You are looking for an electric power source that is:
· Silent
· No Vibrations
· high level current quality
· Totally clean (no polluting emissions)
· Clearly indicates amount of energy production remaining
Easy to handle and simple to store, Mobixane™ allows all-terrain use, indoors* or outdoors.
Technical Specifications
Power range 0,5 to 2,5 kW
Overload capacity 5 kW in 1 second
User voltage 110 V AC / 60 Hz
230 V AC / 50 Hz
48 V DC
Battery charger mode 48 V DC
Output sinusoid THD1 < 5% with resistive load
Electrical protection surge protection and short-circuit
Noise 50 dba at 1 meter
Weight w / o storage 75 kg without hydrogen
Dimensions 66 x 48 x 48 cm (200 liters)
Maximum power Instantaneous transient
Storage temperature -40°C to + 70°C
Operating temperature 0°C to +45°C
Maximum altitude Up to 3 000 meters operating
|
|
|
|
|
|
You are looking for a plug-in power source that:
· highly self-sustaining
· totally silent
· totally clean (no polluting emissions)
· light and modular
Auxipac ™ is modular and compact and can be integrated into different types of applications. It can mainly be used as an auxiliary power source, in order for example to extend the self-containement of a motor vehicle or a piece of equipment. But Auxipac ™ may also be used as the main power supply source of a system.
Power range .... 0,5 to 5 kW
Battery charger
Option main
powersupply .... 12, 24 or 48 V DC
12, 24, or 48 V DC
110 or 230 V AC
Output sinusoid .... THD1 < 5% with resistive load
Electrical protection .... surge protection and short circuit
Sound pollution .... 50 dba at 1 meter
Weight w / o storage .... 75 kg
Dimensions .... 66 x 48 x 48 cm (200 liters)
Maximum power .... Instantaneous transient
Storage temperature .... -40°C to + 70°C
Operating temperature .... 0°C to +45°C
Maximum altitude .... Up to 3 000 meters operating
EC label .... in process
UL/CLSA labeling .... in process
|
|
In the last years COELMO® started the developing of new generating sets using Proton Exchange Membrane (PEM) fuel cells fed by hydrogen. COELMO®’s hydrogen-fueled products create high quality, reliable power and offer the security of standby, emergency or uninterruptible power where it is needed most.
COELMO® has developed a backup power generator fed by pure hydrogen for indoor operation. H2POWER – BPG120 is a fuel cell generator powered by Ballard's fuel cell technology.
COELMO® is now developing a natural gas-fueled 2kW combined heat and power generator for the residential market H2POWER – CHP200.
|
|
|
|
|
|
A single complete energy offer, combining Fuel Cell and Hydrogen, for a main power supply.
You are looking for an electric power source:
· with great self-sustainability
· with excellent current and voltage quality
· that is totally clean (zero emission of pollutant or greenhouse gas)
· designed to resist both climatic extremes
· delivering direct and/or alternating voltage
· that is silent
Technical Specifications
Power range .... From 0.5 to 10 kW (1 to 2 modules)
Overload capacity .... From 5 to 20 kW (depending on the configuration)
User voltage .... 110 V AC / 60 Hz
230 V AC / 50 Hz
48 V DC
Battery charger mode 48 VDC
Output sinusoid .... THD1 < 5% with resistive load
Electrical protection .... surge protection and short circuit
Sound pollution .... 45 dba at 1 meter
Weight .... 60 kg without hydrogen
Dimension .... 115 x 170 x 210 cm
Maximum power .... Instantaneous transient
Storage temperature .... -55°C to + 70°C
Operating temperature .... -40°C to +45°C
Maximum altitude .... Up to 3 000 meters operating
EC label .... in process
UL/CSA labeling .... in process
|
|
|
|
|
|
A complete global energy offer, combining Fuel Cell and Hydrogen, for backup power.
You are looking for an extended backup solution:
· with long autonomy
· that can be operated outdoors as well as indoors*
· that is silent, vibration-free, with no emission of pollutants or greenhouse gases
· that has excellent direct and alternating current and voltage quality
Comm Pac ™ Backup / UPS is reliable and can be used indoors and outdoors. It is the perfect high tech extended backup solution. In combination with hydrogen logistics, autonomy can be extended as required.
Power range .... From 0.5 to 10 kW (1 to 2 modules)
Overload capacity .... From 5 to 20 kW (depending on configuration)
User voltage .... 110 V AC / 60 Hz
230 V AC / 50 Hz
48 V DC
Battery charger mode 48 VDC
Output sinusoid .... THD1 < 5% with resistive load
Electrical protection .... surge protection and short circuit
Sound pollution .... 45 dba at 1 meter
Weight w / o storage .... 600 kg
Dimensions .... 115 x 170 x 210 cm
Maximum power .... Instantaneous transient
Storage temperature .... -55°C to + 70°C
Operating temperature .... -40°C to +45°C
Maximum altitude .... Up to 3 000 meters operating
EC label .... in process
UL/CLSA labeling .... in process
Standard product self-sustainability
(based on 6 cylinders of 8.5 Nm3 at 200 bars each)
at 5 kW : .... for 15 hours
at 2,5 kW : .... for 30 hours
at 1 kW : .... for 72 hours
at any power2 .... self-sustainability over several weeks or several months with external reserve or restocking
|
|
LIPA realizes the importance of looking towards the future. With responsibility for the
retail electric system on Long Island, LIPA is faced with continually increasing energy
needs. While striving to provide reliable, cost-effective service to customers throughout
its service territory, LIPA also makes environmental concerns a top priority.
|
|
