Testomat 2000 iron in water
It is a colorimetric analyzer that controls and monitors the amount of iron in the water
All the materials used for this analyzer have been developed for this purpose. The dosage carried out by a piston pump is precise and accurate. The measuring chamber is mounted inside the equipment and has only two rings.
This prevents the growth of bacteria and makes maintenance easy. The consumption of the indicator and water are reduced.
Optimal for those companies that do not have control and / or maintenance personnel.
dosage by piston pump
display of the result in various units
two maximum values can be programmed with output function (maximum value 1 exceeded, maximum value 2 exceeded)
programmable analysis interval between 0 – 99 minutes
possibility of volumetric analysis
6 relay outputs: hardness value above the first programmed value, hardness value above the second programmed value, washing, malfunction alarm, maintenance request and AUX to control a chiller
4 inputs: stop analysis, start of analysis, IN 1 zeroing the water meter and IN 2 for a water meter
documentation of analysis errors
additional programmable program (for example: to operate a chiller)
programmable maintenance address
galvanic division between high and low voltage
including pressure regulator 0.1 – 8 bar
accessory: output 0 (4) – 20mA, 0 / 2-10V or RS232 output
