Managed switch RJSML-8ELMG

8 portsgigabit EthernetRJ45

Overview
Amphenol Socapex Ethernet Military Switch RJSML-8ELMG is an entry-level managed military Ethernet switch engineered for operation in harsh military and industrial environments. Built for rugged networks in combat vehicles, avionic and shipboard systems, ground stations for UAV/UGV and battlefield C5ISR data acquisition and transmission, it offers a compact, durably designed platform for simplified installation and maintenance and complies with applicable MIL-STD levels where specified.

Key features

• Managed military Ethernet switch
• 8 x Gigabit Ethernet ports
• Entry-level ruggedized design for harsh environments
• MIL-STD compliance options (e.g., MIL-STD-810, MIL-STD-1275)
• Management protocols and monitoring support
• Technical and user documentation available

Applications

• Data acquisition and transmission in C5ISR systems
• Battlefield communications and tactical networks
• Combat vehicles, avionic and shipboard systems
• Ground stations for UAV and UGV
• Rugged industrial networks

Technical information
Detailed technical data, test levels and installation instructions are provided in the product User's Manual available under the Documentation tab. Select models may include enhanced power protection and defined MIL-STD test/compliance levels.

Management & networking features (FAQ highlights)

• SNMP / RMON / MIB support for network monitoring; MIBs provide system, VLAN and statistics information
• VLAN: port-based and IEEE 802.1Q tag-based VLANs for traffic segregation and security
• IGMP and IGMP snooping to optimize multicast forwarding
• Port mirroring for diagnostics and traffic capture
• Per-port flow control to prevent packet loss
• Auto-MDI/MDIX on RJ45 ports
• Management access via Web UI; some models may support serial or Telnet access
• Factory-assigned MAC address; switches support MAC address table storage (typ. up to ~2,048 addresses)

Technical specifications

• Model designation: RJSML-8ELMG
• Manufacturer / Brand: Amphenol Socapex
• Series / Part number: RJSML
• Product type: Managed military Ethernet switch
• Ports: 8 x Gigabit Ethernet
• Ruggedization: Designed for harsh military and industrial environments
• MIL-STD examples: MIL-STD-810, MIL-STD-1275 (options)
• Management & protocols: SNMP, RMON, MIB; VLAN (port-based & 802.1Q); IGMP/IGMP snooping; port mirroring; flow control; Auto-MDI/MDIX
• Management interfaces: Web UI; some models support serial/Telnet
• Documentation: User's Manual and product catalog available via Documentation tab
