Height Adjustment One-touch Spline Controller
-
Adjustment increments Minimum 0.1 mm step
-
Angle adjustment 120° - 180° - 210°
Usage Shaving of weld bead on outside of the pipe
(length direction, circumference direction)
Shaving range Width: 25 mm, Height: -8 mm ~ +4 mm
Dimension of between guide plat: 32mm
O/D of milling head : 35mm
Weight 7.8 kg
-
Power 1700W or 1400W
Inserts 3EA CFWB110350
Application
Non-ferrous metal, Steel, other materials
