Vibration monitoring station ORION

ORION is the new addition to the 01dB monitoring range, covering all vibrations created by human activity. Taking the best features from CUBE and ORION offers unique features for vibration monitoring. Features ROBUST Strong casing IP65 waterproof level HARD WEARING Robust connectors, strong casing IP65waterproof level, battery lifetime of 30 hours EASY TO CONFIGURE QR Code, Mobile app, Web interface MULTI-CHANNELS 4 vibrations channels, 1 pressure channel METROLOGICAL 5 integrated standards: including DIN 4150-3 and BS 5228-4 EASY TO INSTALL Horizontally or vertically mounted, automatic start-up measurements ALWAYS CONNECTED 3G Modem, Wi-FI, Ethernet, GPS, advanced push mode DESIGNED TO PROTECT Buildings protection and occupants protection INTEGRATED TO THE ACOEM ECOSYSTEM dBtrait and Acoem services compatible New standards: ISO 2631-2:1989 and ISO 2631-2:2003 Two new standards – ISO 2631-2:1989 and ISO 2631-2:2003 – released for ORION’s Occupants module (BS 6472-1 and DIN 4150-2 already available) The following indicators can now be measured: ISO 2631-2:1989 Aw(k): weighted rms acceleration per axis (k) AwPeak(k): weighted peak acceleration per axis (k) AvTj: weighted acceleration of the three axes combined A*Tj(k): recomposed acceleration between ⅓ octave F1 and ⅓ octave F2, per axis (k) Weighted rms acceleration ⅓ octave spectrum, per axis (k) Weighted acceleration ⅓ octave spectrum of the three axes combined ISO 2631-2:2003 Aw(k): weighted rms acceleration (Wm) per axis (k) AwPeak(k): weighted peak acceleration (Wm) per axis (k) VDVTj(k): vibration dose value per axis (k) MTVVTj(k): maximum transient vibration per axis (k) Peak factor
