Relative humidity and temperature sensor COMFORT

wall-mountNB-IoTIoT

Overview
This sensor, configurable on NB‑IoT or LTE‑Cat‑M1 networks, monitors ambient temperature and relative humidity inside rooms to support occupant comfort management and energy optimisation.

IoT sensor highlights

• Designed and manufactured in France
• Worldwide cellular compatibility (NB‑IoT, LTE‑Cat‑M1)
• Easy on‑site configuration via the Adeunis NFC Configuration app
• Multi‑platform integration using LwM2M and MQTTS standards
• Up to 15 years battery autonomy in standard configuration
• Also available in LoRa / Sigfox variants

Primary functions

• Measurement: ambient temperature and humidity
• Alerting: configurable threshold alarms and network coverage alerts
• Transmission modes: periodic, event‑driven and logging modes (with configurable logging and blackout options)

Operation & fleet management
The device provides automatic network quality diagnosis, UTC time‑stamped data with remote synchronization, error and fault reporting (including configuration errors and low battery), and supports remote device management (individual or batch commands, configuration read/write, FOTA) via LwM2M.

Complementary information
On‑site parameterisation is available via NFC and automated provisioning on IoT platforms through LwM2M bootstrap. Secure communications are supported using DTLS with PSK and remote update capability for both application and modem firmware.

Technical specifications

• Dimensions: 111 x 61 x 40 mm
• Weight: 140 g
• Enclosure: IP20 (indoor use)
• Mounting: wall or flat placement
• Power: dual Battery Pack or external supply via USB‑C (external supply not included)
• Operating temperature: -10°C to +70°C
• Periodic and/or event‑driven transmissions; configurable logging and blackout to optimise autonomy
• Automatic network quality diagnosis; UTC time‑stamped data
• Error/fault management: configuration error reporting, low battery reporting
• Compatibility: LwM2M 1.1 (over UDP); data formats SENML_JSON, TLV, CBOR, SENML_CBOR; bootstrap support; DTLS (PSK); remote firmware updates (FOTA)
• Configuration: Android NFC app for network/server/application parameters; remote configuration via LwM2M server
• Connectivity: Nano SIM 4FF (Class C 1.8V); 3GPP LTE Release 13; supported networks NB‑IoT and LTE‑Cat‑M1
• Certifications: EU RED (Directive 2014/53/EU), US FCC (Title 47 CFR Part 15), Canada RSS‑247 Issue 2, AS/NZS 4268
• Sensor part number: ARF8394AAA (COMFORT NB‑IoT / LTE‑M1)
