Blind stapling without clinching anvils, with silencer.
The operator has one hand free to shape the carton.
Empty cartons can be bottom-stapled. Staple from inside to outside.
TOP staples will be automatically clinched within the corrugated section of the under board without clinching anvils.
No damage to the contents, no additional stitching holes next to the staples.
Air pressure: 4 - 6 bars, Weight 2.9 kg,
Loading capacity 120 staples
Staples TOP SP 11 for single corrugated cardboard
Staples TOP SP 18 for double corrugated cardboard
|
|
MEROLOCK 3 soundproofed stapler with 1000 coiled staples is used for closing filled folding boxes made from corrugated cardboard.
Clinching anvils return automatically.
Adjustable penetration depth to match the type of cardboard.
Air pressure 4 - 6 bars. Weight 2.76 kg.
Loading capacity 1 coil CR 1/34 = 1000 staples
|
|
For closing filled folding boxes made of strong double
and triple corrugated cardboard.
King size staples are bent onto anvils. Stapler can be adjusted to different penetration depths.
Weight: 8 kg; dimensions: 34.5 x 46.5 x 19 cm
Air pressure: 4 - 7 bars. Loading capacity 100 staples
JUMBO 32 suitable for staples with 32 mm leg length
JUMBO 38 suitable for staples with 38 mm leg length.
|
|
Tabletop stapler TH 210 for stapling paper packs or thin paste-board (cardboard headers, blister packs) onto polythene bags.
Air pressure 4 - 6 bars. weight 5.2 kg.
Measurements 285 x 270 x 220.
Basic device TH 210/2 equipped with 2 staplers.
Automatic staple triggering at the touch of a contact.
Throat depth 100 mm. With manometer, water separator.
For closed and open clinch.
For staples 66/6 + 66/8 with 12,8 mm crown size,
6 + 8 mm leg length
|
|
For staples type B from 16 - 19 mm(5/8" - 3/4")
Carton stapler.
TECHNICAL DETAILS
Weight:
2,5 kg (4.738 lb.)
|
|
2P-H30SD - Pneumatic Stapler
For staples type H from 12 - 30 mm (1/2 - 1-3/16").
Furniture backs, cabinets, framing, wooden cases
TECHNICAL DETAILS
-safety device
-bottom load magazine
-exhaust silencer
-no recoil
Weight:
1,25 kg (2.756 lb.)
Operating pressure:
approx. 4-7 bar
(57 - 100 psi.)
Air requirement:
approx. 0,7 l/staple
(0.198 gal./staple)
|
|
FinishPro 10 - 23 Gauge Pins
This lightweight Micro Pinner is the perfect tool for all of your intricate finish and trim remodeling projects. The micro pins fasten the smallest of decorative trim securely and leave a nearly invisible hole - no splitting or puttying. The FinishPro 10 drives 1/2"-1" 23 gauge micro pins.
Features:
Rear exhaust - Directs oil and dust away
Smooth metal cap - For durability and protection of work materials
Easy fastener length adjustment - Quickly adjusts to desired fastener length
Easy-open latch - For quick and comfortable loading
Hardened alloy steel driver - For durability
Soft grip handle - Extra comfort and control
Extra power - For use in hard woods
Low load alert - Visible fastener load with reload indicator
One-year warranty
Includes case, fittings, repair tools, oil and fastener rebate
|
|
50mm(2") Stapler
- Well balanced and lightweight-only 4.4 lbs.
- Rapid driving and quick response with cylinder valve firing mechanism
- Quick clear jam release
- Depth adjustment
- Rubber grip for comfortable handling
- A sequential trip mechanism kit (single shot parts) is available as an option (Code No. 876762)
|
|
