Max. Lifting Capacity: 180t x 3.75m
Max. Crane Boom Length: 85.3m
Max. Long Boon Length: 85.3m
Max. Fixed Jib Combination: 73.2m + 30.5m
Max. Luffing Jib Combination: 54.9m + 51.8m
|
|
CRANE BOOM
Max. Lifting Capacity: 135 tons @ 4.5 m
LUFFING BOOM
Max. Lifting Capacity: 80 tons @ 8.0 m
LONG BOOM
Max. Lifting Capacity: 44.3 tons @ 10.6 m
FIXED JIB
Max. Lifting Capacity: 26.8 tons @ 16.0 m
LUFFING JIB
Max. Lifting Capacity: 36 tons @ 12.0 m
Whether positioning bridge girders or constructing tall buildings, smooth and speedy operation is the most important performance. KOBELCO CKE1350 crawler crane is designed with latest job trends in construction environment. With its excellent operability, sensitive controls, and most important, its safety features, the CKE1350 achieves the best balance in its
overall performance. In regular crane or luffing jib operations for building construction, as well as general foundation work, there's more than enough capacity. The difference is in its basic performance.
|
|
SL 6000
Max. Lifting Capacity: 550 ton
STANDARD
Max. Boom Length: 108 m
Max. Luffing Jib Combination: 60 + 72 m
HEAVY LIFT
Max. Boom Length: 108 m
Max. Luffing Jib Combination: 66 72 m
SUPER HEAVY LIFT
Max. Boom Length: 126 m
Max. Luffing Jib Combination: 84 84 m
The KOBELCO SL6000 crawler crane, with a lifting capacity of up to 550 tons, targets large-scale energy-related projects and large infrastructure installations. In addition to its superb lifting capacity, the SL6000's innovative unit assembly system' is designed to comply with transport regulations worldwide and to minimize labor required for assembly/disassembly. The SL6000's wide range of attractive features includes advanced safety devices, a wide, comfortable cab giving excellent visibility and other enhancements. KOBELCO is proud to premiere this much-awaited new model, which will further enhance our global reputation for tough, reliable, and outstanding performance.
|
|
Max. Lifting Capacity: 400 ton x 5.5 m
Max. Luffing Boom Length: 96 m
Max. Luffing Jib Combination: 78 m + 66 m
|
|
Raw power and durability alone are no longer enough in today's fs construction environment, as operators and owners increasingly demand greater comfort and operability. KOBELCO has evolved accordingly with advanced hydraulic technology and onboard electronics that help you get the job done more quickly and reliably than ever before. But the real focus of our machine design is safety, both for the operator and for all the workers on the site. With their ideal combination of power, speed, comfort, operability, and advanced safety features, KOBELCO cranes are being used with confidence throughout the world. And now, we are proud to present them to the European market as the CKE Series.
CKE2500
Max. Lifting Capacity : 250t @ 4.6m
Max. Crane Boom Length: 91.4m
Max. Fixed Jib Combination: 76.2m + 30.5m
Max. Luffing Jib Combination: 61m 61m
|
|
Lattice mast crawler cranes are enjoying a real renaissance, and with good reason. Outstanding lifting capacities, almost unlimited mobility on building sites, simple and quick to transport, self-assembly systems and low investment and running costs guarantee maximum benefit for operators. SENNEBOGEN's robust crawler cranes feature state-of-the-art technology, maximum flexibility and excellent economy.
SENNEBOGEN - Crawler Cranes are avaiable from 80 t - 180 t service weight
|
|
For nearly 50 years SENNEBOGEN has been developing heavy-duty universal rope excavators. Years of experience and the continuous intensive refinement of the product family have produced a complete range of high performance rope excavators featuring state-of-the-art technology. Adaptable to a wide range of jobs, extremely stable and with universal utility; rope excavators will remain indispensable in the 21th century.
SENNEBOGEN - HD crawler cranes are avaiable from 30 t - 180 t service weight
|
|
|
Cranes are supplied by Hitachi Sumitomo Heavy Industries Construction Crane Co., Ltd. (a Hitachi group company). If you want information about these types of equipment, please visit their website.
|
|
|
|
|
|
Link-Belt
138 HSL
80-ton (77.62 mt)
Lattice Boom Crawler Crane
- Best capacities in its class!
- 40’ to 200’ (12.19 m to 60.96 m)
tube boom
- 40’ to 160’ (12.19m to 45.72m)
angle boom attachment option
- Live mast standard
- Maximum boom jib length combination
of 180’ + 60’
(54.86m + 18.28m) tube and
150 +60’ (45.72m + 18.28m) angle
- Tier III whisper quite Isuzu power
at 284hp – tops in its class
- Matching high line pull front &
rear drums with Link-Belt designed
“out board style ”wet brake. This
brake design offers low resistance to
free spooling in free fall mode, even
in cold climates.
- Optional front mounted 3rd drum
and or rear mount high line pull
4th drum (with free fall)
- New fast easy counterweight
removal system
- Hydraulic machine “assembly
cylinder” option - mounted in boom
base section for fast easy assembly
& load out
- HSL style cab with latest comfort
technology, high output A.C, AM/FM
radio, 6 way adjustable seat with
djustable console
- Smooth, precise, Bullet proof hydraulic pilot operated function controls for years of trouble free operation and dependability
- HSL 1 Rated capacity limiter with state of the art electronics including color graphic monitor
|
|
With the LR series, Liebherr offers a well-balanced programme of lattice boom crawler cranes. In the class below-300 metric tons, low transport weights, rapid self-assembly, optimum load capacity values across the entire working range and comprehensive operating information are among these cranes' main functional features.
For its larger crawler cranes with lifting capacities up to 1,350 metric tons, Liebherr also offers a wide range of multifunctional jib systems. These cranes can reach heights of up to 223 m at the hook and working radii of up to 152 m, but retain their outstanding manoeuvrability thanks to innovative solutions for the handling of extremely high ballast weights. The LR series is completed by the hydraulic duty cycle crawler cranes range (HS series), which is similar to the LR series in design. The machines have been developed for the most diverse material handling operations. This series comprises 6 models with load capacities between 35 and 200 metric tons.
|
|
|
Manitowoc offers 15 models with capacities ranging from 73 t (80 tons US) to 2 300 t (2,535 tons US). Over 75 years of innovation, experience and passion go into every Manitowoc
|
|
|
The variety of applications of the HS 835 HD is nearly unlimited due to several equipment possibilities and includes jobs like material handling with clamshell, dragline bucket or similar, different types of demolition applications, dynamic soil compaction and jobs with diaphragm wall grab or casing oscillator.
|
|
|
Crawler cranes deliver excellent mobility over soft surfaces. These multiple-purpose cranes can be used in a broad range of applications, ranging from construction to civil engineering and port cargo handling.
|
|
Link-Belt
HC-238H II
150-ton (136.08 mt)
Lattice Boom Truck Crane
- 50’ – 260’
(15.24 – 79.25 m)
tube boom
- Maximum boom & jib
combination: 230’ + 75’
(70.10 + 22.86 m)
- 308’ (93.88 m) maximum
tip height
- 270’ (82.30 m) maximum
360° working radius
- Maximum luffing attachment length:
Luffing boom – 165’ (50.29 m);
Luffing jib – 150’ (45.72 m);
Fixed jib – 30’ (9.14 m)
- 348’ (106.16 m) maximum luffing attachment working height
- 240’ (73.15 m) maximum working 360° radius
- Height - 12’ 6” (3.81 m); width – 11’ 0” (3.35 m); length – 34’ 7.25” (10.55 m)
- 23’ 6” (7.16 m) wheelbase
- 85,334 lbs (38 706 kg) travel weight
- Upper engine: 200 hp (148.4 kW)
- Lower engine: 430 hp (321 kW)
- Outrigger spread: 22’ 8” (6.91 m)
- Outrigger base: 19’ 10” (6.05 m)
- 35,913 lbs (16 290 kg) maximum winch line pull
- 557 fpm (169.77 mpm) maximum winch line speed
|
|
|
Manitowoc offers three lattice-boom truck cranes with capabilities ranging from 132 tonnes (91 tons US) to 272 tonnes (300 tons US).
|
|
|
Depending on the individual application requirements, the LG 1550 can be operated as an 800 t heavy-duty telescopic crane, type LTM 1800, with a 60 m telescopic boom. The new LG 1750, a 750 t powerful lattice boom crane featuring an eight-axle chassis, star support and variable boom system, was unveiled at the BAUMA 2004. LG lattice tower mobile cranes featuring lifting capacities of 550 t and 750 t are heavy-duty cranes and are designed for versatile application conditions.
|
|
|
Manitowoc offers 15 models with capacities ranging from 73 t (80 tons US) to 2 300 t (2,535 tons US). Over 75 years of innovation, experience and passion go into every Manitowoc.
|
|
|
Crawler cranes deliver excellent mobility over soft surfaces. These multiple-purpose cranes can be used in a broad range of applications, ranging from construction to civil engineering and port cargo handling.
|
|
The Favelle Favco crawler crane range is jointly developed with Caterpillar Industrial Products Inc and are a combination of Favelle Favco lifting technology and Caterpillar technology. The model lineup is divided into lattice boom and telescopic boom. The crane sizes range from 30 ton to 60 ton with a telescopic boom and 60 ton with a lattice boom. The innovative telescopic crawlers are ideal for remote jobs which require quick mobilization as they are able to get to work immediately off a truck without the aid of another crane. Their versatility is even more pronounced as it is able to "pick and carry"on rough terrain.
Applications:
- General Construction Worksites
- Pipe Laying Work
From:
MAX LOAD 27.5t
MIN BOOM LENGTH MAX 8.5m
BOOM LENGTH 27.9m
TIP LOAD 0.3t at 27.9m
To:
MAX LOAD 55t
MIN BOOM LENGTH MAX 10m
BOOM LENGTH 32.3m
TIP LOAD 1.8t at 29m
|
|
