| The VIBROSTOP TSZ damper was designed for the isolation of large machinery, with significant weight and unfavourable ratio between the height of the centre of gravity and the base area, without fear of their falling. Loads range from 2000 to 20000 daN. |
|
Precision, height adjustable, vibration damping machine mounts for accurate, efficient and economical machine installation
Typical applications:
Machine tools, rubber and plastics machinery, printing and packaging machinery. |
|
UNISORB® Novibra®¹ Anti-vibration Mounts
The Novibra® product line includes various rubber to metal bonded anti-vibration mounts. Natural rubber is used, generally loaded in a combination of shear and compression to achieve the most effective levels of vibration isolation and to ensure long life for the mounts and machinery mounted on them.
UNISORB® Novibra® Mounts are available in a wide range of shapes and sizes which vary according to the application. Many models are available from stock. |
|
| The line is particularly indicated to solve vibration problems. According to the sectors of use Martin gives the possibility to choose the right solutions among plastic, steel or stainless steel component. Applications: injection presses , machine tools, typographic machines, vibrators a.s.o. |
|
The OSM-Series mount is designed for use on machinery that does not require fastening to the floor and where stringent demands are imposed on effective vibration damping and the reduction of troublesome noise emitted from machinery and equipment.
It has been designed with the aid of FEM analysis, which prevents
fatigue from fast working cycle times and strong lateral forces in heavy machinery.
The reinforced leveling bolt support cup distributes machine loads to
the support points within the mount. The leveling element provides
direct and reliable machine mounting to suit most installation needs.
Vertical as well as horizontal forces are dampened out by
the integral nitrile pad, which also provides chemical resistance
to most fluids.
A tried and tested design with good leveling characteristics
makes the OSM-Series the natural choice for the majority of
machine types used in industry. |
|
A wide assortment with many different variants offers Ganter in Furtwangen (Germany). So you can find in the product range levelling elements made of steel, stainless steel. plastics or combinations like plastic/steel.
Levelling elements with vibration absorption optimise an interesting product-portfolio. |
|
| The infinitely adjustable feet are suitable for structures of all kinds. |
|
STAINLESS STEEL Line/
This line is particularly indicated to all industry, where hygienic rules have to be respected. Applications: pharmaceutical, chemical, nuclear, enological, dairy and food industry in general. |
|
ELESA vibration-damping levelling elements have been designed to damp vibrations, shocks and noise produced by moving bodies or non-balanced vibrating masses of equipment and machines which can cause:
- malfunction and reduction of the machine lifespan and/or of the adjacent ones
- damages at men’s health
- noise.
LW.A are made up of three main elements: zinc-plated steel base with natural rubber disk, zinc-plated steel levelling disk and threaded stem to allow an easy and precise levelling of the machine.
Vibration-damping levelling elements are available in the following diameters: 80 - 120 - 160 and 200 mm. |
|
Range of Applications:
- processing centres
- transfer machines
- industrial robots
- special purpose machines
- plant construction
Characteristics:
- large adjustable range
- exact leveling by using fine thread
- charging from 500 da/N up to 4.000 da/N
- with or without vibration isolation
- for free-standing or srew-on type machine assembly
- cost-efficient assembly method |
|
| The VIBROSTOP TSGE damper is the best choice for isolating disturbing machines that are not to be fixed to the ground, and do not risk toppling over because of the favourable ratio between height of centre of gravity and base area. |
|
Isomounts provide an efficient and economic method of installation of a wide range of machinery and equipment. Machines can be installed and accurately levelled without bolting down or grouting. Machine performance is improved through effective shock and vibration isolation and damping.
Typical applications include:
- Compressors and Pump Sets
- Diecasting machines
- Diesel Generators
- Hydraulic Power Packs
- Injection Moulding Machines
- Packaging Machinery
- Presses: Forging, Hydraulic and Mechanical
- Rubber Machinery
- Testing Machines |
|
Description A swiveling leveling foot for stable positioning on uneven floors
Material Die-cast zinc
Surface Black powder coated (other surfaces on request)
Pack Quantity 10 pieces |
|
Japanese manufacturer, Sugatsune, has a wide range of machine feet and casters.
For more information about this and other similar products, please visit our website or view the PDF catalog files here.
sugatsune.co.jp (Sugatsune Japan)
sugatsune.com (Sugatsune America)
sugatsune.net (Sugatsune America-Industry) |
|
Range of Applications:
- processing centres
- transfer machines
- industrial robots
- special purpose machines
- plant construction
Characteristics:
- large adjustable range
- exact leveling by using fine thread
- charging from 500 da/N up to 4.000 da/N
- with or without vibration isolation
- for free-standing or srew-on type machine assembly
- cost-efficient assembly method |
|
UNISORB® Quantum IM® Injection Molding Mounts :
UNISORB® Quantum IM® Mounts provide optimum leveling and alignment in minutes, without anchoring either the machine or mounts to the floor. Designed especially for injection molding and die casting machines, UNISORB® Quantum IM® Mounts dampen both vertical and horizontal impacts found in reciprocating machines. UNISORB® Quantum IM® Mounts meet applicable OSHA requirements.
The Maximum Adjustment Range :
These mounts are truly a quantum leap in machine mount technology. Every model in the Quantum IM® line provides an overall adjustment range of 1 3/8 inches. This range goes well beyond all of UNISORB's competitors worldwide. In addition, UNISORB's line of Quantum IM® Mounts is available in a wide variety of sizes and configurations, and all share these time tested durability features:
Rugged ductile housing :
Super heavy duty impact plate
Resilient anti-walk isolation pad
High strength steel adjustment bolt
Constant horizontal natural frequency |
|
Description A swiveling leveling foot for stable positioning on uneven floors
Material Fiberglass reinforced nylon
Color Black (other colors on request)
Pack Quantity 10 pieces |
|
These machine mounts may be used in generator sets, power presses, motors, pumps, machine tools, etc...
They guarantee different degrees of stiffness in the three main axes.
Among that serie of mounts there is a range specially designed for marine applications. |
|
Egaña has included some new products in its wide range of machine leveling feet, available in several sizes.
Apart from the standard adjustable machine mounts of HIGH OR LOW PROFILE (In STEEL or STAINLESS) used for all type of machines, there are other types of mounts:
CAM SERIE gives a very good solution for shear and stamping machines and for injection machines.
POLYURETHANE SERIE (In STEEL or STAINLESS) is commonly used for presses and plastic injection machines that work with oils and with corrosive liquids.
(Available with socket in Polyurethane and Rubber (65º).
WEDGE MOUNTS are indicated when perfect levelling is requested. (Big bedplate machinery).
EGAMOUNT serie can be used for the isolation of noise and vibration for generators, tool and production machinery, presses.... They are specially indicated when it is necessary to avoid considerable horizontal movement. Their horizontal stiffness is greater than their vertical stiffness. |
|
Shock & Antivibration machines feet allowing the following performances:
Insulation of the shocks and vibrations
Integrated levelling
Improve machine stability
Anchoring no require
Load by feet 10 to 10.000 kg
Broad range for all the aplications |
|
Fabcel® LeveLers are designed to permit fast, simplified precise leveling of all types of equipment and will compensate for up to a 5° tilt in the mounting surface. Furnished with the patented Fabcel® pad, they control shock, vibration and noise and will not allow equipment to creep or walk.
Model SW and SWB Swivel-type LeveLers compensate up to 10° tilt each side of the centerline in order to adjust for uneven bearing surfaces. The base of the Swivel LeveLer is designed to assure solid support. The Swivel LeveLer is zinc plated and gold iridited to resist rust. Model SWB is furnished with a 2" long adjusting bolt. The Swivel-type LeveLers can be furnished with the patented Fabcel® pad to control shock, vibration and noise and will not allow equipment to creep or walk. |
|
| Machine feet and bases available in many specifications 303, 304 and 316 Grade Stainless Steel, Die Cast Zinc, Zinc Plated - Nuts, Washers and Neoprene Pads also available |
|
SUROSOL®: the solution stability of your machines.
SUROSOL® is a range of adjustable feet and bases for machines, conceived to reduce the vibrations, to compensate for the unevennesses and to remove the disadvantages of the sealing of the machines. SUROSOL® allows an establishment and a setting fast level which support the mobility of your park machine. |
|
Sunnex LL series - Leveling Mounts
Sunnex LL leveling mount are ideal for loads of up to 2000 kg. The LL-Series has a solid base design fitted with an anti-slip pad.
The precision ball and socket design of the swivel connection provides a smooth low friction interface from the equipment to the floor.
Advantages:
Articulated bolt allows inclination up to 10°
With anti-slip rubber protection for stable installation
Made of galvanized steel
Withstands loads up to 2000 kg
Applications:
Assembly Stations
Compressors
Office & Household Machinery
Outside Maintenance Equipment
Small Machines
Woodworking Machines
|
|
