CNC turning center VTC2525
vertical3-axisheavy-duty

CNC turning center - VTC2525 - Toyoda Machine Works - vertical / 3-axis / heavy-duty
CNC turning center - VTC2525 - Toyoda Machine Works - vertical / 3-axis / heavy-duty
CNC turning center - VTC2525 - Toyoda Machine Works - vertical / 3-axis / heavy-duty - image - 2
CNC turning center - VTC2525 - Toyoda Machine Works - vertical / 3-axis / heavy-duty - image - 3
CNC turning center - VTC2525 - Toyoda Machine Works - vertical / 3-axis / heavy-duty - image - 4
Add to favorites
Compare this product

Characteristics

Control type
CNC
Spindle orientation
vertical
Number of axes
3-axis
Applications
heavy-duty
Performance
high-speed, high-rigidity
Associated function
milling
Diameter

3,000 mm
(118.11 in)

Spindle speed

1,600 rpm
(10,053.096 rad.min-1)

Maximum cutting diameter

3,000 mm
(118 in)

Maximum cutting length

2,500 mm
(98 in)

Axe Z

1,500 mm
(59 in)

Rapids on X

10,000 mm/min
(7 in/s)

Rapids on Z

8,000 mm/min
(5 in/s)

Nominal power

60 kW, 75 kW
(81.6 hp, 102 hp)

Overall lenght

7,680 mm
(302 in)

Overall width

5,570 mm
(219 in)

Overall height

6,765 mm
(266 in)

Description

Achieve maximum production and flexibility for high-torque, high-speed turning and milling applications at an exceptional value with Takisawa CNC turning centers The VTC2525 is a highly rigid vertical turning center designed for heavy cutting applications. This machine features a hydrostatic table with C-axis indexing, a puzzle-type magazine for greater tooling flexibility, and automatic head changes. The VTC2525’s spindle utilizes a curvic gear-tooth coupler for increased rigidity, while the live function of the spindle allows turning and milling operations to be done in a single set up.
