A TorcUP Hydraulic Torque Wrench is a tool designed to exert torque on a fastener to achieve proper tightening or loosening through use of hydraulics. A torque wrench is applied to the nut either directly or in conjunction with an impact socket. Hydraulic torque wrenches directly apply a predetermined, controlled amount of torque to a properly lubricated fastener, eliminating the guess work necessary with stud tensioning and turn of the nut methods of bolting. Hydraulic torque wrenches also dramatically increase worker safety and efficiency.
TorcUP Inc. TU Series Features
*Patented Mono-Body Housing
This feature allows for direct reaction against the housing of the tool, as well as significant reduction in housing flex and torsion.
*Dual Independent Swivels
360 degree by 360 degree swivels allow for individual movement of duplex hoses. Steel construction adds durability.
*Push Through Square Drive
Change the direction of the tool from loosen to tighten by pushing the Vascomax square drive through the tool.
*Laser Engraved Torque Chart
The torque chart for the square drive tool is laser engraved directly on the shroud to allow for quick reference. It also reverses from Ft/lbs- PSI to Nm-Bar.
*Quick Connect Couplers
*Body Material
The TU Series housing is manufactured from 7075 Aircraft Quality lightweight alloy.
*U.S. Patent No. 6,068,068
|
|
|
|
|
|
TX Series Low Profile Hydraulic Torque Wrenches are designed for installing and removing large bolts having minimal wrench clearance at offshore platforms, power plants, steel erection sites and other locations requiring precise high torque during bolt makeup and maximum torque for bolt break out.
*Patented "Peanut-Shaped Piston"
This feature allows for the cylinder and ratchet link to be
the same width. Friction reducing sliders prevent wear
on the piston.
*Dual Independent Swivels
360 degrees x 360 degrees swivels allow for individual movement
of duplex hoses. Steel construction adds durability.
*Hex Link Cassettes
Steel alignment pins connect lower reaction area
for added strength.
*Quick Connect Couplers
Each tool is fitted with quick connect, no-drip,
thread less safety couplers, with 4:1 safety ratio.
*Cylinder and Link Material
Both cylinder and link are manufactured from
4340 Aircraft high strength steel alloy.
*Nose Radius
Tight nose radius allows this tool to fit applications
where clearance constraints make other tools too bulky.
|
|
No tools are needed for changing the heads
Innovative, pinless wrench construction incorporates quick
release cylinder and automatic crank engagement
Cylinders and low profile heads have been engineered to give
ultra slim, compact low clearance tooling with a small nose
radius
Robust design with minimal parts enables easy on-site
maintenance without special tools
Nut sizes covered range from 17/16 - 45/8 inch AF (36 – 115 mm)
Optimized strength-to-weight ratio
Fast operation due to the large nut rotation per wrench cycle
(30 degree rotation angle) and rapid return stroke
|
|
Extra light, small and handy, the LÖSOMAT high torque hydraulic wrench works powerfully at up to 27.000 Nm. It carries out its work reliably in the tightest of spaces. The smallest hydraulic wrench in the world, LDH-12V, is part of this series.
Main application areas:
Steel construction, power plants, mining, transport industry, chemical industry and refineries, mechanical and construction engineering, oil and gas industry
|
|
|
|
|
|
Power Team unleashes the ALL NEW PredatorTM Series, a premium line of high performance steel torque wrenches.
Low Clearance Torque Wrench
Square Drive Torque Wrench
Power Team® introduces Predator Series - its newest line of high performance tools serving the global bolting industry. This family of high performance hydraulic products raises performance and reliability to a new level.
After decades of serving the high force torque wrench tool industry, the Power Team portfolio of products and systems is expanding to include a new series of durable steel square drive and low clearance hydraulic torque wrenches.
This new generation torque wrench features more efficient and faster operation in an envelope size that is 2/3rds the size of aluminum wrenches, allowing the tool to be used in applications where space is limited, yet is still comparable in weight.
The Predator range of wrenches offers a reliable performance based solution to your challenging bolting needs. We look forward to introducing the Predator family of wrenches and accessories to your application. Contact us for more information.
Future generations of Predator will include electric, air and gas powered high-performance hydraulic pumps.
Faster - Quieter- More Powerful . . . Predator by Power Team.
|
|
HYTORC’s latest Bolting Machine, the AVANTI™ - A Winner in the 2003 Plant Engineering Product of the Year Awards competition as an Innovative Maintenance Product, is not just the most user-friendly, but is the most universal bolting tool. Convertible for regular-, medium- and highly critical jobs, from torque to tension, from an unprecedented torque-accuracy to an unprecedented bolt load-accuracy.
We invented every major improvement in Hydraulic Torque Tools in the last 25 years, to give you the latest Technological Product which handles any job you have and any one you might come across, safely!
We give you lightweight, speed, reliability and precision in a user-friendly way. We provide the accessory to make your HYTORC the most universal tool money can buy.
|
|
|
Hi-force TWS-N series lightweight aluminium hydraulic torque are designed to handle the tughest bolting jobs accurately and quickly. All modelsn provide a torque accuracy of +/-3% with a handy torque chart clearly angraved on the tool.
|
|
HYTORC’s latest Bolting Machine, the AVANTI™ - A Winner in the 2003 Plant Engineering Product of the Year Awards competition as an Innovative Maintenance Product, is not just the most user-friendly, but is the most universal bolting tool. Convertible for regular-, medium- and highly critical jobs, from torque to tension, from an unprecedented torque-accuracy to an unprecedented bolt load-accuracy.
We invented every major improvement in Hydraulic Torque Tools in the last 25 years, to give you the latest Technological Product which handles any job you have and any one you might come across, safely!
We give you lightweight, speed, reliability and precision in a user-friendly way. We provide the accessory to make your HYTORC the most universal tool money can buy.
|
|
Features and Benefits:
Bolttech's HydraLinks convertible bolting tools offer the global market the first and only 4-in-1 industrial bolting tool system. The HydraLinks tools are lightweight, compact, and versatile to allow the operator ease of use on most applications with greater efficiency. HydraLinks offers a hydraulic cylinder that comes standard with a multi-swivel feature and is available in five graduated torque ranges offering the broadest range of torque and hex link combinations in the industry.
Additional Features & Benefits:
- Multiple-Link-Connection Cylinder
- Mutli-Swivel 360° x 360° Rotataions
- Accuracy Assurance Pawl
- Factory Calibration
- Multi-Indexable Cylinders
- 12-Point Reaction Bar
- Aluminum Bronze Drive Bearings
- Aluminum Bronze Piston Rod Bushings
- Modular - Innovative Design for Ease of Operator Use
|
|
Double Acting Cylinder
360° x 180° Swivel hose connection to reduce hose whip lashing & easy usage at restricted areas
Special high strenth, ultra-light Aluminium alloy material for strength & light weight
360° adjustable reaction arm with trigger style lock for easy adjustment
Compact unibody design with one way ratchet mechanism
Minimum moving parts for durability & low maintenance
External ratchet freeing mechanism
Working pressure of 700 bars
Accuracy ± 3%
|
|
Linear Cylinder Type Hexagon Torque Wrench
Torque Capacity up to 21,180 Nm, Hexagon Cassettes A/F sizes 32mm to 130mm, Maximum Working Pressure 700 Bar.
Double Acting Cylinder.
Linear Power Head - flat & sleek,suitable to exchangeable cassette with one way ratchet mechanism.
Optional square drive cassette attachements for use with Power Head of TLC-28 and TLC-54 models.
Extra Sleek - Ultra strong, exchangeable cassette suitable to limited space.
Special high strength, ultra-light Aluminium alloy material for strength & light weight.
Very compact design with best torque to weight ratio.
Quick exchange of cassettes without using any tools.
360° revolving hose connections.
Torque precision ± 3%
|
|
The Ideal Hydraulic Tension Tool has continuous Rotation!
The Ideal Hydraulic Tension Machine is HYTORC-XXI®!
Stud-tensioning should be fast, hands-off, precise and at decent pressures. The 10,000 psi, 700 bar XXI incorporates the Latest Technology in Bolting tools, - Continuous Rotation. By use of the HYTORC or the HYTORC CLAMP
Accessory, the XXI reinvented Industrial Bolting providing for the first time an unprecedented Bolt Load precision and Reliability at an unprecedented Speed and Safety.
Continuous Rotation
Anti Backlash Design
360 degree Uni-swivel
Simultorc-switch*
New Ergonomic Design
3 times faster than prior art
360 degree Job-adjustable
300,000 psi Alloy-mechanism
Torsion-free internal Mechanism
Upgradeable for Stretch-to-load!
|
|
The Stanley ID07 Impact Wrench develops up to 500 foot pounds (675 Nm) of impact torque making it an ideal tool for drilling holes from 1/2 to 1-1/16 inch diameter, 18 inches in length and working with fasteners of the same size diameters.
The Stanley IW12 Impact Wrench produces up to 1200 foot pounds (1632 Nm) of impact torque. The IW12 is used for nut, bolt and anchor bolt driving and is equally popular for wood boring and drilling.
The Stanley IW16 Impact Wrench produces up to 2500 foot pounds (3400 Nm) of impact torque. The IW16 is used for nut, bolt and anchor bolt driving and other medium to heavy duty applications.
The Stanley IW24 Impact Wrench produces up to 3500 foot pounds (4760 Nm) of impact torque. The IW24 is used for nut and bolt and anchor bolt driving and other heavy duty applications.
|
|
| ... products without technical information |
| |
|
|
|
|
The ZA4T-Series air hydraulic torque wrench pumps can be used with any brand of 700 and 800 bar single- and double-acting hydraulic torque wrenches. The ZA4T come standard with air regulator-filter-lubricator unit, heat exhanger and pressure gauge. The standard pressure gauge with transparent overlay-scales in Nm and Ft.lbs provides accurate torque settings and precise repeatability for all Enerpac torque wrenches. The easy to access adjustable pressure relief valve allow accurate and quick setting of hydraulic pressure. The air motor consumes between 600 - 2840 l/min at 4 - 7 bar dynamic air pressure. ZA4T-Series two-speed air pumps come with 4 or 8 litres reservoir. Through the years the Enerpac line of bolting tools, such as hydraulic torque wrenches and alignment tools, has gained excellent recognition by the offshore and oil & gas markets worldwide. Through its worldwide operations Enerpac is be able to offer application-based solutions and hydraulic systems for the offshore and other industries
|
|
Resato’s new lightweight mini pump unit is available in four pressure ranges up to 1800 bar at 7 bar air drive pressure and 2500 bar at 10 bar air drive pressure.
Key Features:
- Ready-to-use.
- Pressure range up to 2500 bar / 36,250 psi.
- weight of less than 17 kg!
- Lightweight, easy to carry.
- Low noise level.
- Suitable for pressurizing oil, water or other fluids.
- Several pressure ranges available.
- All parts made of non-corrosive materials.
- All operating features panel mounted.
- Completely closed frame.
|
|
|
|
