Laser marking device LM-F series

laser marking device
laser marking device
Add to favorites
Compare this product

Characteristics

Technique
laser

Description

LM-F010A 10 W Fiber Laser Marker AMADA WELD TECH’s LM-F010A is a rugged, cutting-edge machine designed to address a wide range of metal laser marking applications. This laser is designed with multiple integration options to accommodate standalone operation, full production automation, or prototype development. Frequency range: 20-200 kHz Basic marking of metals and plastics Multi language software support Rotary and XYZ integrated motion for marking on cylinders and tubes PC, touchscreen, pendant or standalone Technical Specifications Technology - Yb:fiber Power - 10 W Frequency Range - 20 kHz - 200 kHz F-Theta Options - 100 mm, 160 mm, 254 mm, 420 mm Communication - EtherNet/IP, TCP/IP, Digital IO, RS-232 Input Power - 110 - 260 VAC ±10%, 10 A Single or 3 Phase - Single Phase Size (L x W x H) - Controller: 26.4 in x 17.0 in x 7.3 in (670.9 mm x 431.8 mm x 186.1 mm) Microhead: 8.49 in x 3.03 in x 4.22 in (215.6 mm x 77 mm x 107.2 mm) Weight - Controller: 61 lb (27.7 kg) Microhead: 8.4 lb (3.8 kg)
