Flexible conveyor belt LW series

SBRPTFErubber

Overview
Ammeraal Beltech lightweight rubber belts (LW Product Range) are available in unsupported and fabric-inserted constructions across multiple thicknesses. The range addresses conveying needs where low belt weight and specific material properties (abrasion, oil/chemical resistance, release, grip) are required.

Available materials

• Natural Rubber
• Carboxylated Nitrile
• Nitrile
• SBR
• Butyl
• Silam (silicone-based)
• Teflon (PTFE)
• Cotton

Natural Rubber — General characteristics

• Thermoset rubber
• High abrasion resistance
• Good grip in wet and dry conditions
• FDA-compliant grades available
• Temperature range: -40 °C to 121 °C

Natural Rubber — Main applications in belting

• Paper and cardboard handling
• Wood industry
• Inclined conveyors
• Tobacco industry
• Agriculture

Carboxylated Nitrile — General characteristics

• Thermoset rubber
• High abrasion resistance
• Improved oil and fat resistance
• Good wet/dry grip
• Temperature range: -18 °C to 121 °C

Carboxylated Nitrile — Main applications in belting

• Paper and cardboard handling
• Wood industry
• Sugar industry
• Detergent powder handling
• Metal industry

Nitrile — General characteristics

• Thermoset rubber
• Excellent oil and fat resistance
• Wear and impact resistant
• FDA / USDA-compliant grades available
• Temperature range: -18 °C to 121 °C

Nitrile — Main applications in belting

• Food processing (meat, poultry, fish, cereals)
• Chemical industry
• Textile (roll covering)
• Cardboard production

SBR — General characteristics

• Thermoset rubber
• Good abrasion resistance
• Good grip performance
• Cost-effective option
• Temperature range: -40 °C to 121 °C

SBR — Main applications in belting

• General package handling
• Airport terminals (in- and outdoor)
• Brick and tile handling
• Chemical industry
• Carton handling

Butyl — General characteristics

• Thermoset rubber
• Very good chemical resistance
• Excellent oil and fat resistance
• FDA / USDA-compliant grades available
• Temperature range: -54 °C to 149 °C

Butyl — Main applications in belting

• Freezing applications
• Frying operations
• Shrink tunnels
• Food processing
• Microwave oven applications

Silam — General characteristics

• Thermoset silicone-based rubber
• Excellent release properties
• Good chemical resistance
• FDA / USDA-compliant grades available
• Temperature range: -54 °C to 176 °C continuous; -58 °C to 260 °C intermittent (depending on carcass)

Silam — Main applications in belting

• Tire mixing departments
• Chemical industry
• Shrink tunnels
• Food processing
• Leather and textile handling

Teflon (PTFE) — General characteristics

• Thermoplastic
• Excellent release properties
• Excellent chemical and stain resistance
• Good resistance to oils and fats
• FDA-compliant grades available
• Poor abrasion and scuff resistance
• Temperature range: -50 °C to 82 °C

Teflon — Main applications in belting

• Extrusion industry
• Food industry
• Chemical industry
• Fiberglass manufacturing

Cotton — General characteristics

• Suitable for temperatures up to 120 °C

Cotton — Main applications in belting

• Tire industry
• Cardboard handling
• Metal stamping
• Automotive industry
• Aluminium extrusion

Featured products (examples)
Article Code | Description | Belt thickness | Hardness top side | Info
LWNR560015 | NR EF 16/2 00+C52 black | 7.8 mm | 41A Shore | Datasheet available (datasheet-lwnr560015-en2.pdf)
LWNR560016 | NR EF 16/2 00+C52 tan | 7.8 mm | 40A Shore | Datasheet available (datasheet-lwnr560016-en2.pdf)

Technical specifications / remarks

• Brand: Ammeraal Beltech
• Denomination: LW Product Range
• Product family: Lightweight rubber belts — unsupported and fabric-inserted
• Typical temperature ranges (by material) and key properties are listed per material above
• Selected properties: abrasion resistance, oil/fat resistance, chemical resistance, release behavior, grip (wet/dry) — dependent on material formulation
• Sample references: LWNR560015 (7.8 mm, 41A Shore), LWNR560016 (7.8 mm, 40A Shore)
