Corded electric screwdriver MY-EVO 1 mini

straightwith torque controlfor automatic machines

Product overview
Transducerized DC torque & angle control screwdriver for controlled fastening operations in industrial assembly lines.

Features

• Compact, ergonomic design for extended use with reduced hand fatigue
• Rubberized grip for non-slip hold and vibration absorption
• Four start methods: lever, push, lever+push and external start
• Four LED illumination modes: On / Off / On at start / On when triggered
• Tightening-status LED and buzzer alerts for immediate feedback
• Transducerized DC torque & angle control tightening system with high-resolution encoder
• Angle control range 1°–30600° (≈85 turns)
• < 1% transducer tolerance for precise torque control
• Beginner-friendly downshift and threshold settings in normal mode
• Five customizable rundown steps to adapt screw rundown sequence

Specifications
Model | Input voltage | Torque (N·m) | Torque (kgf·cm) | Torque (lbf·in) | Free speed (r.p.m) | Power consumption | Weight (g) | Length (mm) | Applicable controller | Bit type
MY-EVO 1 mini | DC40 | 0.1–1 | 1.02–10.2 | 0.89–8.85 | 980~20 | 90W | 644 | 285 | MY-EVO mini | B 9.5, C, D
MY-EVO 2.4F mini | DC40 | 0.3–2.4 | 3.06–24.48 | 2.66–21.24 | 2000~20 | 90W | 705 | 293 | MY-EVO mini | B, B 9.5, D
MY-EVO 3 mini | DC40 | 0.38–3 | 3.88–30.60 | 3.36–26.55 | 980~20 | 90W | 705 | 293 | MY-EVO mini | B, B 9.5, D

Applicable Bit Type

• B (including B 9.5)
• C
• D

Accessories (examples shown)

• MY-EVO mini Controller
• KP-AUX-TL-450N
• KP-AUX-TL-700N
• KP-AUX-TI-300N
• KP-AUX-TI-600
• KH-2
• KH-2L

Technical specifications

• Available models: MY-EVO 1 mini, MY-EVO 2.4F mini, MY-EVO 3 mini
• Input voltage: DC40
• Torque ranges (N·m): MY-EVO 1 mini 0.1–1; MY-EVO 2.4F mini 0.3–2.4; MY-EVO 3 mini 0.38–3
• Angle control: 1°–30600° (approx. 85 turns)
• Encoder: high-resolution
• Transducer accuracy: < 1% tolerance
• Free speed (r.p.m): MY-EVO 1 mini 980~20; MY-EVO 2.4F mini 2000~20; MY-EVO 3 mini 980~20
• Power consumption: 90W
• Weight: MY-EVO 1 mini 644 g; MY-EVO 2.4F & 3 mini 705 g
• Length: MY-EVO 1 mini 285 mm; MY-EVO 2.4F & 3 mini 293 mm
• Start methods: lever, push, lever+push, external
• LED illumination modes: On / Off / On at start / On when triggered
• Alerts: tightening-status LED and buzzer
