Vertical disc grinding machine ASDlll series
angularfor metal sheetsCNC

vertical disc grinding machine
vertical disc grinding machine
Add to favorites
Compare this product

Characteristics

Type
vertical disc, angular
Applications
for metal sheets
Control type
CNC, automatic
Other characteristics
precision, hydraulic, heavy-duty, vertical
Power

Max.: 5.5 kW (7.5 hp)

Min.: 1.5 kW (2 hp)

Spindle speed

1,750 rpm, 3,450 rpm (10,996 rad.min-1)

Distance between centers

Max.: 630 mm (25 in)

Min.: 0 mm (0 in)

Description

Standard Features On ASDlll models, you can set the vertical zero point, start point, finish grinding volume, target point and the grinding wheel rise-up point. The machine features a simple and clear digital display & touch control panel for easy learning and operation Vertical feed powered by dual motors, AC motor for rapid up / down and stepping motor for micro downfeed positioning, slow auto downfeed and slow up / down Vertical positioning is displayed on the screen showing present spindle and setting the start point,rough grinding volume, finish grinding volume, downfeed volume for finish grinding, target point, rise up point, intermittent spark-out Cross transverse travel powered by DC servo motor, allows step feed and continuous infeed grinding The speed of wheel dressing can be adjusted on the control panel Wide, deep base and honeycomb ribbed column on 10, 12, 16 & 20 series, designed for heavy-duty grinding High quality, ribbed, cast iron table, saddle and base All slideways and screws are fully oiled by an automatic continuous lubrication system to minimize wear on slideways & screws High Grade Anti-Wear Slideways... The saddle rides on precision, hand-scraped double V ways, and the table rides on precision hand-scraped V and flat ways coated with "TURCITE-B". Precision spindle cartridge, supported by preloaded precision angular contact ball bearings and one NN type roller bearing on 618 & 818 models Presettable hydraulic table speed control allows operator to pre-set speed rate, so you can have the same speed rate every time the hydraulic table is engaged (10, 12, 16 series) Ballscrew for cross travel, powered by DC servo motor
