One exemple:
JUMO ecoLine / JUMO BlackLine pH and redox combination electrodes versions with glass or plastic shaft (20.1005)
Electrodes in the JUMO ecoLine und JUMO BlackLine series are high-quality measuring sensors with an optimum price/performance ratio.
Active pH element: JUMO ecoLine electrodes have been manufactured using the JUMO U glass that has proved itself for many years. JUMO BlackLine electrodes are equipped with the lowresistance JUMO UW glass. This guarantees fast and safe measurement results.
Active redox element: A robust platinum tip ensures reliable measurements and allows simple cleaning of the sensor.
Reference system: The acrylamide-free JUMO gel is used for the glass version and the PEI plastic version. This highly viscous KCI solution lends itself ideally to measurements in general acqueous media. For measurements in media containing few ions, or with high flow rates, the electrolyte can be equipped with an optional "salt reservoir" for a longer operational life.
The JUMO BlackLine model employs a polymerized KCl solid electrolyte. The JUMO cartridge-type conduction system - tried and tested for many years - is used as the reference system. So the electrolyte remains free from silver ions and therefore less susceptible to electrode poisons. In the glass shaft version, JUMO ecoLine electrodes feature a ceramic diaphragm. The model with plastic shaft in transparent PEI comes with a glassfiber diaphragm. A push-on proctection basket protects the sensor when used with handheld measuring equipment. The JUMO BlackLine has an open annular-gap diaphragm, the shaft is made from black PPO and features an integral protection basket....
|
|
Refine your measurement!
Highest accuracy and easy care - these are the two outstanding properties of Unitrode and Aquatrode Plus. The fixed ground-joint diaphragm is largely insensitive to contamination; its constant electrolyte flow guarantees a low-noise measuring signal even in difficult samples and independent of the measuring conditions. Try also our Sufactrode and ISE electrodes!
|
|
|
|
|
|
SCHOTT® Instruments IoLine – pH electrodes for the most demanding measuring tasks
The new IoLine electrode family with iodine/iodide reference system from SCHOTT® Instruments has been developed to meet the most demanding laboratory measurement tasks. These electrodes are 100% metal ion free and hence ideally suited for measurements that are critical towards sample contamination by such ions (e.g. silver ions) and for pH measurements in Tris buffers too.
Advantages of IoLine Electrodes over classical Ag/AgCl reference systems are notably by:
• A longer service life thanks to a patented three-chambers Iod reservoir in the reference electrode.
• Fast reaction, precise measurement and clearly improved stability of measurement values, especially with changing temperatures or at temperatures other than the calibration temperature. This is due to the lower temperature sensitivity of the iodine/iodide reference potential.
• Free choice of the bridge electrolyte, hence optimum adaptation to the sample by double electrolyte system.
The electrodes are available in different membrane glass shapes and types and with different plugs to ensure that the user gets the instrument best suited to his needs. ID versions are available for use with SI Analytics’ s ProLab line of high-end laboratory meters.
IoLine electrodes are the right choice for the most critical pH measurements in research and quality control in pharmacy, biotechnology or food industry.
|
|
|
|
|
|
SteamLine electrodes are low-maintenance pH process electrodes for a wide temperature range from 0 to 135 °C and a pH application range from 0 to 14 pH.
The reference electrode uses a gel electrolyte. A special feature of these electrodes is the even, minimal flow of electrolyte: constant pressure is exerted on the electrolyte by a pressure mechanism that is integrated into the reference electrode. This ensures reliable and reproducible measurement results, and poisoning of the reference system can be avoided. That is why the useful life of SteamLine electrodes is substantially longer in comparison with non-pressurized, low maintenance electrodes.
We manufacture SteamLine electrodes out of the highly alkali-resistant S Glass developed for the most extreme conditions. As a result, the electrodes can not only be utilized for SIP applications (Sterilization In Place, temperature of up to 135 °C), but also for CIP cleaning applications (Clean In Place), in which hot, concentrated sodium hydroxide solution is utilized. Electrodes that were designed for this type of extreme cleaning processes can also demonstrate their strengths under other extreme application conditions.
SteamLine electrodes are available in different versions and lengths.
|
|
A wide range of industrial electrodes and probes are conceived for different uses : water, wastewater, food, textile, paper, pharmaceutical, cosmetic, chemical industries.
A platinum resistance Pt 100 incorporated assures the mesurement and the automatic correction of temperature.
Wide ranges of adaptations :
- in tanks: canes up to two meters
- on pipes: stainless steel, polypropylen, PVC
- in reactors: sleeves to be soldered
|
|
Hanna Instruments, a world leading producer of electro-analytical instrumentation, introduces a complete line of Ion Selective Electrodes (ISE’s) to complement their extensive offering of high performance electrochemical electrodes. With the considerable advantages offered by ISE technology to analytical chemistry, these electrodes are ideal for use in many industries including agriculture, education, food processing, biomedical, metal finishing, waste treatment, power generation and water quality monitoring. Compatible with any ISE meter they may be used with a variety of analytical techniques. Developed and produced in Hanna’s state of the art ISO 9001 production facility, each electrode is rigorously tested to confirm high performance, durability and quick response.
Hanna’s new Ion Selective Line is fully supported with ionic strength adjusters, filling solutions and certified standards.
|
|
Jenway supply a full range of pH electrodes for general purpose use and specific applications.
Combination and three-in-one (with in-built temperature compensation) as well as half cell and reference electrodes. a wide range of different sizes and shapes are available from long reach to small sample volume requirements.
All electrodes are supported with fill, storage and cleaning solutions as well as pH buffers in bottles and sachets.
Application specific electrodes are available for food samples, the life sciences, environmental samples and many more...
|
|
|
|
|
|
Orion ROSS Ultra® Premium pH Electrodes
The best of the best! The fastest response, highest accuracy, and best reproducibility that you can get with a pH electrode plus a 2 year warranty. ROSS Ultra pH electrodes combine all the benefits of the ROSS line with an extended life expectancy and minimized long-term drift. The ROSS reference offers stable, fast results regardless of temperature or sample composition.
Orion ROSS® pH Electrodes
The ROSS line offers precise pH measurements with unmatched stability, reliability, and rapid response regardless of temperature or sample composition. Since ROSS electrodes do not contain silver or mercury, they are well-suited for biological media, food, and pharmaceutical samples where metal ions cannot be tolerated. ROSS Sure-Flow® electrodes have a unique free flowing reference junction with an easy-to-clean design that assures stable, drift-free measurements.
Orion AquaPro Professional pH Electrodes
Low maintenance electrodes with an extended life, fast response, and clog-resistant junction. The double junction reference system prevents silver from coming in contact with the sample, so AquaPro electrodes can be used in samples where metal ions cannot be tolerated.
|
|
|
|
|
|
Our broad range of sensing systems apply sensor technologies directed at specific application challenges.
Flowing junction technology is used specifically for pure waters, whereas solid-polymer and solid-matrix sensors are used in aggressive process streams. High temperature measuring electrode are available for applications up to 140°C; while flat glass promotes self-cleaning efficiency in highly fouling media.
The AP121 is a highly process-resistant 12mm combination pH/Redox (ORP) electrode. It is equipped with a rugged solid electrolyte providing effective combat of process poisons and fluctuating pressures. The electrode has all three measuring elements located closely together and a very fast temperature response. This ensures high integrity of calibration and leads to tighter control. Already a number of years in service, the proven multi-pole VP connector facilitates easy connection and disconnection of multi-parameter sensor signals.
- Exceptional resistance to poisoning and pressure
- IP67 (NEMA 6P) ingress protection
- High corrosion resistance and steam sterilizability
- Assured high accuracy of calibration and operation
- Rapid response enabling tighter process control
- Unparalleled resistance to plugging
- Extended life and improved performance
|
|
The Foxboro family of analyzers, sensors and accessories are suitable for on-line, continuous measurement of pH and ORP in a wide variety of industrial processes.
Benefits:
- DolpHin Series pH Sensors deliver longer life and more reliable pH and ORP measurement in the harshest process applications
- pH Analyzers - line and loop powered units with industry-leading ease of use
- Advanced Sensor Diagnostics - predictive maintenance indication optimizes asset utilization
- Longer life than other sensors in high temperatures and harsh applications
- Reduce maintenance costs
- One sensor style fits all process connections - reduces types of sensors in store
|
|
WDP and WPH Series Controllers are a perfect match with Walchem's WEL pH/ORP electrodes - offering an extremely reliable differential measurement technique immune to any possible ground loop problems.tible with GLI and Aquametrix (Lisle Metrix) controllers.
Together they provide a true NEMA 4X system with no BNC connectors exposed to wet or corrosive conditions. Walchem's pH/ORP controllers and sensors are engineered to give you the most reliable measurement and control available.
|
|
Rugged refillable flat surface pH electrode
* Refillable pH electrode that can be reused by refilling the reference solution once it depletes
* Obtains continuous high accuracy using fresh reference solution
* Fast and easy steps to refill your electrode
* Eliminates the concern of electrode shelf life
|
|
|
Eutech offers a wide range of pH meters that measure pH values in various educational, laboratory and industrial applications. These include the pHTestr10, 20 and 30 pocket testers, portable meters CyberScan Series pH 300, pH 310, pH 11 and pH 110, EcoScan pH 6 and the CyberScan bench meter series 510, 1100, 2100, 1500 and the colour touchscreen research-grade series 6000.
|
|
