iCM4011 is a dsPIC embedded communication module that makes it possible to quickly and effectively develop applications requiring calculation capacities of up to 30MIPS.
Its architecture is based on a next-generation DSP and incorporates transceivers for the most common communication protocols (RS485, RS232, USB and CAN) to allow interaction with the largest possible number of peripherals.
The board can also be USB powered, giving the module full plug&play functionality.
The processor comes preprogrammed in the factory with bootloader firmware that allows the user to load programs through a RS232 or USB port in a few seconds, without the need for an external programmer or additional software.
It also incorporates an ICSP connector for debugging applications.
Main features:
------------------
* dsPIC 16 bits processor (RISC MCU + DSP)
* 48 KBytes of program FLASH memory
* 2048 Bytes data RAM
* 1024 Bytes data EEPROM
* 30 I/O Ports
* 9 ADC channels (10 bits/sample)
* Auto switching power supply modes: Regulated / USB
* LED indicators
* Small size (38.1 x 38.1 mm)
* Interfaces and Transceivers
o SPI
o I2C
o USB
o RS485
o RS232
o CAN
* Motor control features
o 6 PWM channels
o Quadrature encoder interface
* Other features
o 5 timers
o 4 input capture/compare
o Brown-out reset
|
|
|
|
|
|
The Z32Embedded DOS is the base components for realizing a Z32 CNC system. It is installed in the electrical cabinet, and it come sin two versions:
- Embedded DOS.
DOS Operative syetem.
Simply connecting a standard qwerty keyboard and a SVGA monitor to Z32 Embedded it is possibile to use the simple, but complete, DOS interfaces.
If it is connected (through Ethernet cable) with an external console PC, the strongest point of the Z32Embedded DOS is the complete and definitive separation between the real time controller (axes and PLC) and the supervisor connected with an Ethernet cable.
- Embedded WRT
Windows Real Time Operative System
The Embedded WRT has the same features of the Embedded DOS, but the Windows operative system permits to use evolute human-machine-interfaces without needing an extern console PC.
(HMI) -- Human-Machine-Interface:
D.Electron has developed a full software suite ("Z32 for Windows") for installing, servicing and using the Z32 CNC's.
It is however possibile for the machine manufacturer to develop its own interface.
|
|
VM-1 is a highly capable, low power embedded controller intended for
Intelligent instruments
Hand-held devices
Industrial automation
Process control
Security systems
and many other applications
Programmed in Venom-SC, the VM-1 can handle
Analogue and Digital I/O
Graphical User Interfaces
TCP/IP Internet protocols
Data and Text files
More capabilities...
VM-1 has lots of I/O on board and an enormous potential for expansion.
2 Serial Ports up to 38,400bd Async; 250Kbd Synch
1 Serial Port up to 9,600bd Async
2 I2C bus (Master only)
1 SPI Bus
1 Dallas 1-Wire Bus
10 Pulse I/0 Channels (6 PWM..., 4 Pulse counting)
2 Quadrature shaft encoders (4 inputs)
8 Analogue inputs (10-bit)
2 Analogue outputs (8-bit)
42 Digital I/0
System bus for Ethernet, Graphic LCD, etc
|
|
|
Computer independence is a key advantage of the VXI platform, and a wide range of solutions are available from many different sources. To provide complete VXI subsystems, VXI Technology offers a broad array of VXI slot 0 interfaces and controllers.
|
|
Sigma Air Manager
To be able to control air systems reliably, a comprehensive exchange of data between the master controller and the internal compressor controller is required.
Unrivalled technical performance and large memory capacity are the main features of the industrial computer that is the heart of the SIGMA Air Manager. The Profibus DP interface (master) allows a single cable to quickly and efficiently exchange large amounts of data with the the SIGMA Control Profibus interface (slave).
The components of this automation system allow a far more sensitive, energy-saving and sure control of compressed air supply equipment than conventional base-load sequencers with their limited rates of data transfer and processing.
- Enables unrivalled control and system flexibility
- Simple installation and interconnection
- Clear menu structure
- Easy parameter setup
- Pressure band control to within +/- 0.1bar
- Fast 32bit technology
- Teleservice capability
|
|
SIMATIC S7-mEC-RTX F is a safety, embedded controller in S7-300 design pre-installed with Windows XP Embedded and the SIMATIC WinAC RTX F S7 software controller.
It combines the benefits of the field-proven modular S7 controllers and PC technology in a single device, and it is especially suitable for high-performance applications.
All common PC interfaces, such as Ethernet or USB, are onboard as standard for open networking with the office world.
Both standard and safety tasks can be solved with just one controller.
The SIMATIC S7-mEC-RTX F can be expanded centrally with the safety I/O modules of the ET 200M. Distributed expansion is possible with the safety I/O ET 200S, ET 200M, ET 200pro (IP67) or the safety block I/O ET 200eco (IP67).
Communication can take place via the PROFIBUS or PROFINET interface.
|
|
| ... products without technical information |
| |
Embedded panels
Description
Magelis Smart is as easy to set up as it is to maintain.
Simple and easy tp use
Standard Windows XPe technologies
Touch-sensitive screen and viewing angle of up to 160°
Swapable with most Magelis
Dependable availability
Compact
Rugged : Hardened and UL 508, CSA certification
Open
Internet/intranet access
Easier to upgrade : Fast Ethernet 10/100 Mbps port, Compact Flash card, 2 PCMCIA expansion slots
2 Fast Ethernet ports
|
|
|
|
