Column formwork

circularfor pillarexpanded polystyrene

Today, they are ideal for projects that have a complex or articulated architectural design. casseforme per colonne 05 Formworks for columns are one of the most representative products of the company since its origins. The polystyrene foam can withstand concrete pressure up to 120 kn/m2, and it can be shaped in the most varied forms. The resin coating is applied by spraying, then sanded to obtain smooth fair facings. A male and female joint system allows the alignment between the two halves of the reusable formworks. Arbloc offers both reusable and single-use solutions according to the needs Topfinish Topfi nish formwork consists of two polystyrene elements that are fastened together and tightened by a traditional carpentry provided by the customer. A male and female joint system, consisting of a shaped wooden panel, allows the two halves to be aligned. The surface is coated with resin to allow for removal and reuse. Design from drawings Customized dimensions Fastening system to care of the customer Fair facing upon request Male and female joint system Reusable 6-10 times Maximum resistance to pressure 100 KN/m2 Rapidoget As a result of Arbloc’s research and experience, Rapidoget formwork is equipped with a new fastening system, which makes it self-supporting so it does not need any other formwork to be fastened. Quick and safe, this new fastening system allows the formwork to be compressed evenly, with good resistance to the concrete pressure. Rapidoget formworks generally consist of two elements joined by a system of male and female joints made on a wooden panel for alignment.
