CNC turning center VTC2020vertical3-axishigh-productivity
Add to favorites
Compare this product
Characteristics
- Control type
- CNC
- Spindle orientation
- vertical
- Number of axes
- 3-axis
- Other characteristics
- high-productivity, high-speed, high-rigidity
- Diameter
2,400 mm
(94.49 in)- Spindle speed
1,600 rpm
(10,053.096 rad.min-1)- Maximum cutting length
2,000 mm
(79 in)- Axe Z
1,250 mm
(49 in)- Nominal power
37 kW, 45 kW
(50.3 hp, 61.2 hp)- Maximum torque
304 Nm
(224 ft.lb)- Overall lenght
7,150 mm
(281 in)- Overall width
5,270 mm
(207 in)- Overall height
5,940 mm
(234 in)
Description
The VTC2020 is a highly rigid vertical turning center designed for heavy cutting applications. This machine features a hydrostatic table with C-axis indexing, a puzzle-type magazine for greater tooling flexibility, and automatic head changes. The VTC2020’s spindle utilizes a curvic gear-tooth coupler for increased rigidity, while the live function of the spindle allows turning and milling operations to be done in a single set up.
VIDEO
