Absolute pressure gauge SOLFRUNT 1409

dialthreadedbrass

Model 1409 SOLFRUNT Test Gauges are stem or low mount pressure gauges used for field testing and validation, with an ASME B40.100 Grade 2A accuracy (±0.50%) up to 1000 psi, or Grade 1A ((±1%) for 1500 psi and above. The Model 1409 has a light weight chrome plated ABS solid front case with a blow out back design. This pressure gauge has a knife-edged micro-adjustable pointer to reduce parallax readings. The gauge has a low mount chrome plated brass socket with a ¼” NPT connection, with a seamless phosphor bronze or beryllium cooper bourdon tube. Pressure ranges are from 0-30 psi through 0-5000 psi. A protective cover is available as an option to protect the window from scratches. These gauges are available with a NIST Calibration Certificate option.
