Ideal for applications where space is at a premium.No mechanical connection to the piston. The fully enclosed actuator body prevents contaminants from entering. Air or oil actuated to 100 PSIG. Operation temperature range of 0°F to 170°F. Recommended for magnetically coupled actuator applications requiring end-of-stroke adjustment or shock absorbers.
|
|
Ultran Rodless Slides
The Bimba Ultran rodless slide has two types, UGS-Ultran Slide, Gold coupling strength and USS-Ultran Slide, Silver coupling strength.
Bore sizes are 5/16", 7/16", 9/16", 3/4", 7/8", 1-1/16", 1-1/4", 1-1/2", and 2".
Options include stroke adjustment (both ends or one end), bumpers (both ends or one end), dowel pin holes for Transition Plates, switch track, and alternate ports (both ends or one end).
Accessories include shock absorbers, stroke adjustments, and stop collars.
Improper mounting of the Ultran slide could result in binding and/or excess breakaway. As a rule of thumb, the end blocks should be mounted flat with no more than 0.30 ° of differential misalignment end-to-end (including both end blocks).
|
|
|
Pre-engineered, pre-packaged and ready to install. Load bearing design incorporates precision linear bearings for long life, high load capacity and low friction. One-piece extruded tube housing supports bearing rods to eliminate rod deflection and increase torsional stability. Rigid, torque-resistant, low-profile slide. Loads to 200lbs.
|
|
Linear Thrusters Pneu-Moment
For smooth, guided motion. A durable housing with guide shafts keeps our Linear Thruster from rotating and allows it to carry higher loads. Choose from two different models. A choice of stroke lengths and a wide variety of catalog options make the Bimba Linear Thrusters easy to use and ready to order.
The Benefits of the Linear Thrusters Pneu-Moment Include:
Bimba stainless steel body air cylinders for long, reliable life
Optional magnetic piston for use with Hall Effect or Magnetic Reed Switches
Optional adjustable cushions for smooth deceleration of load at end of stroke
Optional internal or external bumpers to absorb shock or adjust stroke
Easily accessible ports
|
|
|
High load weight vs extension. Five bore sizes from 3/4" (20mm) to 2" (50mm). Stroke lengths up to 12" (305mm), Base or side mount. Linear ball or composite bearings. Options include switches, shock absorbers, stop collars and bumpers.
|
|
|
|
|
|
Custom Thrusters
With over 30 years experience in the automation industry, we at Ultramation understand the challenges faced by today's engineers and we recognize that a standard "off the shelf" unit does not always meet the need. Our specials range from simple modifications of standard units to complete customized solutions. We are versed in utilizing various materials and finishes in order to accommodate specific design and operating environment demands. We also offer both 2D and 3D design capability and our service and quality is unsurpassed.
Early in the design phase, we work closely with the customer to thoroughly understand the requirements and expectations. Once the design is finalized, documentation is provided for both design confirmation and future traceability. Customers can rest assured that their customized design will be available in our document control system for years to come.
Our design and fabrication experience enables us to provide competitively priced custom solutions and fast delivery. Quantities can range from 'one-of' designs to high volume production. We welcome the opportunity to quote these special applications because we recognize that today's special might well be tomorrow's standard.
|
|
The Two Shaft Linear Thrusters offer a compact design while offering maximum design flexibility. They feature two precision guide shafts that provide non-rotational linear guidance and high load capacity. Replaceable linear ball bearings are standard and provide long life, high load capacity and low-friction service. Optional composite bushings and chrome plated stainless steel guide shafts provide a solution for more challenging environments. A stainless steel option is offered for wash down applications.
The black anodized precision machined housings are designed for replaceable stainless steel or aluminum body nose mounted cylinders. Cylinder options range from magnetic pistons to dry service. Other options include position sensing, counterbored or tapped short or long tooling plates, auxiliary mounting plates, and external bumpers or hydraulic shock absorbers.
|
|
Spring Engaged, Rod Lock, For ISO Pneumatic Cylinders
Model RLSS 040-016-S-A
Rod Size: 16 mm
Holding Force: 890 N
Model RLSS 125-032-S-N
Rod Size: 32 mm
Holding Force: 8560 N
|
|
PClamp clamps and brakes rod loads safely amd quickly. It can be adapted to standard systems such as pneumatic cylinders from leading manufactures (e.g. SMC, Festo= or to individual solutions. Rotatory clamping can also be achieved with PClamp. Certified systems from Employer's Liability Insurance Association can be realised.
Area of application:
Linear rails and guide ways
Clamping of linear axis
Swivel tables
Rotary tables
Spindles, feeders
Rod, piston, spindle clamping
Elevating devices
Hydraulic presses
Hydraulic lifts and elevating tables
Safety catches
Blocking systems
High-lifting devices
|
|
Nexen's RBR-series rail brakes are ideal for clamping and power-off holding applications. The unique piston design allows high clamping forces and low release pressures.
The RBR is engineered for dependable performance, easy set up and low maintenance.
|
|
Active without pressure:
The Clamping and Braking Element including spring-loaded energy storage MB
The MB series is based on a dual-effective wedge slide gear with spring-loaded energy storage for clamping and braking without pressure.
As a specific feature it has three pistons connected in a line.
This arrangement allows use of a stronger spring at 4.5 bar than the BW series does. The stronger spring-loaded storage permits holding forces up to 3,800 N.
The MB series is designed for braking on linear guides.
Because of the material combination of the linear guide/contact section,the linear guide won't be damaged by the contact section.
|
|
|
|
|
|
Active without pressure - compact and powerful:
The Clamping and Braking Element with spring-loaded energy storage UB.
The UB series combines the technology of our BW, TK and MB series. The rigid housing and central position of the wedge slide gear achieve very high supporting forces. The mounting hole template enables the BW, TK and MB series to be substituted. The UB series is based on a dual-effective wedge slide gear with spring-loaded energy storage for clamping and braking without pressure.
This arrangement of three pistons connected in a line allows use of a stronger spring at 5.5bar.
The stronger spring-loaded storage permits holding forces up to 9,000 N. Positive fit contact sections mounted within a strong casing guarantee high axial and horizontal rigidity.
The UB series is designed for braking on linear guides. Because of the material combination of the linear guide/contact section, the linear guide won't be damaged by the contact section.
In order to exclude damage from contamination with chips (chips between contact section and linear guide), the elements can be fitted with original seals (seal kit) from the respective linear guide manufacturer and longitudinal seals as accessories.
When used in harsh work environments or with cooling liquid, the seal kit should be used as well.
|
|
Active without pressure – flat design:
The Clamping Element for torque take-up with spring-loaded energy storage TP
The TP series is a pneumatic clamping element for torque motors or for rotational axes.
It works with a newly developed spring-loaded energy storage system.
Torque take-up occurs inside the TP which excludes wear on the driven shaft.
TP achieves high holding torques at a pneumatic opening pressure of >4 bar.
Due to high rigidity, positioning accuracy is exact in use.
The zero maintenance TP is suitable for shaft diameters of
Ø50 to Ø320 mm.
It is characterised by easy assembly and a flat design.
|
|
The clamping elements react in the shortest possible response time by the patented pneumatic pre-loading of the system of the spring plates in the diaphragm.
These safety systems are permanently operational for the maximum machine protection.
|
|
PClamp clamps and brakes rod loads safely amd quickly. It can be adapted to standard systems such as pneumatic cylinders from leading manufactures (e.g. SMC, Festo= or to individual solutions. Rotatory clamping can also be achieved with PClamp. Certified systems from Employer's Liability Insurance Association can be realised.
Area of application:
Linear rails and guide ways
Clamping of linear axis
Swivel tables
Rotary tables
Spindles, feeders
Rod, piston, spindle clamping
Elevating devices
Hydraulic presses
Hydraulic lifts and elevating tables
Safety catches
Blocking systems
High-lifting devices
|
|
Nexen's RBR-series rail brakes are ideal for clamping and power-off holding applications. The unique piston design allows high clamping forces and low release pressures.
The RBR is engineered for dependable performance, easy set up and low maintenance.
|
|
Active without pressure:
The Clamping and Braking Element including spring-loaded energy storage MB
The MB series is based on a dual-effective wedge slide gear with spring-loaded energy storage for clamping and braking without pressure.
As a specific feature it has three pistons connected in a line.
This arrangement allows use of a stronger spring at 4.5 bar than the BW series does. The stronger spring-loaded storage permits holding forces up to 3,800 N.
The MB series is designed for braking on linear guides.
Because of the material combination of the linear guide/contact section,the linear guide won't be damaged by the contact section.
|
|
|
|
|
|
Active without pressure - compact and powerful:
The Clamping and Braking Element with spring-loaded energy storage UB.
The UB series combines the technology of our BW, TK and MB series. The rigid housing and central position of the wedge slide gear achieve very high supporting forces. The mounting hole template enables the BW, TK and MB series to be substituted. The UB series is based on a dual-effective wedge slide gear with spring-loaded energy storage for clamping and braking without pressure.
This arrangement of three pistons connected in a line allows use of a stronger spring at 5.5bar.
The stronger spring-loaded storage permits holding forces up to 9,000 N. Positive fit contact sections mounted within a strong casing guarantee high axial and horizontal rigidity.
The UB series is designed for braking on linear guides. Because of the material combination of the linear guide/contact section, the linear guide won't be damaged by the contact section.
In order to exclude damage from contamination with chips (chips between contact section and linear guide), the elements can be fitted with original seals (seal kit) from the respective linear guide manufacturer and longitudinal seals as accessories.
When used in harsh work environments or with cooling liquid, the seal kit should be used as well.
|
|
Active without pressure – flat design:
The Clamping Element for torque take-up with spring-loaded energy storage TP
The TP series is a pneumatic clamping element for torque motors or for rotational axes.
It works with a newly developed spring-loaded energy storage system.
Torque take-up occurs inside the TP which excludes wear on the driven shaft.
TP achieves high holding torques at a pneumatic opening pressure of >4 bar.
Due to high rigidity, positioning accuracy is exact in use.
The zero maintenance TP is suitable for shaft diameters of
Ø50 to Ø320 mm.
It is characterised by easy assembly and a flat design.
|
|
The clamping elements react in the shortest possible response time by the patented pneumatic pre-loading of the system of the spring plates in the diaphragm.
These safety systems are permanently operational for the maximum machine protection.
|
|
Slide Valve (Pictured)
Slide Valve and Lock-Out Slide Valves
In the open position, slide valves allow air to flow through to downstream equipment in the open position. When in closed position, the valve shuts off the air from the compressor. Air trapped on the load side is then bled off into the atmosphere, preventing equipment from unexpectedly cycling even though the line is "shut off".
The lockout slide valves can be locked in the close position. This is an especially important feature when equipment or machinery is being worked on because it avoids accidental start up, which can cause injury to personnel. The lockout slide valve can accomodate standard lock shank sizes up to .145" (sold separately).
Other types of Valves that Coilhose Pneumatics offers:
Ball Valves
Safety Excess Flow Check Valve
|
|
|
|
