Vacuum evaporator ARK-LAB-EV1

thermallaboratoryfor sample concentration

Overview
Borosilicate-glass evaporator for small-scale concentration and solvent recovery. Designed for laboratory use supporting solvent recovery, sample concentration and process workups in nanofiber and biopolymer R&D laboratories.

Key figures

• Evaporation capacity: 2 L/h (representative)
• Working temperature range: 30–180 °C
• Vacuum level: 50 mbar (representative)
• Power consumption: 1.2 kW (max)

Technical specification (general)
Application · Concentration / Solvent removal
Operating Mode · Batch / Semi-continuous
Working Temperature Range · 30–180 °C (process dependent)
Typical Solvents · Water, Alcohols, Light organics
Materials of Construction · Borosilicate glass + 316L SS (product contact)

Performance
Evaporation Capacity · Up to 2 L/h (model dependent)
Vacuum Level · Down to 50 mbar (with external pump)
Heating Method · Integrated bath + PID control
Cooling Integration · External chiller interface (optional)

Control & Interface
Controller · PID + adaptive logic
User Interface · 3-inch/5-inch touch display
Data Logging · USB CSV export (optional)
Alarm Functions · Over-temp / low level / vacuum fault

Utilities
Power Supply · 230 ±10 V, 50/60 Hz
Power Consumption · Max 1.2 kW
Cooling Water · Optional (for condenser-supported models)
Vacuum Source · External pump (optional package)

Applications

• Solvent recovery – closed-loop recovery for downstream wet-spinning and electrospinning solvent baths
• Concentration – bench-scale sample concentration for analytics, formulation and bio-research labs
• R&D distillation – light-organic distillation for early-stage formulation and material-chemistry research
• Recycling pilots – pilot-scale solvent recycling to support sustainable-chemistry programmes

Materials & construction notes
Product-contact materials: borosilicate glass and 316L stainless steel. Representative figures; production specifications confirmed in writing per project. Drawings and electrical schematics are supplied with confirmed orders.

Characteristics / technical specifications

• Application: Concentration / Solvent removal
• Operating Mode: Batch / Semi-continuous
• Working Temperature Range: 30–180 °C (process dependent)
• Typical Solvents: Water, Alcohols, Light organics
• Materials of Construction: Borosilicate glass + 316L SS (product contact)
• Evaporation Capacity: Up to 2 L/h (model dependent)
• Vacuum Level: Down to 50 mbar (with external pump)
• Heating Method: Integrated bath + PID control
• Cooling Integration: External chiller interface (optional)
• Controller: PID + adaptive logic
• User Interface: 3-inch/5-inch touch display
• Data Logging: USB CSV export (optional)
• Alarm Functions: Over-temp / low level / vacuum fault
• Power Supply: 230 ±10 V, 50/60 Hz
• Power Consumption: Max 1.2 kW
• Cooling Water: Optional (for condenser-supported models)
• Vacuum Source: External pump (optional package)
