Straight-line toggle clamps

Clamping force: 55 N - 175 N

Can clamp at the same position by precision projection of clamping bars. Clamping bar deflection is ±0.05. Clamping force is constant. The handle clicks to indicate the clamping end.

Clamping force: 50 N - 140 N

For low profile clamping. Compact manual push-pull toggle clamps whose handle clicks at the clamping end. Clamping bar moves along with push-pull operating handle. Clamping Force: 50 - 140 N Clamping Stroke 1.5

Clamp made of galvanized steel. Handle cover in orange oil-resistant plastic.

Clamp made of galvanized steel. Supplied with neoprene pressure pad. Handle cover in orange oilresistant plastic.

Clamping force: 20,000, 40,000 N

Base and latch bracket in cast steel. Clamp in galvanized steel. Handle in spheroidal graphite casr iron. Handle cover in orange oil-resistant plastic.

Clamping force: 45 N

Flanged Base Manual Push Pull Clamp fits spindle threads to hold materials in place with 45.0 N of force. The low profile clamp uses a Forward Action to prevent slippage and movement.

Clamping force: 890 N

Capable of being installed straight into a tapped hole or with the aid of a hex locknut, the flush mount toggle clamp features a hex locknut and a blue vinyl handle. The two types of ...

HDP1300 HD Long Handle Toggle Clamps Plunger: Locks at both extended & retracted ends of the stroke Base: Body mounting Nominal Holding Force: 1,322 lbs. Weight: 1 lb Supplied complete with: Setscrew & nut

HDP2600 HD Long Handle Push-Pull Toggle Clamp Plunger: Locks at both extended & retracted ends of the stroke Base: Body mounting Nominal Holding Force: 2,643 lbs. Weight: 3 lbs Supplied complete ...

Clamping force: 800 N - 4,500 N

Clamping force: 1,000, 2,000 N

Clamping force: 12,000 N - 77,000 N

Toggle clamp Form ASD Push and Pull Toggle clamps - Straight-line action series Push and pull Straight-line ...

Toggle clamp Form ASS Toggle clamps - Straight-line action series Push and pull Straight-line Action ...

Toggle clamp Form ASD Heavy Push and Pull Toggle clamps - Straight-line action series Push and pull straight-line ...

Clamping force: 2,000 N - 3,000 N

Push-pull type toggle clamp variable with angle base. Toggle clamp with continuous counterbalance function for workpieces with different clamping ...

Clamping force: 2,000 N - 3,000 N

Push-pull type toggle clamp variable with horizontal base. Toggle clamp with continuous counterbalance function for workpieces with different clamping ...

Clamping force: 0.8 kN - 4.5 kN

Push-pull type toggle clamp with small angle base. For push- and pull-clamping. (Equal operation of rod and lever). Long rod-guide with attaching thread and nut. Galvanized and passivated. Rivets ...

MATERIAL: Adjustable toggle latch made of galvanised shear steel. SURFACE: Glossy. ATTENTION: THE CATCH PLATE MUST BE ORDERED SEPARATELY. SPECIAL REQUESTS: • None.

Clamping force: 2,500, 4,500, 7,500 N

The Push-Pull Plunger Clamp, manufactured by Carr Lane, features a space-efficient yet heavy-duty design with an extremely low-profile shape. This clamp is equipped with a robust forged steel base for ...

Clamping force: 670 N

Heavier duty version of model 601 with 50% more holding capacity while keeping the same envelope as the 601. Locks over-center in both extended and retracted position, provided the handle is allowed to fall below the mounting plane. Base ...

Clamping force: 1,471 N

Toggle Clamp Plunger Action Mild Steel Zinc Plate Passivate (Silver Blue)Operates on the over centre linkage principle. High forces are generated as the clamps are locked into position. ...

Clamping force: 1,100 N - 2,500 N

Product details Moving the handle moves the push-pull rod Automatic and infinitely variable adjustment of the clamping height up to 13 mm while clamping force remains unchanged – without having to make manual changes to the ...
