- Laser diode current source with integrated 32W temperature controller
- Three models available with up to 4A laser drive current
- GPIB/IEEE-488 remote interface
- High stability, low noise laser current source operating in constant power or constant current modes.
- Analog modulation capability to 1MHz
- 4-wire laser forward voltage measurement and adjustable voltage limit
- Temperature controller compatible with thermistor, IC, and RTD temperature sensors
- Temperature stability of ±0.004°C
- TE voltage measurement
|
|
|
The OP250 is a configurable stabilized light source with a variety of Lasers and LEDs. Available in a single port or dual port configuration, selectable wavelengths, and various power levels and industry standard optical interfaces this instrument offers all the features and functions necessary for the development, testing and inspecting of optical components and cables.
|
|
FEATURES:
- Ultra Low Noise: <10mA*
- High Current without Heat Sink: 1A
- High Absolute Accuracy: <0.1%
- High Stability: 100ppm/°C
- Dual Modulation Ports: High/Low Speed
- Low Drop Out Voltage: 1V
- Complete Shielding
- Compact Size
- SMT Package Available
- *Total RMS between 0.1Hz to 0.5MHz.
APPLICATIONS
- Driving diode lasers with low noise, including DPSSLs,
EDFAs, fiber lasers, diode laser modules, etc.
|
|
| ... products without technical information |
| |
|
The ZL40514 is a high performance laser driver capable of driving two separate cathode grounded laser diodes (e.g. 650 nm and 780 nm laser diodes). The ZL40514 contains a 150 mA low noise read channel (ChR), and three 500 mA LVDS controlled write channels (Ch2, Ch3 and Ch4). The Read channel amplifies the positive current supplied at its reference input, INR, by a fixed factor of 100. Write channels amplify the positive currents supplied at its reference input IN2, IN3, and IN4 by a fixed factor of 240. An on-chip RF oscillator is provided for the reduction of laser mode hopping noise.
|
|
| ... products without technical information |
| |
The ProWriterTM D10 is a Q-switched, end-pumped Nd: YVO4 (vanadate) laser marker with excellent beam energy density. The D10 offers the power and versatility to mark ceramics, diamonds, silicon, steel, and other non-ferrous materials and alloys. The D10's small footprint allows for bench top operation or integration into crowded production lines. Important features:
10 Watt, YVO4 diode laser marker (also available in 20 watt)
Available with 4" and 6" marking fields
115 VAC, 50/60 Hz single phase operation
Estimated 25,000 hours diode life expectancy
Air-cooled, requires no external cooling
Pentium® computer and Windows® XP Professional
17" LCD monitor, keyboard, and mouse
Multi-gigabyte hard drive and 512 MB RAM
DVD-RW, Serial, parallel, and USB ports
Ethernet capable
Laser Marking StudioTM software
Two year warranty
|
|
The ProWriterTM D25T is a 25 watt diode-pumped laser marker featuring a TEMoo beam profile. This compact laser system is ideal for specialized applications requiring a tightly focused beam with high energy density. The D25T marks a wide variety of marks on: metals, ceramics, composites, plastics, painted/anodized metals, and many others.
Features
Two Year Life Warranty (10,000 Hour Diode Pack)
Reduced Maintenance
Internal Stainless Steel Chiller
Lower Operating Costs
Improved Beam Density For Better Marking
Available in 4", 6" and 12" Marking Field
|
|
Description
Compact diode-pumped Nd:YAG Laser with outstanding beam quality. Cabin equipped with a large sliding door, tangent-bent to the top, with window to provide optimum feed conditions and access for setting up workpieces.
Features
- Travel ranges (X - Y optional, Z standard) X - Y - Z 200 mm x 200 mm x 300 mm
- Z axis with electrical adjustment
- Refrigerating set to cool the laser, thus no external water supply required
|
|
|
|
