Stroke : 10 mm - 1,000 mm
Force: 18 N - 450 N
Speed: 10 mm/s
The new Series 23 pneumatic cylinders are based on the innovative concept of ‘auto-cushioning’ and comply with the ISO 6432 standard. The cylinder, thanks to a patented system*, automatically adjusts the cushioning in order to provide ...
Stroke : 1 in
Clippard's 7S-1 bore brass cylinder is capable of handling demanding applications with its universal mount and simple and user-friendly build. A versatile tool, it boasts features such as the spring return, 0.6 power factor, 1/8 NPT ports, ...
Stroke : 0 mm - 6,000 mm
Torque: 10 Nm - 480 Nm
- Torque 10 ... 2300 Nm - Swivel angle 0 ... 90°, 0 ... 180° - Flange hole pattern to ISO 5211 - NAMUR connection pattern for solenoid valves/sensor boxes to VDI/VDE 3845 - Epoxy coating - for butterfly valves and ball valves
Stroke : 5 mm - 500 mm
Com pod cylinder to ISO 21287, UNER series, available in different versions to meet all possible requirements: •With or without magnet •Double oding, single or through piston rod •Double oding, perforated through piston rod •Single ...
Stroke : 10 mm - 200 mm
The guided compact cylinder series CMPG is a robust and practical solution with a built-in guide unit. The rod guiding bushes are mounted directly in the anodized aluminium alloy lining. Two guiding solutions are available: sintered bronze ...
Stroke : 1 mm - 5,000 mm
Force: 153 N - 754 N
Diameter: 18, 25, 40 mm Stroke length: 1 ... 5000 mm Force: 153 ... 754 N Position sensing End position cushioning with shock absorber Recirculating ball bearing guide Special features: Heavy-duty guide ...
Stroke : 10 mm - 3,000 mm
Force: 153 N - 3,016 N
Diameter 18, 25, 32, 40, 50, 63, 80 mm Stroke length 10 ... 3000 mm Force 153 ... 3016 N Position sensing Adjustable cushioning Guide variants Ball bearing guide Heavy-duty guide
The range of HP high-pressure inflatable jacks can be used with inflation pressures of up to 7 bar. PRONAL can supply single-stage, two-stage or three-stage jacks with a square or circular profile. Single-stage jacks can also be produced ...
The SOUPLETEAU range of jacks can be used with inflation pressures of up to 3 bar. These devices can operate in compact spaces (12mm in depth). Jacks can be used in a wide variety of applications for the generation of loads, volume ...
Manufactured from a synthetic rubber-coated fabric base and assembled by hot vulcanization, the PRONAL annular jack can be deployed for numerous applications, including sealing, compression, clamping, handling, isolation, gripping, etc.. ...
Tube I.D. φ 16, 25, 32, 40, 50, 63 (mm). Equal forces on both ends of the piston. High cantilever and direct loads can be taken on piston.
Tube I.D. φ16, 25, 32, 40 (mm), 50% space saving when compared to conventional cylinders. End caps with 3 air connections and adjustable cushioning. Load strength is higher than MCRPLF series (about 4 Multiple).
Stroke : 50 mm - 1,500 mm
Force: 0 N - 10,000 N
Speed: 80 mm/s - 150 mm/s
Features The load capacity is extremely strong when used vertically. Horizontal use and external guide mechanism can effectively improve the lateral load capacity of the electric cylinder; High-speed, high-precision positioning features; High ...
Special cylinders is created to adapt customer's specific needs. Its manufacturer with a team of professionals is capable of designing and manufacturing the pneumatic cylinder that best adapts to the needs of each customer where a "customized" ...
The 30-35 series, which are manufactured by Aircontrol, are heavy-duty pneumatic cylinders. The units are ideal to use in extreme applications with minimal servicing conditions such as opening truck platforms, and as well as closing furnace ...
Stroke : 10 mm - 500 mm
Force: 12,058 N - 18,840 N
Covers: Painted die-cast aluminum Tube: Anodised aluminum Seals: Polyurethane - NBR Guide bush: Sintered bronze Piston rod: Chromium coated steel Tie rods: Chromium coated steel Max pressure: 10 bar Operating temperature: -20 ° ...
Stroke : 10 mm - 500 mm
Force: 29,438 N - 48,230 N
Covers: Painted die-cast aluminum Tube: Anodised aluminum Piston: Aluminium Seals: Polyurethane - NBR Guide bush: Sintered bronze Piston rod: Chromium coated steel Tie rods: Chromium coated steel Max pressure: 10 bar Operating ...
Stroke : 5 mm - 60 mm
Force: 188 N - 4,710 N
ISO 21287 compact cylinders. Available with magnet, single or double acting, single or through piston rod, non-rotating or not. Compatible with ISO 15552 mounting accessories. Special versions are available. ISO 21287 Compact "K" ...
Stroke : 300 mm
Force: 0 N - 600 N
This pneumatic linear unit has the ability to move considerable loads extremely fast. Transverse forces of a maximum of 600 N are easy owing to the exclusive guiding. The extremely short end damping permits a controlled transfer of the ...
HIGH TEMPERATURE (PH): High temperature actuators to pilot ball, butterfly and plug valves for high temperature environments. May be actioned with air or any nonagressive fluid up to 8 bar pressure (to 15 bar, on demand). Working ...
Stroke : 25 mm - 1,000 mm
Features High quality anti-corrosion cylinder Hygienic design, easy to clean for Food Industry applications Long service time and easy maintenance Wide range of options
Stroke : 500, 800 mm
Double acting, Non-rotating, single or double rod with Air cushion on both ends and Bumper cushion Bore sizes (mm): 32, 40, 50, 63, 80, 100 Standard stroke up to 500mm, maximum stroke 800mm Auto switch capable
Stroke : 26, 27, 29 mm
Force: 500 N - 4,000 N
This extremely robust linearsystem from the series PLK 16, PLK 25, PLK 32 and PLK 40 has been especially developed for use in the machine tool and robototics industries. The move force for this guide is our proven rodless cylinder PL ...
Stroke : 20 mm - 50 mm
This is a square, space saving cylinder that can be used for applications in which a lateral load is applied to the piston rod.
These end effectors offer the user a wide range of advantages over traditional pick and place work holding devices. Simply by varying the air pressure in the picker or gripper, the user can conform the end effector to the diameter that ...
The In Force Cylinder Line is a heavy-duty , steel body cylinder line that is designed and built to exceed all your strenuous application requirements. The ASP Series is an NFPA Steel Body pneumatic cylinder line. The ASP Series encompasses ...
Heavy Duty Service - NFPA Specifications and ANSI B93.15-1981 Mounting Dimension Standards Standard Construction - Square Head - Tie Rod Design Nominal Pressure - Up to 250 PSI Air Service Standard Fluid - Filtered Air ...
Class 1 SVR: Severe Service Heavy Duty, Cast Head Cylinders
Stroke : 30 mm - 300 mm
Pneumatic cylinders SOBRAIR to increase the mechanical strength Applications: clamping, punching, crimping, swaging, riveting, cutting.
Take advantage of Seal Master Corporation's extensive rubber fabricating expertise. Custom inflatable shapes and structures required for sealing and/or lifting purposes can be engineered and manufactured for your specific application requirements.
Standard Metric Cylinders Standard Metric Cylinders Product Description Compact Automation Products cylinders are designed for limited space and weight applications. Cylinders are up to 60% smaller than conventional types and are ideal ...
