| Headquartered in USA, Cherokee International is a largely experienced international company manufacturing telecommunication power sources in Belgium. As one of the greatest players of the world in its own field of activity, it gives direction to the technology. |
|
The modular AMKASYN servo inverter series KE/ KW consists of a compact supply module (KE) and different compact inverter modules (KW) in various power ranges.
Features:
- Power range up to 120 kVA
- Modular design
- Nearly limitless module arrangement
- Number of servo axes at a supply module is limited only by total power
- Cooling with coldplate technology
- Regenerative feedback optional
- Variable encoder technology standard encoder inputs for resolver, square or sine-wave encoder, EnDat, Hiperface pulse forwarding
- Multifunctional networking via powerful ACC bus
- PLC functionality optional
- Fieldbuses:
- SERCOS
- Profibus DP
- CAN
- EtherCAT
The most important advantages at a glance:
- Reduction of control cabinet space through compact devices
- Cost savings through possible integration of control cabinet in machine
- Cost-optimized solutions through modular system design
- Complex networked machines possible through precise synchronization
- Simple implementation of motion control functions through integrated PLC
- Integrated safety functions to category 4 |
|
Green TEC Laser:
StockerYale's Lasiris™ Green TEC structured light laser offers a thermoelectric system and fan that maintains a constant laser diode temperature, resulting in excellent wavelength, power, and pointing stabilities. The new, improved design makes focusing even easier with the focus adjusting screw located directly on the body of the laser. In addition, the Green TEC boasts one of the longest green laser lifetimes, and is offered with a 1-year warranty.
A green beam can provide better contrast on red hot metal or wood. Another advantage is that a green beam is more visible to the human eye than red, thereby making the relative eye response to the green much higher. A 1 mW green beam (532 nm) will be better perceived by the human eye than a 1 mW red beam (635 nm).
Applications
-High-end aligment and targeting
-Fluorescence
-Machine vision
-Positioning
-Industrial inspection
-R&D |
|
Thermo-electrically cooled, (TEC), blue/violet laser diode modules which offer exceptional wavelength and power stability, (better than 1%), greatly increased pointing accuracy and significantly extended laser diode lifetime.
Designed for applications demanding consistency and repeatability such as industrial inspection, high-resolution printing, reprographics, biomedical instrumentation, spectroscopy, microscopy and genomics, the modules are compact, versatile and highly cost effective.
They produce elliptical output beams and output powers of 1.5mW in the 375nm ultra-violet, 4mW and 25mW in the 405nm violet and 4mW in the 440nm blue wavelength bands.
The modules incorporate microprocessor based temperature control electronics, thermo electric cooler, heatsink and fan that enable the laser diode temperature to be controlled to a set point temperature between +15 degrees C to +25 degrees C, (user adjustable), and with a stability of +/-0.05 degrees C.
All UV, violet and blue TEC laser diode modules in the range offer low and high temperature automatic shut-off protection, analogue and digital modulation capability and safety interlock, as standard. |
|
Low noise, temperature stabilized laser mounts is designed for easy operating Fabry Perot, Broad Area Lasers, DFB and DBR lasers. The intelligent, low noise microprocessor operated laser controller allows a safe and easy operation of all wavelength scanning functions of DFB and DBR diodes. Remote control via GPIB, USB, or RS232 our Cheetah laser system enabled an easy system integration for OEM customers. Available models are:
Cheetah Laboratory Grade Laser System
Cheetah OEM Laser System
Cheetah Butterfly Laser System
Customized DFB and DBR Laser Wavelength Selection:
OEM Industrial Grade Laser Controller |
|
TEC Laser:
The TEC laser is now available in Ultra-Violet, Violet, Blue, Red or Infrared. Our design boasts one of the longest violet/blue diode lifetimes. All the interchangeable pattern projection heads of our SNF Series laser work with the TEC series laser.
The TEC laser's thermoelectric system maintains a constant laser diode temperature, allowing the use of these lasers in applications demanding consistency.
- Excellent wavelength and power stability
- Extended lifetime
- Line generators that have a uniform intensity distribution
- Wide range of wavelengths, fan angles and patterns
- Focusable
- Spatial filters available
- ESD, over-temperature, and reverse-polarity protection
Applications
-Medical applications
-Machine vision
-3D contour mapping
-Alignment
-Positioning
-Industrial inspection
-R&D
-Microscopy |
|
| Distributed Feedback (DFB) Diode Lasers are fixed wavelength single mode diode lasers. Typical geometrical sizes of the laser chip are 1000µm x 500µm x 200µm (length x width x height). The laser chip is grown by MOVPE of compound semiconductor material. The optical gain is provided by double heterostructure which include several Quantum Wells for electronic confinement. Typcal emitter width range between 3µm and 7µm. The single mode emission is enforced by a Bragg grating with the laser chip. The surfaces of the laser chip act as cavity mirrors due to the difference of the refractive index of the laser material and the surrounding air. The rear facet of the laser chip is provided with a high reflection coating. The front facet of the laser chip is provided with a high quality antireflection coating for avoiding the Fabry Perot modes of the laser chip. Distributed Feedback (DFB) Diode Lasers are available at almost any wavelength between 760nm and 2800nm. |
|
BC4 series diode laser beam combiners can combine up to four laser diodes with similar (at least two different wavelengths with 50 nm spacing) or disimilar wavelengths (at least 50 nm spacing) .
Photo monitor of the combined power output is an optional addition.
The standard package features an SMA receptacle for multimode fiber coupling. The combiners can accept both 5.6 mm and 9.0 mm TO packages. |
|
| ... products without technical information |
| |
| The Pilot PC is benchtop, highly precise, low noise, microprocessor operated, controller for laser diodes. The laser current or the optical output power and the temperature of the connected laser diode can be precisely regulated. For automated control, a GPIB / IEEE 488.2, a RS232 and a USB computer interface allows remote programming and readout from most computers |
|
-High stability, low noise output
-Dual output ranges on most models
-Constant current and constant power operating modes
-Multiple laser protection features
-Up to 15V compliance available with 4-Wire voltage measurement on select models
-Pulsed and CW modes
|
|
| The OP250 is a configurable stabilized light source with a variety of Lasers and LEDs. Available in a single port or dual port configuration, selectable wavelengths, and various power levels and industry standard optical interfaces this instrument offers all the features and functions necessary for the development, testing and inspecting of optical components and cables. |
|
| Distributed Feedback (DFB) Diode Lasers are fixed wavelength single mode diode lasers. Typical geometrical sizes of the laser chip are 1000µm x 500µm x 200µm (length x width x height). The laser chip is grown by MOVPE of compound semiconductor material. The optical gain is provided by double heterostructure which include several Quantum Wells for electronic confinement. Typcal emitter width range between 3µm and 7µm. The single mode emission is enforced by a Bragg grating with the laser chip. The surfaces of the laser chip act as cavity mirrors due to the difference of the refractive index of the laser material and the surrounding air. The rear facet of the laser chip is provided with a high reflection coating. The front facet of the laser chip is provided with a high quality antireflection coating for avoiding the Fabry Perot modes of the laser chip. Distributed Feedback (DFB) Diode Lasers are available at almost any wavelength between 760nm and 2800nm. |
|
BC4 series diode laser beam combiners can combine up to four laser diodes with similar (at least two different wavelengths with 50 nm spacing) or disimilar wavelengths (at least 50 nm spacing) .
Photo monitor of the combined power output is an optional addition.
The standard package features an SMA receptacle for multimode fiber coupling. The combiners can accept both 5.6 mm and 9.0 mm TO packages. |
|
| The Pilot OEM is an industrial grade, highly precise, low noise, microprocessor operated controller for laser diodes, especially designed for rough enviroments. The laser current or the optical output power and the temperature of the connected laser diode can be precisely regulated. For automated control a RS232 computer interface allows remote programming and readout from most computers. Several security concepts are implemented: Slow Start, Interlock, Compliance Voltage Protection, Passive Polarity Protection by separated current lines. |
|
| ... products without technical information |
| |
The Photon Laser Module is a self-contained module designed as a complete laser diode solution for OEM use. Applications include industrial alignment, machine vision, measurement & positioning, medical fluorescence and bar code readers.
Wavelengths range from 635nm-830nm, with an elliptical output beam and powers from 0.9mW to 85mW. The laser modules can be supplied with various coloured sleeves to assist in wavelength and power identification. Other wavelengths and power options are available - please contact our sales department to discuss your requirements.
The customer-adjustable lens for collimated or focused beam may be replaced by other optical systems such as line and cross generators.
The laser module consists of an anodised aluminium housing, laser diode, drive circuit and collimating lens, either cylindrical or with a 25mm mounting flange. Mechanical dimensions are 12 mm diameter x 43mm length and all standard Photon Module options are available. Electrical connections are made via external flying leads. |
|
T-MFL Lasers:
StockerYale’s Lasiris™ T-MFL lasers produce long telecentric lines as thin as 9.0 µm at 1/e2 at a specified working distance and are designed for applications where utmost accuracy and precision are required.
This technology benefits applications such as inspection of microelectronics, solar cell inspection, high resolution 3-D contour mapping and other machine vision systems.
Lasiris T-MFL lasers use refractive uniform line generator optics without beam clipping.
- Line width remains constant along line length
- Extremely thin lines down to 9.0 µm at 1/e2
- Line length up to 60 mm
- ESD, over-temperature, over-voltage and reverse-polarity protection
- Two year warranty
Applications:
Precision inspection of small parts (chips, wafers, small pins, resistors, semiconductor components)
Solar cell inspection
High precision surface analysis
Machine vision
3-D contour mapping
Industrial inspection
Bio-detection |
|
Laser diode of alignment for industrial use, uasn in many applications that need the aligned one precision to cut, positioned of precision to mark, to make holes, to make borders...
Applications and sectors type:
- aligned marble pieces in cutting machines
- aligned tables or trunks in the sector of the wood
- aligned fabrics, botenes, pockets... in the textile sector
- aligned planxas or blocks in iron and steel industry
- aligned tables and leaves in premsas
- To aim positioned in cranes
- ecc ............
The comfort of this system is in seeing early where the requested work will be developed, then the work will be faster and with less errors.
Laser Rasnel produces lasers for 20 years and we can count between our European clients more than 100 constructors of machinery for the industry. |
|
The 300-0600-00 series of Thermo-Electrically Cooled, (TEC), red and infrared laser diode modules offers exceptional wavelength and power stability, (better than 1%), good pointing accuracy and significantly increased laser diode lifetime.
Designed for applications demanding consistency and repeatability such as machine vision, alignment, industrial inspection, high-resolution printing, biomedical instrumentation, spectroscopy, microscopy and genomics, the TEC laser modules are compact, versatile and highly cost effective.
The laser module produces a circular output beam and output powers of 0.9mW to 32mW at 635nm, 25mW at 690nm, 55mW at 785nm and 24mW to 120mW at 830nm.
We can fit almost any laser diode in a 9mm or 5.6mm package into our TEC laser modules. If you need a wavelength or power that we do not offer as standard, please contact our sales team to discuss your requirements. |
|
Powerline lasers:
StockerYale’s Lasiris™ PowerLine structured light laser is a line generator developed for demanding industrial machine vision and scientific applications. Bridging the power gap between the popular SNF and Magnum series lasers, this thermoelectrically cooled device is able to emit uniform laser lines at high powers, up to 1 W at 810 nm and 500 mW at 670 nm.
With exceptional beam pointing and focusing stabilities, the PowerLine laser can be operated in extreme environments ranging from -20°C to +55°C. The laser beam can be modulated by an external signal through a DB-9 connector on the back panel and all models can operate in either CW or external modulation mode. The laser is protected against over-voltage, reverse polarity of the power supply, over-temperature, and ESD. |
|
| Coherent's Laser Diode Modules combine the technology of the diode laser with quality optics, sophisticated electronics and rugged modular packaging to provide a reliable laser source suitable to a variety of application needs. |
|
Features:
- Uncooled operation at 1310 nm
- MSA compliant XMD (10 Gbit/s Miniature Device)
- Field-proven high reliability
Applications:
- OC-48 and STM-16 (2.5 Gbit/s), OC-192 and STM-64 (10Gbit/s) trans-mission systems
- Long haul and Metropolitan DWDM systems
- Small form Transponders and Transceivers |
|
| New Source Technology can provide you with a variety of Laser modules, which are offered for use as a building block "engine" in the development or production of rod laser systems, or as a drop-in replacement for arc lamp pump chambers in industrial lasers. They are well suited for applications such as laser marking, materials processing, and scientific research. |
|
| Silver Bullet diode laser sub assemblies (ASMs) are offered with optional soldering kits. CEO® can also attach Silver Bullets to customer-supplied heat exchangers to make completely packaged laser diode arrays. Extreme care should be taken when handling these components. We recommend that they be only used by customers who are experienced in the handling and packaging of laser diode bars. |
|
