The excellent quality of the raw materials and manufacture, combined with an extremely modern method of formulation, make TOSH inks range one of the most advanced and complete available in the market today.
Single and two-components, realized in 13 different ink formulations, TOSH is able to satisfy every application requirements, capable to give adhesion and specific resistance on every substrates with a wide range of standard shades together with a rapid service of non standard shades on-demand.
All TOSH inks are NT (non-toxic), thus conforming to European Standard EN71.
|
|
The comprehensive tampon printint inks product range from the market leader TAMPOPRINT AG comprises:
- 1- and 2-component inks, UV tampon printing inks
- for "open" / "hermetic" / rotary tampon printing systems
- more than 20 standard ink types in 28 standard ink shades each
- special ink shades according to RAL, PMS, HKS
- in-house ink laboratory for your special ink shades or ink types
- ink samples and samplings
- small quantities
|
|
|
|
|
|
PAD printing inks Type B, P, PG & 434 from ITW Trans Tech have been approved for use in applications that require United States Pharmacopoeia (USP) 30, NF 25, 2007 certification, known as Medical Class VI. This classification is widely used in public quality standards for drugs, medical devices, and dietary supplements to comply with FDA standards for products which may come in physical contact with the human body.
The USP-NF includes a full range of tests, procedures, and industry best practices for all phases of pharmaceutical development and manufacturing. The world-recognized standards are FDA enforceable for pharmaceutical and medical device exports to the United States and used in many other countries.
Commonly used pad printing applications on medical devices include: trocars, catheters, tubing, syringes, surgical instruments, medical fittings, skin staplers, vials, medication dials, dosage dispensers, pill containers, and pipettes.
Compatible substrates suitable for pad printing with Ink Type B, Type P, Type PG, and Type 434 include: treated and untreated polypropylene, acrylic, polycarbonate, polyester, ABS, polystyrene, vinyl, PVC and other plastics. Printing on polyolefins such as polyethylene and polypropylene is possible but requires surface pretreatment. Sample testing is always recommended.
|
|
When decorating audio, as well as electrical and household appliances, high requirements for chemical stress resistance, elevated temperatures, and daily use clearly predominate.
There is every reason for pad printing: Printing of finest details, high resistances, a great variety of shades, metallic effects.
|
|
| ... products without technical information |
| |
... see all the products in the category
Inks
|
Sealed Cup Manual Pad Printer
Specifications:
Sealed cup manual pad printer
100MT
1.Plate area: 100×214mm
2.Dimension: 400 × 220 × 490 mm
3.Net weight: 30 Kg
4.Printing speed: 500pcs/H.
5.Max printing area:70×100mm.
6.Horizental Stroke:100mm
7.Vertical Stroke:60mm
Advantages: 1. Sealed Cup Manus operating .
2. Easy to change plate.
3. Lower price.
4. Coin aluminum structure.
5. Sealed cup is more environmental protection and ink saving.
Machine Fittings:
1.One pad
2.One steel plate
3.One operation manual.
|
|
|
|
|
|
This high productivity machine is designed for a wide variety of printing uses. Rapid change: from open ink to sealed ink cups, printing from 1 to 6 colours. Axis movements controlled by microprocessor. Designed to allow for the addition of further accessories, even at a later date.
Features
- Machine structure in electric-welded steel, enamelled and normalised to avoid deformation and vibration. Oven-enamelled with dual component paints.
- Machine movements and regulation are numerically controlled, using a touch keypad, easy to learn and simple to use. The operations are displayed on a backlighted LCD.
- Keypad in solvent-resistant material.
- Ability to store up to 15 work programs.
- Axis registration by self-instruction and by co-ordinate dimensioning.
- High micrometric precision of plate-holder inktray.
- High micrometric precision of ink cups and doctor blades.
- Electro-pneumatic operation of horizontal and vertical axes.
- Machine in conformity with machinery directives EEC 89/392 and 89/336.
- Indipendent doctor blade wagon
|
|
We are a medium-sized, globally renowned high-tech company from the Stuttgart area, and for almost fifty years have provided a range of decorative and marking technologies offering unparalleled opportunities.
Since the invention of the industrial tampon printing process by owner Wilfried Philipp in 1968, the opportunities in the field of ‘tampon printing’ have been subject to constant development. New materials and the ALFALAS laser system technology in particular have also contributed to this.
The extensive range of standard tampon printing machines includes a wide range of models and options that allow us to tailor the machines and automated systems precisely to the needs of the customer.
The best trained employees, state-of-the-art production facilities and effective organisational structures are just the start of what we have to offer.
The DIN ISO 9001 certification requirements are fulfilled.
|
|
|
|
|
|
It is updated on two colours pad printer with shuttle .overprint is more precision . Coin aluminum machine body ensure running stabilization.
Standards Certificate©U CE ISO9001-2000
Power Supply©U 110/220v 60/50Hz 1PHASE
Colour Painted ©U White colour
Specifications©U LC-PM2-100
1.Max. plate size: 100¡Á100 mm£»
2.Max. worktable area: 125¡Á200mm£»
3.Max. printing area: 85¡Á85mm£»
4.Max. printing speed: 1000pcs/hr£»
5.Printable colour :2;
6.Stroke of table shuttle: 125mm.
LC-PM2-150
1.Max. plate size: 100¡Á150mm£»
2.Max. worktable area: 125¡Á200mm£»
3.Max. printing area: 85¡Á130mm£»
4.Max. printing speed: 900pcs/hr£»
5.Printable colors:2;
7. Stroke of table shuttle: 125mm.
Advantages©U
1.Two-colour pad printer with shuttle ;
2.Each function controlled by microprocessor ;
3.Four-digit auto counter built-in;
4.Coin aluminium structure ensure solidity and durablity;
5.Ink roller flooding for easy install/uninstall ;
6.Independent pad up/down stroke and speed asjustment;
7.Auto balanced doctor blade available for efficient ink scraping;
8.Printing speed asjustable to fullfil various requirements;
9."Inking twice, printing once" for better ink covering;
10.Able to sweep forward/backward without lowering pad to avoid ink drying at intervals;
11.One or two colours printable;
12.Two-colour ink tray base adjustable separately for overprint adjustment;
13.Drying with auto air blowing for easy colour registration;
Machine Fittings©U 1. Two plates,
2. Two pads
3. Two blades
4. A tool box.
Package List©U LC-PM2-100
1. Package dimension:850¡Á580¡Á1460mm
2. Gross weight:140KG
|
|
|
|
|
|
Sealcup 90
Single Color, Sealed Ink Cup Pad Printer
The Trans Tech SEALCUP 90 is an all-mechanical, cam-operated bench model pad printing machine with an hermetically sealed ink cup. The design and operating features make this an ideal printer for manual, semi-automatic or fully automated single-color applications. The simple cam mechanism, driven by an infinitely variable AC drive, provides for smooth and highly reliable operation which allow for easy integration to automation. High-quality prints and low ink maintenance are achieved with the hermetically sealed ink cup system, including ease of operation and quick changeovers.
Main Features and Benefits:
Electro-mechanical, cam-operated drive with infinitely variable AC drive, provides the most reliable and smooth, maintenance-free operation.
Sealed ink cup system provides continuous operation, high-quality print and low ink maintenance in uncontrolled work environments.
Easy setup and quick changeovers with magnetically held pad and quick cup release system.
All operating controls on front panel with LCD operating mode display allows for convenient and simple operation for setup and continuous operation.
Clear safety guard with interlock to meet with safety regulations.
Hinged machine cover for easy maintenance.
X-Y-Z-R adjustable worktable provides fast and accurate part setup.
Smooth and vibration-free operation at high speed is provided by aluminum-cast main machine body.
Easy and cost-effective automation interfacing is achieved with latest electrical controls technology, including programmable controller and frequency inverter.
|
|
