The USB to CAN bridge/gateway enables communication between two or more devices that use different communication interfaces (RS232 or USB in one device, and CAN in the other).
The converter acts as a bridge and interpreter between the devices.
The USB to CAN bridge/gateway is compatible with standards for CAN messages established in the CAN 2.0A and CAN 2.0B standards.
Main features:
------------------
* Sending and receiving CAN messages in ASCII format.
* Compatible with CAN 2.0A and CAN 2.0B.
* Communication speeds available:
- RS232/USB interface: set at 115200bps.
- CAN interface: 10, 20, 50, 125, 250, 500 or 1000Kbps can be set using ASCII commands.
* Configurable CAN communication parameters:
- Mask.
- Filter.
- Standard (11-bit identifier) or extended mode (29-bit identifier).
- Transmission speed.
* Full report of communication errors obtained.
|
|
USB400
Industrial RS422/485 - USB gateway
The new range of serial to USB solution offers performance, simplicity of installation, security, robustness and high reliability at affordable prices.
USB400 is enclosed in a compact aluminum case (dongle format), it features an industrial 2-4 wire RS422 / RS485 serial interface with 5-point screw-in terminal block.
USB400 installation is quite simple as the product is instantly plug & play, it doesn't require any IRQ, DMA or I/O port resources.
Installed serial ports are considered by Windows 9x, Windows 2000, Windows XP & Linux operating systems as computer's standard COM ports.
|
|
|
|
|
|
Panel Mount - USB to Serial Converters, 2-4 Ports
Connect serial devices to your USB-only PCs
Benefits
Use legacy serial devices with USB PCs and laptops
Connect multiple devices with multi-port models
Features
New! Higher retention USB connector...
Meets Class 1 Div 2 withdrawal requirements (15N)
Add two or four COM ports to your USB PC
LEDs on transmit and receive lines
USB 1.0, 1.1, and 2.0 compatible (12 Mbps)
Automatic configuration on Windows 98, ME, 2000, XP and Vista
No power supply required (powered from USB bus)
Includes 1 meter USB cable
Get the extended range and multi-drop capability of RS-232 or RS-422/485 from the USB port of your PC. Windows automatically configures the serial outputs as additional COM ports, compatible with your Windows application.
RS-232 USB/serial converter unique features
Full handshake support (TD, RD, RTS, CTS, DTR, DSR, DCD, RI, GND)
DB9 male (DTE)
Baud rates up to 460 Kbps
RS-422/485 USB/serial converter unique features
Pluggable terminal blocks
Supports TDA, TDB, RDA, RDB, GND
Baud rates up to 921 Kbps
Use on RS-485 2-wire or RS-422/485 4-wire networks
Supports Send Data Control (SDC)
|
|
Instant Plug & Play
The UPort® 1110/1130/1130I/1150 USB-to-serial converters are the perfect accessory for laptop computers that don’t have a serial port. The UPort® 1110 converts from USB to RS-232, the UPort® 1130/1130I from USB to RS-422/485, and the UPort® 1150 from USB to RS-232/422/485. All three products are compatible with new and legacy serial devices, and can be used with mobile, instrumentation, and point-of-sale applications.
Features:
Compatible with USB 2.0
12 Mbps USB data rate
921.6 Kbps maximum baudrate for super fast data transmission
Drivers provided for Windows, WinCE, and Linux
Mini DB9 female to terminal block adaptor for easy wiring
LEDs for indicating USB and TxD/RxD activity
15 KV ESD protection for all serial ports
2 KV optical isolation protection (UPort® 1130I only)
|
|
Converter DCS770 is low cost unisolated USB to RS485 converter which powers itself from USB.
Converter RCS770 has 3-way galvanic isolation between USB, 232 and 485/422 and supports all conversions between these. If used with USB it powers itself with USB, otherwise it needs power supply.
It has it all.
See our website for more information.
|
|
|
|
|
|
The new versions of NETLink PRO and the S7/S5 OPC Server, as well as Softing’s new S5-PCLink, have expanded the suite of Softing products for convenient, powerful and economical access to data in SIMATIC S7 and S5 controllers. NETLink PRO, which was recently recognized as one of the top developments of 2006, is a robust S7 adapter available in Ethernet and USB versions. In hundreds of installations worldwide, it has proven itself to be an economical alternative to the communications processors from Siemens and other manufacturers. The new Version 1.3 is up to 20% faster than its predecessor, and it supports up to 12 MPI/PROFIBUS connections at once. With a single NETLink PRO, you can easily access up to twelve S7 controllers using Siemens STEP7, WinCC, ProTool or the Softing S7/S5 OPC server. The Ethernet version, known as NETLink PRO/ETH, now also supports the RFC 1006 protocol (ISO-on-TCP).
Alongside the adapters for S7 systems, Softing's new S5-PCLink enables economical access to S5 controllers via Ethernet, STEP5 or the Softing S7/S5 OPC server.
STEP®, WinCC®, ProTool® and SIMATIC® are registered trademarks of Siemens AG.
|
|
