Packaging film ImaflexellTM C01

barriermultilayerpolymer

Product Overview
The Imaflexell™ C01 is a five-layer freezing film featuring an EVA (Ethylene-Vinyl Acetate) contact layer and an LDPE outer layer. The EVA contact layer provides mechanical strength while retaining flexibility at low temperatures, resisting abrasion, puncture, stretching and tearing. The LDPE outer layer ensures transparency and additional flexibility. Together the layers preserve film integrity in cryogenic and cold-storage conditions, extending service life for temperature-sensitive products.

Applications
Single-sided EVA contact film designed for bioprocessing, pharmaceutical packaging and cryogenic storage. Suitable for freezing bags and containment of biologicals such as stem cells, blood products and reagents where moisture and oxygen barrier properties help maintain stability. Compatible with sterile manufacturing and cold-chain workflows.

Technical Data (summary)

• Appearance: Transparent
• Available Width: 1400 mm
• Available Thickness: 320 μm
• Recommended Sealing Method: Heat sealing
• Recommended Sterilization Method: Gamma, E-Beam
• Manufactured Environment: Cleanroom ISO Class 7

Pharmacopoeia and Biocompatibility Tests

• Biological Reactivity, in vitro (Cytotoxicity Test) — USP<87>
• Biological Reactivity, in vivo (Acute Systemic Toxicity, Intracutaneous and Implantation Test) — USP<88>
• Bacterial Endotoxins - LAL Test — USP<85>
• Extractable Study as per BPOG Guidelines — 24 hours, 21 days, *70 days
• Physicochemical Test — USP<661.1>
• Hemocompatibility Test — ISO 10993-4
• Skin Sensitization Test — *ISO 10993-10
• Skin Irritation Test — ISO 10993-23
• ROHS Complied — Directive (EU) 2015/863
• REACH (SVHC) Complied — (EC) No 1907/2006
• TSE/BSE Declaration (ADI - Animal Derived Ingredients free)
• Phthalate Content Free
• Bisphenol A (BPA) Content Free

Physical Properties (detailed)

• Tensile Strength at Break (ASTM D882): 16 / 8 MPa
• Elongation at Break MD/TD (ASTM D882): 380% / 482%
• Haze (ASTM D1003): 3.57%
• Transmittance (ASTM D1003): 93.4%
• Density (ASTM D792): 0.95 g/cm³
• Water Vapour Transmission Rate (23°C, 100% RH) (ASTM F1249): 0.46 g/m²/24h
• Oxygen Permeability (23°C, 0% RH) (ASTM D3985): 0.002 cm³/m²/day/bar

Film Composition

• Outer layer: LDPE — transparency and flexibility
• Bonding layer: TIE
• Gas barrier layer: EVOH
• Bonding layer: TIE
• Contact layer: EVA — contact surface for frozen products

Technical specifications

• Product name: Imaflexell™ C01
• Function: Freezing application film with EVA contact layer
• Structure: Five-layer film (LDPE / TIE / EVOH / TIE / EVA)
• Appearance: Transparent
• Available width: 1400 mm
• Available thickness: 320 μm
• Tensile strength at break: 16 / 8 MPa
• Elongation at break (MD/TD): 380% / 482%
• Haze: 3.57%
• Transmittance: 93.4%
• Density: 0.95 g/cm³
• Water vapour transmission rate (23°C, 100% RH): 0.46 g/m²/24h
• Oxygen permeability (23°C, 0% RH): 0.002 cm³/m²/day/bar
• Recommended sealing: Heat sealing
• Recommended sterilization: Gamma, E-Beam
• Manufactured in: Cleanroom ISO Class 7
• Regulatory / biocompatibility: Meets indicated USP and ISO tests; ROHS and REACH compliant; phthalate- and BPA-free; TSE/BSE declaration (ADI free)
