiple nozzle stations
- Fully automated - no interruption of work to fill machine with dry ice pellets
- Works with robots or manual blasting
- Ideal for integration with a production line
- Operating pressure up to 300 psi (20.7 bar) |
|
This innovative lightweight, compact, single-hose low pressure, electric blasting system utilizes dry ice block with as little as 12 cfm and blasts at variable air pressures from 20 to 125 psi (1.4 to 8.6 bar).
Features:
- Uses as little as 12 cfm of air at blast pressures up to 125 psi (8.6 bar)
- Uses as little as 0.2 pounds of dry ice per minute which provides as much as 45 minutes of blasting before reloading
- Single-hose, patented feeder design for maximum blasting aggression
- Standard size block is 5" x 5" x 12" (12.7 cm x 12.7 cm x 30 cm), 6" x 6" x 12" (15 cm x 15 cm x 30 cm) configuration available when requested. (
- Adjustable blast pressure allows for flexibility in order to optimize performance
- Adjustable ice rate enables better performance
- Internal blast air filter (20 Micron) minimizes the effects of contaminated air
- Extruded Aluminum frame |
|
Cold Jet dry ice blasting systems provide a superior clean. Period.
We provide solutions for any budget with the widest selection of blasting machines and nozzles available anywhere in the world today. Whatever you need to clean, we can help you find the right solution for your application. |
|
COMBI 75
Complete, Automated Machine for
Dry Ice Production and Dry Ice Blasting
The IceTech COMBI 75 and its accessories have been developed with
the intention of manufacturing an automated cleaning system which
both meets the requirements especially of industrial companies for
a continuous cleaning process, and minimizes consequential costs of
machine / plant cleaning and maintenance.
The IceTech COMBI 75 combines dry ice pellet production and dry ice
blasting. Therefore high-density dry ice pellets will always be available
on site in the exact quantity required.
Several Functions in one Machine
The IceTech COMBI 75 combines several units and functions:
:: A pelletizer unit
:: A dry ice blasting unit
:: Optional distribution system to facilitate the connection of several
blasting guns
:: Optional integration in plant control units and automation processes
The IceTech COMBI 75 continuously produces dry ice pellets directly into
the pellet tank of the dry ice blasting unit.
From there the dry ice pellets are transported through a distribution
system to one or more blasting guns or robots. |
|
The IceBlast KG6S Battery is suitable for companies that have a limited number of short cleaning tasks.It is supplied complete with an ergonomic blasting gun and 5 m hose.
The machine is unique due to its size and operation principles. It is electrically driven and controlled.
The machine includes a battery which allows the KG6S to operate without power supply.
The machine is made of stainless steel and has a well-arranged, user-friendly control panel, making it simple to operate. Its compact size allows easy use in production areas.
The machine is highly effective due to the IceTech patented self-adjustment system that requires a
minimum of maintenance.
Dry ice pellets with a diameter of 3 mm are used as blasting material. |
|
Micro Jet Basic Silent
The low noise < 85 dB/6 bar
- small and compact
- easy handling
- minimal pellet and air consumption
- no damaging of sensitive parts
- increases the efficiency factor
- cleans sensitive parts with dry ice powder
Standard features:
- base and function features
- integrated Scrambler
- compressed air preparation
- automatic grounding reel
- blast gun GAP 3 S with blast nozzle RD 5
- flat nozzle S 1
- 5 m blast hose with PVC protection sleeve |
|
IceTech Products
IceTech provides a very comprehensive and versatile range of products enabling users to cover all possible dry ice blasting applications - from the simplest to the most sophisticated tasks.
In spite of the wide range of machines and accessories, the user will not find it difficult to select exactly the items needed and combine them into standardized sets and basic kits, thanks to the flexibility and rationality with which the IceTech products have been conceived, designed and manufactured.
IceTech products are:
High-quality
Reliable
Ergonomic
Easy to operate
Multifunctional
Cost and time saving |
|
E-Jet
The allrounder
- easy handling
- ideal for all type of users
- unique cleaning spectrum
- Scrambler to clean sensitive parts /optional
- simple Scrambler switch function
Standard features:
- base and function features
- blast pressure and pellet regulator
- blast gun Tornado Plus with blast nozzle RD 8
- 7 m blast hose with PVC protection sleeve |
|
IceBlast KG30S is suitable for professional users with extensive cleaning requirements.
It is supplied complete with an ergonomic blasting gun, and a 10 m hose including a protective sleeve.
The dry ice tank has a capacity of 30 kg allowing the machine to be used for 25-40 minutes before refilling.
With an operating pressure of up to 16 bar, IceBlast KG30S provides extremely effective cleaning. The machine is made of aluminium and has a well-arranged, user-friendly control panel, making it simple to use. Its compact size allows easy use in production areas. |
|
The IceBlast KG6 Battery is suitable for companies that have a limited number of short cleaning tasks.It is supplied complete with an ergonomic blasting gun and 5 m hose. The machine is unique due to its size and operation principles. It is electrically driven and controlled.
The machine includes a battery which allows the KG6 to operate without power supply.
The machine is made of stainless steel and has a well-arranged, user-friendly control panel, making it simple to operate. Its compact size allows easy use in production areas.
IceBlast KG6 Battery has adjustable pellet dosage, and various pressure can be selected depending on the coating to be removed. |
|
Each year since the introduction of dry-ice blasting, TRIVENTEK has made innovative steps towards making
this technology more affordable, yet with higher performance.... |
|
Mini Jet Basic
The universal one
- small and compact
- easy handling
- high capacity
- minimal pellet and air consumption
- Scrambler to clean sensitive parts / optional
- simple Scrambler switch function
Standard features:
- base and function features
- blast pressure and pellet regulator
- blast pressure and dry ice usage gauge
- blast time counter
- emtying function
- vibrator interval function
- compressed air preparation
- automatic grounding reel
- blast gun SX Micro Plus with power control
- compressed air injector G 6
- blast nozzle RD 290 POM SX #7
- 7 m blast hose with PVC protection sleeve |
|
| ... products without technical information |
| |
The IceBlast KG20S Battery is suitable for companies that have a limited number of short cleaning tasks.It is supplied complete with an ergonomic blasting gun and 5 m hose. The machine is unique due to its size and operation principles. It is electrically driven and controlled.
The machine includes a battery which allows the KG20S to operate without power supply.
The machine is made of stainless steel and has a well-arranged, user-friendly control panel, making it simple to operate. Its compact size allows easy use in production areas.
IceBlast KG20S Battery has adjustable pellet dosage, and various pressure can be selected depending on the coating to be removed.
The machine is highly effective due to the IceTech patented self-adjustment system that requires a minimum of maintenance.
Dry ice pellets with a diameter of 3 mm are used as blasting material. |
|
|
|
