A-frame rack for joinery SAF02-S

General
The Aardwolf SAF02-S stone A-frame is a two-section storage rack designed to support natural and engineered stone slabs. The kit includes two A-frame sections, a steel cross member and all required fasteners. A 4"x2" C-channel at the base accepts timber gluts for additional support.

Features

• Steel construction with powder coat finish for corrosion resistance.
• Full-slab A-frame design supports slabs on both sides.
• Sold and used as a set (two sections with cross member).
• Base C-channel accepts timber gluts to protect slab edges.

Optional extra

• Timber gluts for the base C-channel.

Product code
SAF02-S

Technical specifications

• Material: Steel with powder coat finish.
• Design: Full-slab A-frame.
• Base: 4"x2" C-channel (accepts timber gluts).
• Includes: Two A-frame sections, steel cross member and fasteners.
• Height for full slabs: 1500 mm (59").
• Working load limit (WLL): 12,000 kg (26,455 lb).
• Net weight: 53.8 kg (118.6 lb).
• Gross weight: 59 kg (130 lb).
• Packaging dimensions (frame): L1500 x W200 x H1640 mm (59.1" x 7.9" x 64.6").
• Corrosion mitigation: Drain holes in base rail to remove water.
• Usage: Sold and used as a set.
