Underwater depth sensor CS229

CS229 Survey or Navigation High Strength for Harsh Environments The high-strength, cast-steel CS229 stands up to harsh environments. It has been designed to facilitate service and repair. The transformer can be accessed from the top of the housing for a quick field repair or impedance change. The transducer is removable from the outer, thru-hull housing and can be replaced while a vessel is underway. Applications: - Large, steel-hull vessels - Harsh environments including ice-filled water - Navigation or survey Features: - Versatile housing accommodates variety of frequencies for most navigation and survey requirements - Low-ringing arrays provide good bottom detail in deep water - Available with stainless steel or “acoustically transparent” urethane window, depending on the frequency - Inner, CS234 transducer and outer, CS229, thru-hull housing Options: - Impedance to customer’s specifications using matching transformer - Available as special-order unit with 12 kHz, 24 kHz, 28 kHz, 30 kHz, 33 kHz, 38 kHz, or 50 kHz array Specifications: - Weight: Varies depending on configuration (Call for weight) - Hull Material: Steel hull only - Acoustic Window: - Urethane: 28 to 200 kHz - Stainless steel: 12 to 24 kHz - Cable Type: C43, one shielded twisted pair (2-14 AWG) with braided shield, black neoprene jacket, 10 mm (13/32") diameter
