Signal lamps with integral filament lamps/LEDs or with lamp sockets
Signal lamps with integral LED, mounting hole diameter 5 - 10 mm
Signal lamps with integral filament/neon lamp, mount.hole.diameter 5 - 14 mm
Signal lamps with lamp sockets, mounting hole diameter 9 - 30 mm
Panel mounting sockets, tubular lamp holders |
|
AE&T has developed a system of flashing lights specially designed for illuminations. The LED flashing lights are addressable and programmable to enable users to create their required lighting effects.
The system is connected via a BUS system :
- a string of a maximum of 60 flashing lights
- 2 branches per string, 5A maximum per branch
- 200 control boxes (concentrators) on a single bus
- Up to 12.000 lights
Light characteristics :
- LED technology : service life of 30 million flashes
- lighting power : variable from 0.1 to 4 Joules. 2 Flashes/sec maximum
- 48 V DC power supply (40-60 VDC) 10 VA maximum
- low consumption : from 25 mA to 100 mA
- degree of protection : IP 55
- thermal dissipation : 10 W
- grey polycarbonate box and clear dome
- leds available in white, green, red, orange. Different coloured lights can be combined to give different colour effects
|
|
PEW Flashing Light - w/ Audible Alarm option
PES - Flashing Light
- Size: 82 mm diameter
- Colors available: Red, Yellow, Green
- Unique LED reflection system and lens increases visibility
- Dome is viewable from top and sides
- PEW-B features 85 dB (at 1m) adjustable audible alarm with volume control
- Power consumption: approximately one-half of comparable bulb products
- Flashing function available in three different flash rates: 60 fpm, 120 fpm, 180 fpm
- NPN open collector transistor compatible
- IP Ratings: PEW meets IP-54 ; PES meets IP23 (IP-55 w/gasket )
- CE rated |
|
The rules of beaconing of the obstacles to the aerial navigation are defined by the International Civil Aviation Organization (ICAO) (Appendix 14 Volume 1, 3rd edition July 1999).
The obstacles defined by the ICAO include/understand the following structures:
- smokestacks
- pylons (Telecom, TV, Radiocom...)
- lines High voltage (electric distribution)
- bridges
- buildings great height
- powerplants
- cranes
The ICAO recommends the average use of fires intensity for the structures exceeding 45 m height. For structures exceeding the 150 m height, the average use of fires intensity will have to be supplemented by a marking (red/white).
Fires average intensity BA200 and BA202 only fulfill the requirements of the ICAO for marked out structures of night (BA200 with an luminous intensity higher than 2.000 Cd) and for the marked out structures day and night (BA202 with an luminous intensity higher than 20.000 Cd of day and 2.000 Cd of night). |
|
| The LED501/500 beacon conforms to ICAO requirements for aviation obstruction marking. This product is of robust, corrosion-free construction and has a rubber housing which offers vibration protection. Ideal for most low intensity applications. Various mounting bracket options. Available in red only. |
|
The new Moflash "Spectrum 600" LED Beacon offers the option of 3 colours in one enclosure (Red, Amber and Green). The Spectrum 600 also incorporates a Piezo Buzzer offering an additional audible signal option. The unit offers a total of 28 signal combinations for PLC controlled operation. An optional interface unit is available for non-PLC operation and offers 8 pre-set signals.
|
|
| The Moflash range of rotating beacons incorporates a parabolic reflector which revolves around a continuously illuminated lamp - thus giving the rotating effect. This gives a powerful beam of light travelling through 360 degrees. Available in a wide range of voltage options. Diode Polarised and Magnetic Base versions also available. |
|
| The Moflash X501/X500 is an extra-high output Xenon beacon - making it suitable for the more demanding of visual applications. The unit also offers the option of double-flash which extends the signal duration and makes it more noticeable to the human eye. Available in a choice of five colours (amber, red, blue, green or clear). |
|
The DA135 LED Beacon provides an ultra-bright LED flash to warn of abnormal events in any hazardous area.
It is ATEX certified to Ex II 1G for use in any zone. The ruggedised and encapsulated enclosure is sealed to IP65 to ensure reliable operation in harsh environments and is backed up with our 5 year warranty.
Available in five equally bright colours including white and blue, the DA135 Beacon is often used as a simple flashing warning signal but there are also additional unique display features that allow the user to show additional information. These include single, double and triple flash selection and a dual colour version.
Combined with our Intrinsically Safe Sounder and a pushbutton the unit can be configured as a full single point alarm annunciator.
|
|
New DA135 Intrinsically Safe LED Beacon from RTK Instruments
RTK Instruments has developed a new range of LED Beacons, which provide powerful visual alarm signals in both hazardous and safe areas. The DA135 is ATEX certified for use in Zone 0, 1 or 2 hazardous areas and is available in five super-bright colours. The ruggedised and encapsulated enclosure makes this an ideal choice for the harsh environments found offshore and in the chemical and petrochemical industry.
The standard unit has a unique method of allowing the user to change the flash rate between single, double or triple flash by triggering control inputs. Customers can then use the same unit to indicate different site problems. A dual colour version is also available where each colour can be triggered separately from the control inputs
The DA135 can be operated alone or in conjunction with an intrinsically safe Sounder and Pushbutton to create a fully featured single point Alarm Annunciator.
RTK Instruments is a leading supplier of safe and hazardous area alarm, display and interface products and can provide specific application advice, as well as product recommendations and installation assistance.
|
|
Federal Signal Model 371 incandescent warning lights have a powerful sealed beam lamp that rotates 360º within a glass or polycarbonate dome. Power is delivered to the Commander's rotating lamp by a unique collector ring. The lamp itself is mounted in a pivoting yoke. This allows the lamp beam angle to be adjusted through 90 degrees from horizontal to vertical. Changing the beam angle allows the user to create unique light patterns and/or direct the light for better visibility.
- Available in 120VAC
- Five dome colors
- Pivoting lamp yoke
- Surface mount and integrated 1- inch pipe mount
- Type 4X, IP66 enclosure
- UL and cUL Listed, CSA Certified |
|
- ATEX GOST-R IECEx approved
- All units are available in EEx d and EEx de versions.
- 110dB and 117dB Alarm Sounders.
- 5, 10 & 15 Joule Xenon Beacons
- High output L.E.D beacons and status lamps
-15 & 25W Loudspeakers (100v, 70v line & 16R, 8R low impedance versions).
- 'Appello' Speech and Tone voice annunciaton models.
- Suitable for Zone 1, 2, 21 & 22.
|
|
Hazardous areas often require the use of optical signals for warning or information purposes. The EExII strobe light dSLB21 offers both of these signalling features. It is designed for continuous operation. If the supply voltage is turned on, the Strobe Light dSLB21 is activated. The device is available in several versions with various levels of operating voltage and flash energy and various signalling colours. The stable, glass-fibre reinforced polyester (GRP) housing is made to the IP66 degree of protection and may be used indoors or outdoors. The II 2 G EEx de IIC T6 protection class enables the unlimited use of the signalling device in all hazardous areas, zones 1 and 2. The flameproof enclosure and the "increased safety" type of protection of the terminal room guarantee hazardous area protection. The upper part of the flameproof enclosure, which contains the flash electronic and the mounted flash tube, consists of a transparent Makrolon-cap. An inner cap lends colour to the light. The housing consists completely of GRP. Thus the device is protected against corrosion, and fulfills the requirements of contact safety class II. An equipotentiel bonding is not required. All outer fastening parts are manufactured
in noncorrosive materials. |
|
The new ATEX directive, Appendices 4 &
7, states that manufacturers of electrical
equipment to be used in explosive atmospheres
where flammable gases, vapours,
fumes or dusts are present, must have a
certified quality system according to ISO
9000 with clearly defined quality plans for
the design, production, inspection and assistance
of such equipment that can be constantly
verified by an advisory body.
SIRENA has been awarded an ISO certificate
by Istituto Masini, notified body no.
0068. |
|
Application
It is often necessary to use optical signals for warning, indicating and signalling purposes in areas with explosive atmospheres. The ExII-signal light dSLB 20 LED offers these signalling possibilities. Through the 4 modes (blinking, flashing, permanent or rotating) this signal-lamp is uniquely in the ex market. Decision-advantages for this modern technology are not only the reduced of warehouse charges (only one article on stock) but also the illuminations level. |
|
ActiveLine is designed to indicate various operating states of machines and systems. The possible signalling colours green, yellow, red, blue and white are all shown in one single light element. Each colour can be preset to continuous light, blink light or flash light. The light is generated by use of lightemitting diodes. The model with sounder can also generate a penetrating signalling tone, with four adjustable sound levels.
The plastic housing, the stable foot and the sounder housing are made of impact-resistant thermoplastic. The cap consists of im-pact-resistant polycarbonate, and the stand-tube is made of aluminium. |
|
Bright idea for control signals and productivity.
* Size: 82mm diameter.
* Lenses are made of heat and shock resistant polycarbonate resin.
* Colors available are Red, Yellow, Green, and Blue.
* Integral rotating parabolic reflector makes the light visible from a distance.
* Uses incandescent automobile bulb for longer life.
* Rain and dust resistant (IP-23)
* Rubber gasket is available for wash-down applications. (Meets IP-55 requirement for RU models only)
* RUP model is furnished with pole & bracket.
* Rotates 120 times per minute.
* Optional custom poles up to 1000mm long are available.
* CE compliant (12V and 24V versions). |
|
| Hazardous areas often require the use of optical signals for warning or information purposes. The EExII rotating beacon dSLD 21 offers both of these signalling features. It is designed for continuous operation. If the supply voltage is turned on, the rotating beacon dSLD 21 is activated.The device is available in several versions with various levels of operating voltage and and various signallingcolours. The stable, glass-fibre reinforced polyester (GRP) housing is made to the IP66 degree of protection and may be used indoors or outdoors. The II 2 G EEx de IIC T6 protection class enables the unlimited use of the signalling device in all hazardous areas, zones 1 and 2. The flameproof enclosure and the "increased safety" type of protection of the terminal room guarantee hazardous area protection. The upper part of the flameproof enclosure, which contains the electronic and the mounted halogen lamp, consists of a transparent Makroloncap. An inner cap lends colour to the light. The housing consists completely of GRP. Thus the device is protected against corrosion, and fulfills the requirements of contact safety class II. An equipotentiel bonding is not required. All outer fastening parts are manufactured in non corrosive materials. |
|
Ideal for extreme temperatures or chemically exposed areas.
KP Non-corrosive - Fade resistant
* Size: 162mm diameter.
* Acrylic dome is available in Red, Yellow, Green, and Blue.
* Anti-UV coated body protects from fading for long term use.
* Stainless steel bolts and nuts protect from rusting.
* Motor operates at extreme low temperatures of -30°C
* Suitable for chemically exposed areas.
* Spare bulb included.
* Rain and dust resistant (IP-23).
* CE compliant (24V version). |
|
Visual warning signals establish a code communication
through two variables, i.e. different degrees of brightness
and the use of different colours. Through these features
the operator receives information. |
|
KX Flashing strobe - Xenon Type Light
* Night time visibility up to 3000 feet.
* Strobe flashing cycle is adjustable from 30 to 90 flashes per minute.
* Lenses are made of heat and shock resistant polycarbonate resin.
* Newly developed prism cut lenses diffuse light effectively to produce the brightest light possible from all directions.
* Rubber gasket is available for wash-down applications. (Meets IP-55 requirement.)
* The strobe tube is unaffected by vibration and average life is up to 10,000 hours.
* Colors available are Red, Yellow, Green, and Blue. |
|
| APS Resource is a recognized leader in providing lasting and economical solutions to safeguard loading dock personnel and warehouses against accidents and damage from poor lighting or poor communication between truck driver and dock workers. APS offers dock lights in many sizes and variations to meet your needs. Our line of safety products has been developed to solve multiple safety concerns at your facility. |
|
The DB5 intrinsically safe multitone sounder is ideally suited for use in areas of high ambient noise. Additionally, for extreme noise levels, they can be linked with the DA134 Xenon Beacons to combine audible and visual warnings. They are designed with a re-entrant configuration to combine compactness with maximum efficiency.
One of 26 tones can be selected using a 5-way DIL switch and by switching the incoming negative supply to a third terminal a second tone is sounded. The sounders have suitable low frequencies to conform to BS 5839: Part 1: 1988, making them ideal for fire alarm systems and other annunciator applications.
The IP65 enclosure enables the DB5 sounder to cope with the harsh environmental conditions found offshore as well as those of the onshore oil, gas and chemical industries. The tough construction enhances the reliability of the solid-state piezoelectric sounder. |
|
|
|
