Plate heating element

cast-inaluminumfor thermoforming

Overview
AMARC designs and manufactures cast-in heating plates to customers' technical specifications. These plates contain one or more armoured heating elements embedded in aluminium, bronze or other alloys and are used in industrial processes such as packaging, thermoforming and flow-packing.

Production
Heating element geometry is engineered to deliver uniform surface temperature (design dependent) with precision up to ±3°C and service temperatures up to +400°C. The cast-and-press production ensures material homogeneity, high thermal conductivity and effective heat transfer at the contact surface. Final machining is performed on CNC centres for dimensional accuracy.

Characteristics

• Fully customizable dimensions and mating surfaces
• Minimum plate thickness: 20 mm
• Operating voltage: up to 500 V (custom voltages on request)
• Variable power ratings to suit low- and high-power applications
• Optional coatings for contact areas: non-stick, smooth finish, anti-abrasion

Models
FLOW PACK

• Heating plates for flow-packing applications
• Materials: aluminium, bronze | aluminium
• Voltage: V110 | 230
• Power rating: W150 | 450

THERMOFORMING MACHINE

• Heating plates for hot-pressing and moulding thermoplastic materials
• Materials: aluminium
• Voltage: V230 | 500
• Power rating: W2000 | 10000

SEALING / PACKAGING

• Heating plates for sealing and closing food trays and packaging
• Materials: aluminium
• Voltage: V230 | 500
• Power rating: W2000 | 10000

SPECIAL APPLICATIONS

• Custom heating plates for specific packaging or process requirements
• Materials: aluminium, bronze | aluminium
• Voltage: on request
• Power rating: on request

Benefits

• Controlled casting processes for consistent material quality
• CNC machining ensures precision and repeatability
• Cast-in heating plates offer long service life, reliable performance and efficient heat transfer
• Warranty available up to three years (product dependent)

Technical specifications

• Construction: one or more armoured heating elements embedded in aluminium, bronze or other alloys
• Maximum temperature: up to +400°C
• Temperature uniformity: up to ±3°C across the surface (design dependent)
• Minimum plate thickness: 20 mm
• Maximum standard operating voltage: up to 500 V (custom on request)
• Power ratings: from low power (e.g. W150) to high power (e.g. up to W10000) depending on model
• Materials: aluminium, bronze and other alloys selected per application
• Surface finishes/coatings: non-stick, smooth, anti-abrasion for contact areas
• Manufacturing: cast-in elements with presswork for homogeneity and thermal performance; CNC machining for precision
• Customization: dimensions, mating surfaces, voltage and power configurable to customer specifications
• Warranty: up to three years (product dependent)
