industrial application - lift applications
This scissors lift platform - heavy model is use in the automotive industry.
Application : Sledge change system in a surface treatment plant.
Location : Automotive Industry
Load ( kg ) : 3000
Speed ( mm / s ) : 300
Stroke : ( mm ) 1800
Rate ( / day ) 900
Product in use : HDLift 90 D
Description : Lift Platform, heavy model
lenght : 4000 mm
width : 1400 mm
|
|
This scissors lift platform is used in the market of electrical industry. The Serapid rigid chain standard product in used is the linklift 100.
Application : Electric transformer manufacturing
Location : Energy Industry
Load ( kg ) : 7000
Speed ( mm / s ) : 42
Stroke : ( mm ) 2750
Product in use : LinkLift 100
|
|
|
|
|
|
DuoRam - Hydr. Single-Ram-Lifts
The original version of all lifts, invented in 1924, is the single-ram underfloor lift, which is still of great importance in modern workshops. In certain areas it is the only one to provide ideal working conditions.
To mention just a few of them, e.g the washing bay, the pre-paint area and the numerous repair works that require the vehicle to be freely accessible from all sides.
The new developed DuoRam combines all advantages of a single-ram lift and of a two-ram lift. Two hydraulic cylinders - which building two independing units - grant that the lifted vehicled is safe lifted even in case of failure in one hydraulic circuit. Optimised arrangement of two compact combined guide bars generate a torsion and bending rigidity which is unknow until now.
This innovative lift accomplishes the DIN en 1493 (for vehicles lifts) through its redundant safety system - because safety comes first!
Different support pieces ensure the specific use of this lift, which is simple, yet solid and easy to service - made in JAB quality, it's an investment for decades
|
|
Lifting systems - Startseite
J.A. Becker & Söhne is the eldest lift manufacturer Europe. Since more than 70 year we are specialized in manufacturing hydraulic inground lifting systems.
Our main focus is set on realisation of customer specified workshop solutions and lifting systems, which are suitable for continous application in the automobil production.
Our comprehensive product range includes car and commercial vehicle lifts, as well as specialised lifts for various applications including industrial trucks, special purpose vehicles and rail.
Based on our high construction and manufacturing quality, our lifting systems are used at leading automobile manufacturers all over the world.
For public transportation services we offer special lifting unit. Because of our excellent know-how we have realised several really special projects for lifting buses or railway vehicles.
As special feature, all lifts can be delivered in explosion proofed version!
|
|
High travel material lifts provide an economical, dependable, and versatile method of raising loads to elevations up to 12 feet for standard scissors tables, up to 20 feet for special scissor lift designs, and up to 100 feet for Vertical Reciprocating Conveyors, or VRC Material Lifts. These high travel material lifts can be easily customized to meet ant specific platform, capacity, and foot print requirement, and meet the industry safety requirements.
Autoquip offers the broadest line of high travel lifts in the industry.
|
|
V-25-AFSMC Lift-A-Lift® Work Platform Vertical Travel Maintenance Specifications
Capacity: 20,000# G.V.W.
Width Platform 12'-0"
Length Platform 12'-0"
Entry Opening 50"
Platform Height min. 27"
Platform Height max. 93"
Variable Height Stairway
Motor 5 Horsepower
Power: 230/460/3/60
Hydraulic Lift
Auto Safety Locks
Auto Self Leveling
Hinge Entry Gates (Aluminum)
Lockable Control Pane
Shipped Semi-Assembled
Factory Tested
|
|
Tilt-Or-Lift's Newest Four-Post Maintenance Lift
The new V-30-ALRS Lift-A-Lift® was designed for use by warehouse maintenance departments to service forklifts, reach trucks, stock-pickers, pallet trucks, sweepers, scrubbers and personnel carriers.
Capacity: 30,000# G.V.W.
Approach ramp: 12' long
Runway length: 16'
Runway width: 18"
Entry width: 76"
Hydraulic width adjustment: 56" to 76"
Maximum runway height: 71"
Power: 230/460/3/60
Shipping weight: 8,900#
|
|
GIA Utility/Service Truck. Three models are manufactured today i.e. GIA 111 and GIA 211 which is articulated trucks and GIA TT 24 which is a rigid truck. All three models are 4-wheel driven in order to be able to operate in steep inclinations.
The models can be equipped with e.g. boom and basket, scissors platform for ANFO charging, scaling, different kinds of installations and service works. The trucks can also be used as e.g. small dump truck or shotcreting rig. A combination of several equipments on cassettes makes one truck useful in many different applications.
The main feature with GIA Utility/Service Truck is:
• High productivity
• High safety
• Low investment and service cost
• Well known components
|
|
Scissors lifter
▪ Storage at outside is available
▪ ENTL series are liftable at one point.
Type : wheel, crawler
Max. Ground Clearance : 4.0 - 9.9 m
Max. Lifting Weight : 250 kg
Weight : 550 - 2580 kg
|
|
|
|
|
|
CAR-LIFT
Car-lift is used for the vertical and horizontal transfer of cars - without driver - between several levels of storage or exhibition in a car agency. The driver is only allowed to drive the car on and out the platform.
Car-lift must be equipped with securities in conformity with law or must be embedded in built concrete shafts or metallic cage with plain walls and doors equipped with electro-mechanical interlocks.
Main characteristics of the car-lift shown on the photo :
Lifting capacity : 2000 daN
Platform dimensions : 5,000 m x 2,500 m equipped with safety handrails
Collapsed height : 0,700 m
Vertical stroke : 3,000 m
Particularity of this configuration : The car-lift includes an automatic safety locking device in its high position. It maintains the position of the platform and secure the transfer of cars.(......)
Main options : galvanization, all optional safety equipment, transport facilities, set up and commissioning, maintenance contract....
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Vertical transfer of any kind of vehicles : industrial, for roads, army,... inside or outside buildings, parking, museum, exhibition room....
|
|
Service platforms
AMV Service Platforms are supplied in many configurations. The most popular version is the AMV 10,5. This unit is built on a lorry chassis, it has a maximum working height of the platform floor of 10,5 m. and a lifting capacity of 1500 kg. over the whole working range. It is equipped with four hydraulic support legs. The standard version has a p.t.o. driven hydraulic pump. An electric powerpack can be supplied as an option. Other options are diesel driven compressors and generators for tool operation. All operations are radio operated.
|
|
|
|
|
|
Utilift scissors lifts on our famous mining carrier are designed for lifting and installations in mining and low-profile tunnelling. Utilifts are suitable for roof reinforcement work, charging explosives, hanging cables and installing pipes, ventilation equipment, etc. Typical standard options include a side-shift platform, platform tilt, crane, pipe changing equipment, air compressors, an electric-driven power pack for platform hydraulics, ANFO charging kits and helper platforms. The vehicle’s driving ergonomics can be enhanced with an optional, fully enclosed, high-comfort operator’s cab.
Himecs are the product of long-term collaboration between Normet engineers and global tunnelling customers and experts. This has generated a holistic understanding of customers’ lifting and access equipment needs in both hard and soft rock environments. The wide range of Himecs is ideal for medium to heavy-duty load lifting and work coverage in practically any tunnel profile. With a large variety of platform configurations and standard options, they can be perfectly customized for specific lifting applications. Our new platform load sensing system and other built-in man-lifting safety features comply with the latest safety rules and regulations. Himecs are also CE-approved and feature the famous Normet mining carrier.
|
|
The HAULOTTE diesel scissor lifts offer :
- from 8 to 18 m working heights
- an important working area (platform size up to 6 m x 1.80m)
- a maximum platform capacity (up to 900 kg)
- a remarkable driveability (4 x 4)
|
|
The HAULOTTE electric and Rough Terrain Electric scissor lifts offer :
- from 6 to 12 m working height
- an important working area (platform size up to 3.70m x 1.50m)
- a high autonomy (powerful batteries)
This all-purpose models are very adapted for congested areas.
|
|
|
JLG’s range of scissor lifts is designed for applications where more workspace and lifting capacity are required rather than outreach. The scissor lift provides a large platform work area and allows for heavier loads – for example large sheets of wall cladding. While deck size, load capacity and lifting heights are of prime importance, other factors such as power source, ground conditions and manoeuvring requirements also have to be considered. Four wheel drive is standard on all JLG diesel scissor lifts, providing impressive gradeability to travel on steep grades.
|
|
ELECTRIC SCISSOR LIFT
Genie® electric scissor lifts are exceptionally mobile, letting you manoeuvre in tight worksites. Plus, they are productive and efficient, allowing maximum workspace for larger loads and more workers. All models have front-wheel drive and most models feature zero inside turning radius for excellent manoeuvrability in tight spaces like congested costruction sites, lifts and narrow aisles.
Low-emission electric scissors deliver a quiet, convenient method for operation in sound-sensitive environments like office buildings, shopping malls, hotels, schools and more.
On-board diagnostics help operators troubleshoot on the fly and make adjustments in the field to maximize uptime. Swing-out battery box and power module trays allow easy access to engine components for convenient service.
Working height from 6.57m to 11.75m
Lift capacity from 227kg to 567kg
|
|
|
JLG’s range of electric scissor lifts cover a multitude of applications – both inside and out. JLG offer three ranges of electric scissor lifts – ES series, LE series and LiftLux™ Electric Series – providing a versatile choice to suit all types of applications. Scissor lifts are used where less outreach but more workspace and lifting capacity are required. They are designed to provide larger platform work areas to walk on and generally allow for heavier loads than boom lifts. Scissor lifts may be manouevred in a manner similar to boom lifts but the platform may be raised only vertically, except for a deck extension that provides some horizontal outreach and additional working area.
|
|
ROUGH TERRAIN SCISSOR LIFT
Genie® rough terrain scissor lifts enhance productivity by providing exceptional traction, speed and gradeability. They are the perfect machines for big outdoor jobs where platform work space is critical.
Genie® RT scissor lifts are able to traverse through uneven or rough terrain environments more efficiently. They are equipped with four-wheel drive and positive traction control for traction when you need it most. They offer up to 50% gradeability when driving on slopes.
Heavy duty fold-down guardrails and a removable rear platform railing allow increased accessibility for loading and unloading the machine in trucks, containers and other situations with limited overhead space.
Working height from 9.92m to 18.15m
Lift capacity from 454kg to 1,134kg
|
|
The Mid-Size Series Rough Terrain Scissor Lifts combine solid and powerful design elements to meet the demands of any job site environment. All models are equipped with Skyjack’s unique axle based 4WD system which features a “Detroit Locker” type rear differential and limited slip front differential for unmatched terrainability.
Working heights for these two models are 33’ (SJ 7127) and 41’ (SJ 7135), while capacities are 1,500 lbs (SJ 7127) and 1,000 lbs (SJ 7135) respectively.
A standard 4.5’ roll out extension deck adds to the already generous platform sizes, giving a combined 75 square feet of platform space. Both models are drivable at full height, and feature 30% gradeability.
Consistent with Skyjack’s robust and reliable design features, the Mid Size Series Rough Terrain Scissor Lifts utilize Skyjack’s standard color coded and numbered wiring system with analog based controls.
|
|
|
|
|
|
The Compact Series DC electric scissor lifts offer Skyjack's renowned design elements in a compact and versatile package. Equipped with variable speed front wheel hydraulic drive, and 90° steering, both models in the Compact Series are capable of maneuvering in the smallest spaces. The SJIII 3215 and SJIII 3219 feature durable steel swing-out trays, providing unrestricted access for easy maintenance and service. Featuring a 3' roll out extension deck, these Compact Series models offer work heights up to 25', and an industry leading 600 lbs capacity, and 25% gradeability.
Consistent with Skyjack's robust yet simple design philosophies, these units are controlled by a durable, easy to service analog based controls, utilizing Skyjack's
standard color coded and numbered wiring system. The user friendly controls are fully proportional for drive and lift functions, ideal for effortless control in the tightest of places. Combining features like these with Skyjack's philosophies, the SJIII 3215 and SJIII 3219 can boast the industry's lowest life cycle costs.
STANDARD FEATURES
- Drivable at full height
- Variable speed, front two wheel hydraulic drive
- 90° steering (zero inside turning radius)
- Dual holding brakes
- Proportional controls for drive & lift functions
- 3' (0.9m) roll out extension deck
- 24V DC power source
- Low voltage battery protection
- Analog control system
- Color coded and numbered wiring system
- 25% gradeability
- Operator horn
- Solid rubber, non-marking tires
- Pothole protection system
- Forklift pockets and tie down/lift lugs
- 110V AC outlet on platform with GFI
- Tilt alarm with drive & lift cut-out
- All motion audible alarm
- Lanyard attachment points
OPTIONS
- Flashing light
- Shop airline to platform
- 800 watt AC inverter
- EE rating package
- Hinged railing system
- Half height spring hinged gate
- Full height spring hinged gate*
|
|
1. Safe electric scissor lifts with high work platform.
2. Scissor structure is more steadily lifting.
3. Self-driving improve work efficiency.
4. Platform can be extended about 1 meter, to augment using area.
5. The platform will stop automatically while lowering at some point, prevent something clamp.
|
|
You have so much to do in your workday, and you need equipment that stays with you all day. The ES Series scissor lifts from JLG have the industry’s best on-the-job performance with double the duty cycles of other electric scissors. This gives you double the operating time on a single charge.
A full range of platform heights from 19 ft (5.79 m) to 40 ft (12.19 m)
Long battery duty cycles for hours of operation in multi-shift conditions
Smooth controls combined with fast lift and drive speeds provide improved productivity for the operator
ES Series designed specifically for rental markets
Typical Applications
Construction, industrial, maintenance, distribution, entertainment and institutional users
Warehousing and distribution centers
Hotel, recreation and educational facilities
|
|
Elevated work platforms are often used for the assembly of large machines, in the car industry, airplane manufacture and generally for any work at variable or adjustable heights.
Elevated work platforms comply with EN 280 norm.
Particularly stable thanks to their design, they give their users the possibility to work at the correct height, safely, for long hours, almost as if they were working on the ground.
|
|
|
Autoquip Vertical Ram Lifts are utilized when a scissors lift is not a option, either due to high axle load requirements, high travel requirements, high load requirements - or some combination of all three. Vertical hydraulic ram lifts are designed to handle the most awkward and heaviest loads and can reach heights where scissors lifts become unstable. Vertical Ram Lifts offer inherent simplicity with the typical configuration having one or two hydraulic rams supporting a rigid platform. Completely customizable, these hydraulic ram lifts have very few moving parts and offer the greatest flexibility as to platform size, travel and capacity. The Vertical Ram Lifts require a pit and usually become permanent installations. Autoquip Hydraulic Ram Lifts are ideal for concentrated, rolling loads of all kinds, and can be used as a loading dock or for in-plant applications.
|
|
The jobsite isn’t always clean and isn’t always easy to get through. With JLG RT Series scissor lifts, you have the power you need to go through mud and ruts. The RT Series has larger platforms with more than 20 ft of deck space and up to 2,250 pounds capacity.
A full range of platform heights from 33 ft (10.06 m) to 43 ft (13.11 m)
Optimal rough terrain performance
Rigid scissor arms provide the operator with the stability of a solid and sturdy platform
Smooth controls combined with fast lift and drive speeds provide improved productivity for the operator
Typical Applications
Construction (commercial buildings and infrastructure)
Mechanical, electrical, utility and painting contractors
Manufacturing and industrial facilities
|
|
SL-3 Scissor Lift
Designed to provide a safe work platform for installation of services in tunnel headings up to twenty feet (six meters) high. The Mine-Mate™SL-3 Scissor Lift is fully equipped as standard for the multi-tasking required in today’s underground trackless mining environment.
|
|
The RDH All Purpose Scissor Lifts have been designed to exceed the most stringent engineering criteria. With RDH’s solid steel arms we are able to offer a level of safety and durability that has yet to be matched.
The RDH 500N, 500R & 600R are built on the RDH carrier which offers a four wheel drive fully articulated power shift vehicle. The units offer excellent maneuverability with superior handling and good visibility from the cab position. They have been designed with the same criteria as our larger series. These Scissor Lifts make mining safe, productive and cost effective. The complete line of RDH Scissor Lifts can be custom built in order to meet individual requirements.
|
|
|
|
|
|
SPECIAL LIFTING TABLE
The special lifting table is set on a vertical electric horn and lift operators in order they can supervise the thermal treatment of parts.
Apart from that operation, the special lifting table is stocked in another place.
Main characteristics of the special platform shown on the photo :
Lifting capacity : 500 daN by 3 operators without any equipment or tool
Platform dimensions :
Outside diameter : 5,400 m
Inside diameter completely free : 3,400 m
Platform with drop steel plate
Basic frame adapted to the round platform / platform for operators
Six feet and 3 supports adapted to the existing supporting areas of the horn
Collapsed height : 1,280 m including 0,680 m for feet
Vertical stroke : 1,750 m
Lifting system by three double superposed and synchronized scissors at 120°C
Main options : galvanization, internal compressed air circuit or breath air or paint or water circuit, ATEX equipment, radio-controls, any adaptation : mechanic, hydraulic, electric and surface treatment.
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Industrial forge, mechanical engineering, cars and all kind of industries mass-producing items. Stacking and un-stacking items to fill in or to empty containers...
|
|
FIXED LIFTING PLATFORM WITH TANDEM SCISSORS
Lifting platform with tandem scissors, equipped with handrails and reinforced PVC skirts, for the leveling of operators in the aeronautic industry.
Main characteristics of the fixed platform shown on the photo :
Lifting capacity : 400 daN
Platform dimensions : 4,000 m x 1,500 m
Collapsed height : 0,210 m
Vertical stroke : 0,790 m
Main options : particular covering (wood floor, carpet,...) input socket, compressed air circuit with rapid connections, light, galvanization...
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Ergonomic leveling of operators on production lines to ease the assembling of parts or of equipment....in all kind of activities and manufacturing.
This particular design, as two standard lifting tables linked together with tandem scissors, allow the lifting of heavy and bulky loads - while being at a low collapsed position.
|
|
P1 SL6000 Features
Heavy-duty scissor mechanism and deck provide a stable elevated mobile work platform.
Four totally enclosed stabilizers with built-in hydraulic safety locks for leveling machine and higher reach.
6 000 lb or 2 720 kg safe lift capacity.
Proven powertrain with integrated torque converter and three gears in forward and reverse.
Four-wheel totally enclosed wet multi-disc brakes with POSI-STOP feature for emergency/parking.
Articulated heavy-duty frames made to withstand the high impact and torsional stress associated with mining application, frames come with a five-year unlimited guarantee. Large high tensile alloy steel pins located in replaceable anchor bushings
|
|
|
|
