These two EZK models understand themselves as pure Kommissionierfahrzeuge. Whether in the 2-Mast or shears stroke version, the Kommissionieren from profiles to 8 m length or disk commodity from 600 mm to 2100 mm of depth is with these stackers possible. The commodity can be taken thereby problem-free reciprocally under way out of the shelf. The 2-Mast-Modell convinced by the particularly low platform height, this lies with the shears stroke version more highly. In response the shears stroke version possesses the preference/advantage of a smaller overall length. Optionally a shifter is available, in order to facilitate the withdrawal with a separate stacker of the finished customer Kommision for both models. Also the EZK models fulfill the HUBTEX standard of durable hubmasten, ergonomic jobs, three-phase alternating current technology and HUBTEX information terminal with color diagram display.
|
|
|
|
|
|
Single mast climbing work platform
As a leader in the production of mast climbing platforms, today SAFI has a range of products which covers from the smallest single mast climbing work platform for small restoration work with the “JOLLY JUNIOR” to large twin mast climbing work platforms for heavier constructions work like the “VISION 4000”, for working surfaces over 100m high and 35m long.
The strong point of all the models is the modular composition, both height-wise and lengthwise, which means enormous saving on construction site costs.
There are many versions for all types of machines : single mast, twin mast , wheel mounted for road or construction site use and special versions.
All models had the ministerial authorizations before the machine directive of 1997 and several international certificates such as the German TUV GS , the French ATS, the Italian OCE.
After the introduction of new regulations in the European Community all equipments were conformed to the safety standards and obtained the European certification from Italian and International boards with the related CE mark.
|
|
Mast climbing work platform are a handy and efficient alternative to traditional scaffoldings.
Suitable for:
- Facade maintenance and repair
- Bricklaying
- Facade insulation
- Window installation
- Facade refurbishment, plastering and painting
- Ship building and restoration
- Roof restoration
- Industrial plants
- Demolitions
|
|
|
|
|
|
Twin mast climbing work platforms
As leader in the production of mast climbing platforms, today SAFI has a range of products which covers from the smallest single mast climbing work platform for small restoration work with the "JOLLY JUNIOR" to large twin mast climbing work platforms for heavier constructions work like the "VISION 4000", for working surfaces over 100m high and 35m long.
The strong point of all the models is the modular composition, both height-wise and lengthwise, which means enormous saving on construction site costs.
There are many versions for all types of machines : single mast, twin mast , wheel mounted for road or construction site use and special versions.
All models had the ministerial authorizations before the machine directive of 1997 and several international certificates such as the German TUV GS , the French ATS, the Italian OCE.
After the introduction of new regulations in the European Community all equipments were conformed to the safety standards and obtained the European certification from Italian and International boards with the related CE mark.
|
|
GOLDLIFT 14.70 AERIAL PLATFORM
This is the most famous platform, the most sold and successful.
The thousands of units sold in the last few years show that it is a completely reliable and safe machine.
The traditional hydraulic controls are now totally managed by the PLC.
Reduced machine dimensions: width 78 cm height 2 m
It is equipped with a diesel/petrol engine and with an electric motor. The undercarriage can be hydraulically extended. The patented load cell allows a load from 120 to 200 kg to be selected.
Provided with power outlet and air intake on the cage.
Double travel speed available on request.
|
|
|
JLG has been designing and manufacturing aerial work platforms for almost 40 years. We pride ourselves on our customer-driven technical knowledge and innovation, resulting in a superior range of products that are designed from the inside out to keep pace with a changing and demanding world. We also place a great deal of importance on the aesthetics of the machine being sensitive to the surroundings. Ergonomic design is important – helping the user to operate the machine with ease and confidence – and being in complete control. It is also a product that is durable and reliable. Our quality is second to none and our guarantee is a full one-year warranty with a further five-year structural warranty.
|
|
industrial application - lift applications
This scissors lift platform - heavy model is use in the automotive industry.
Application : Sledge change system in a surface treatment plant.
Location : Automotive Industry
Load ( kg ) : 3000
Speed ( mm / s ) : 300
Stroke : ( mm ) 1800
Rate ( / day ) 900
Product in use : HDLift 90 D
Description : Lift Platform, heavy model
lenght : 4000 mm
width : 1400 mm
|
|
This scissors lift platform is used in the market of electrical industry. The Serapid rigid chain standard product in used is the linklift 100.
Application : Electric transformer manufacturing
Location : Energy Industry
Load ( kg ) : 7000
Speed ( mm / s ) : 42
Stroke : ( mm ) 2750
Product in use : LinkLift 100
|
|
New Tracked Aerial Platform LightLift 23.12
Heigth 23 metres
Outreach 12 metres
Weight: just 3000 kg!
Max. Capacity: 200 kg !
Automatic stabilization
Wide display on the new remote controll
Two travel speeds
Reduced maintenance thanks to the pins free of greasing
Troubleshooting over the web to offer all users real-time support
|
|
Hitachi has the #1 variety of crawler-type aerial platforms in Japan, and we offer two different types for overseas sales. This kind of variety means that we can deal with any customer requirements. By using crawlers instead of tires, our machines can move on to unpaved ground, and there is no need to use outriggers during operation. We put safety first, in order to ensure the smoothest possible construction for your workers.
Hitachi's aerial platforms use hydraulics instead of electricity for basic operation. This makes for easy and smooth operation. The design for these machines is based on Hitachi excavators. By working off of a machine that is already known for its performance and efficiency, we can assure our customers of the reliability of our aerial platforms.
|
|
Skyjack’s Full-Size Series Rough Terrain Scissor Lifts deliver huge platforms, soaring work heights and heavy duty capacities— all in one package! A fuel efficient GM 1.6L Vortec dual fuel engine powers Skyjack’s robust axle based 4WD system resulting in 30% gradeability.
The SJ 9250 features an expansive platform, up to 24’ in length, when optional 5’ powered extension decks are added to the front and back of unit. With a working height of 56’, and standard independant/auto leveling outriggers, the SJ 9250 can meet the challege of any
job site.
As with every Skyjack model, these units use an analog based control system, featuring Skyjack’s standard color coded and numbered wiring, for ease of troubleshooting.
|
|
|
|
|
|
DuoRam - Hydr. Single-Ram-Lifts
The original version of all lifts, invented in 1924, is the single-ram underfloor lift, which is still of great importance in modern workshops. In certain areas it is the only one to provide ideal working conditions.
To mention just a few of them, e.g the washing bay, the pre-paint area and the numerous repair works that require the vehicle to be freely accessible from all sides.
The new developed DuoRam combines all advantages of a single-ram lift and of a two-ram lift. Two hydraulic cylinders - which building two independing units - grant that the lifted vehicled is safe lifted even in case of failure in one hydraulic circuit. Optimised arrangement of two compact combined guide bars generate a torsion and bending rigidity which is unknow until now.
This innovative lift accomplishes the DIN en 1493 (for vehicles lifts) through its redundant safety system - because safety comes first!
Different support pieces ensure the specific use of this lift, which is simple, yet solid and easy to service - made in JAB quality, it's an investment for decades
|
|
Lifting systems - Startseite
J.A. Becker & Söhne is the eldest lift manufacturer Europe. Since more than 70 year we are specialized in manufacturing hydraulic inground lifting systems.
Our main focus is set on realisation of customer specified workshop solutions and lifting systems, which are suitable for continous application in the automobil production.
Our comprehensive product range includes car and commercial vehicle lifts, as well as specialised lifts for various applications including industrial trucks, special purpose vehicles and rail.
Based on our high construction and manufacturing quality, our lifting systems are used at leading automobile manufacturers all over the world.
For public transportation services we offer special lifting unit. Because of our excellent know-how we have realised several really special projects for lifting buses or railway vehicles.
As special feature, all lifts can be delivered in explosion proofed version!
|
|
When lifting workers high up on platforms, you first and foremost need to keep safety in mind. Hitachi's aerial platforms offer variety and stability in our machines to make sure workers are in safe hands.
|
|
|
The PA 20 T lifting platform offers simplest operation and handling with maximum reliability. It facilitates rapid access to exposed and difficult-to-reach working positions, while offering highest working convenience and maximum stability and safety.
|
|
High travel material lifts provide an economical, dependable, and versatile method of raising loads to elevations up to 12 feet for standard scissors tables, up to 20 feet for special scissor lift designs, and up to 100 feet for Vertical Reciprocating Conveyors, or VRC Material Lifts. These high travel material lifts can be easily customized to meet ant specific platform, capacity, and foot print requirement, and meet the industry safety requirements.
Autoquip offers the broadest line of high travel lifts in the industry.
|
|
V-25-AFSMC Lift-A-Lift® Work Platform Vertical Travel Maintenance Specifications
Capacity: 20,000# G.V.W.
Width Platform 12'-0"
Length Platform 12'-0"
Entry Opening 50"
Platform Height min. 27"
Platform Height max. 93"
Variable Height Stairway
Motor 5 Horsepower
Power: 230/460/3/60
Hydraulic Lift
Auto Safety Locks
Auto Self Leveling
Hinge Entry Gates (Aluminum)
Lockable Control Pane
Shipped Semi-Assembled
Factory Tested
|
|
Tilt-Or-Lift's Newest Four-Post Maintenance Lift
The new V-30-ALRS Lift-A-Lift® was designed for use by warehouse maintenance departments to service forklifts, reach trucks, stock-pickers, pallet trucks, sweepers, scrubbers and personnel carriers.
Capacity: 30,000# G.V.W.
Approach ramp: 12' long
Runway length: 16'
Runway width: 18"
Entry width: 76"
Hydraulic width adjustment: 56" to 76"
Maximum runway height: 71"
Power: 230/460/3/60
Shipping weight: 8,900#
|
|
Elevated work platforms are often used for the assembly of large machines, in the car industry, airplane manufacture and generally for any work at variable or adjustable heights.
Elevated work platforms comply with EN 280 norm.
Particularly stable thanks to their design, they give their users the possibility to work at the correct height, safely, for long hours, almost as if they were working on the ground.
|
|
|
Autoquip Vertical Ram Lifts are utilized when a scissors lift is not a option, either due to high axle load requirements, high travel requirements, high load requirements - or some combination of all three. Vertical hydraulic ram lifts are designed to handle the most awkward and heaviest loads and can reach heights where scissors lifts become unstable. Vertical Ram Lifts offer inherent simplicity with the typical configuration having one or two hydraulic rams supporting a rigid platform. Completely customizable, these hydraulic ram lifts have very few moving parts and offer the greatest flexibility as to platform size, travel and capacity. The Vertical Ram Lifts require a pit and usually become permanent installations. Autoquip Hydraulic Ram Lifts are ideal for concentrated, rolling loads of all kinds, and can be used as a loading dock or for in-plant applications.
|
|
GIA Utility/Service Truck. Three models are manufactured today i.e. GIA 111 and GIA 211 which is articulated trucks and GIA TT 24 which is a rigid truck. All three models are 4-wheel driven in order to be able to operate in steep inclinations.
The models can be equipped with e.g. boom and basket, scissors platform for ANFO charging, scaling, different kinds of installations and service works. The trucks can also be used as e.g. small dump truck or shotcreting rig. A combination of several equipments on cassettes makes one truck useful in many different applications.
The main feature with GIA Utility/Service Truck is:
• High productivity
• High safety
• Low investment and service cost
• Well known components
|
|
Scissors lifter
▪ Storage at outside is available
▪ ENTL series are liftable at one point.
Type : wheel, crawler
Max. Ground Clearance : 4.0 - 9.9 m
Max. Lifting Weight : 250 kg
Weight : 550 - 2580 kg
|
|
|
|
|
|
CAR-LIFT
Car-lift is used for the vertical and horizontal transfer of cars - without driver - between several levels of storage or exhibition in a car agency. The driver is only allowed to drive the car on and out the platform.
Car-lift must be equipped with securities in conformity with law or must be embedded in built concrete shafts or metallic cage with plain walls and doors equipped with electro-mechanical interlocks.
Main characteristics of the car-lift shown on the photo :
Lifting capacity : 2000 daN
Platform dimensions : 5,000 m x 2,500 m equipped with safety handrails
Collapsed height : 0,700 m
Vertical stroke : 3,000 m
Particularity of this configuration : The car-lift includes an automatic safety locking device in its high position. It maintains the position of the platform and secure the transfer of cars.(......)
Main options : galvanization, all optional safety equipment, transport facilities, set up and commissioning, maintenance contract....
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Vertical transfer of any kind of vehicles : industrial, for roads, army,... inside or outside buildings, parking, museum, exhibition room....
|
|
|
|
|
|
SPECIAL LIFTING TABLE
The special lifting table is set on a vertical electric horn and lift operators in order they can supervise the thermal treatment of parts.
Apart from that operation, the special lifting table is stocked in another place.
Main characteristics of the special platform shown on the photo :
Lifting capacity : 500 daN by 3 operators without any equipment or tool
Platform dimensions :
Outside diameter : 5,400 m
Inside diameter completely free : 3,400 m
Platform with drop steel plate
Basic frame adapted to the round platform / platform for operators
Six feet and 3 supports adapted to the existing supporting areas of the horn
Collapsed height : 1,280 m including 0,680 m for feet
Vertical stroke : 1,750 m
Lifting system by three double superposed and synchronized scissors at 120°C
Main options : galvanization, internal compressed air circuit or breath air or paint or water circuit, ATEX equipment, radio-controls, any adaptation : mechanic, hydraulic, electric and surface treatment.
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Industrial forge, mechanical engineering, cars and all kind of industries mass-producing items. Stacking and un-stacking items to fill in or to empty containers...
|
|
FIXED LIFTING PLATFORM WITH TANDEM SCISSORS
Lifting platform with tandem scissors, equipped with handrails and reinforced PVC skirts, for the leveling of operators in the aeronautic industry.
Main characteristics of the fixed platform shown on the photo :
Lifting capacity : 400 daN
Platform dimensions : 4,000 m x 1,500 m
Collapsed height : 0,210 m
Vertical stroke : 0,790 m
Main options : particular covering (wood floor, carpet,...) input socket, compressed air circuit with rapid connections, light, galvanization...
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Ergonomic leveling of operators on production lines to ease the assembling of parts or of equipment....in all kind of activities and manufacturing.
This particular design, as two standard lifting tables linked together with tandem scissors, allow the lifting of heavy and bulky loads - while being at a low collapsed position.
|
|
Service platforms
AMV Service Platforms are supplied in many configurations. The most popular version is the AMV 10,5. This unit is built on a lorry chassis, it has a maximum working height of the platform floor of 10,5 m. and a lifting capacity of 1500 kg. over the whole working range. It is equipped with four hydraulic support legs. The standard version has a p.t.o. driven hydraulic pump. An electric powerpack can be supplied as an option. Other options are diesel driven compressors and generators for tool operation. All operations are radio operated.
|
|
|
|
|
|
Utilift scissors lifts on our famous mining carrier are designed for lifting and installations in mining and low-profile tunnelling. Utilifts are suitable for roof reinforcement work, charging explosives, hanging cables and installing pipes, ventilation equipment, etc. Typical standard options include a side-shift platform, platform tilt, crane, pipe changing equipment, air compressors, an electric-driven power pack for platform hydraulics, ANFO charging kits and helper platforms. The vehicle’s driving ergonomics can be enhanced with an optional, fully enclosed, high-comfort operator’s cab.
Himecs are the product of long-term collaboration between Normet engineers and global tunnelling customers and experts. This has generated a holistic understanding of customers’ lifting and access equipment needs in both hard and soft rock environments. The wide range of Himecs is ideal for medium to heavy-duty load lifting and work coverage in practically any tunnel profile. With a large variety of platform configurations and standard options, they can be perfectly customized for specific lifting applications. Our new platform load sensing system and other built-in man-lifting safety features comply with the latest safety rules and regulations. Himecs are also CE-approved and feature the famous Normet mining carrier.
|
|
LIFTING TABLE FOR AIRCRAFT REFUELING VEHICLES
For the leveling of operators and equipment. The lifting table is embarked on an aircraft refueling vehicle.
Main characteristics of the lifting table shown on the photo :
Lifting capacity : 450 daN
Platform dimensions : 2,100 m x 1,350 m
Collapsed height : 0,410 m
Vertical stroke : 2,700 m
PARTICULARITIES : floor, handrails, hydraulic power unit, electric equipment and other specific components shown on the photo are supplied by the aircraft refueling vehicle manufacturer.
Main options : metallization with or without final coating, hot deep galvanization without final coating.
FOR ANY SPECIFIC REQUEST, CONSULT US.
Fields of application :
Equipment for vehicles, trailers or others. Also vehicles on runway as for refueling, maintenance, control,... for civil and military planes.
|
|
Haulotte, N° 1 in Europe and one of the worldwide leading manufacturers
The HAULOTTE articulating booms offer :
- from 12 to 41 m working height
- an important outreach (up to 21m)
- a maximum platform capacity (up to 250 kg)
|
|
The HAULOTTE diesel scissor lifts offer :
- from 8 to 18 m working heights
- an important working area (platform size up to 6 m x 1.80m)
- a maximum platform capacity (up to 900 kg)
- a remarkable driveability (4 x 4)
|
|
|
|
