3-color flexographic press

for paperfor plastic filmcarton

3 Color Flexo Printing Machine General Features » Via automatic in and out system control provides full control in tension. » Easy-use with 2 control panels. » Illumination in each unit. » Automatic stop in goal quantity. » By the individual drying for each color prevents undesirable mixing (contamination) of the colors. » Easy removable paint tray system. » Tray prevents dripping of the paint. » Free-of-charge operator traning & support. Technicial Specifications Print Paper Width 300 mm Number Of Colors 3 Repetition 200 - 400 mm Anilox Roller Ceramic Anilox Roller Mixer Electric Motor Operated Dr. Blade System 0,20x30 Doctor Knife Automatic Cliché Removing System Pneumatic In Tension Control Magnetic Powder Brake / Digital Control Out Tension Control Electromagnetic / Digital Control Machine Mechanical Speed 150 mt. / min. Machine Chassis/Body Quality ST37 Steel Chassis / Static Powder Painted Chassis Type Tower Transmission System Trigger HSS Timing Belt Register Control Sensitive Register Control during the Work, seperately for each color In and Out Air Mill 76 mm 3 " Meter Counter Digital Drying System Hot / Cold Weather Drying Dimensions G.125 X U.220 X Y.190 cm Weight 800 kg. Electricity 220 V. 50 hz. 7.5 kw / h. Engine Power 2.2 kw. Compressed-air Consumption Just when it is needed, no consumes constantly Operation Pressure 6 bar Packaging Material Used Laminated packaging, OPP, Coated, kraft, metallized. etc. PE, LDPE, MDPE, HDPE, PET, PP, OPP, BOPP, PA, Nonwoven
