Screen printing machine HYCON XH3

for ceramicscolorautomatic

A versatile screen and stencil printing system with unique expansion options that sets new standards in printing technology. Technology Alignment repeatability of ±12.5 µm @ 6 Sigma Print repeatability ±20 µm @ 6 Sigma Single substrate processing with Optilign & Optilign Multicarrier Pneumatic or electric printhead Squeegee for sreen printing applications Hardmetal transport via round belt systems for ceramic substrates Extended Automation Cost savings through optimal throughput and longer stencil life Closed-loop print force control for optimal printing results Data Intelligence Seamless data exchange through standardized interfaces such as IPC-HERMES-9852, IPC-CFX, OPC UA Developed for SynapticaOS Product Pool: central data storage of print programs Offline programming for creating and editing machine programs at a separate workstation Remote Cockpit Sustainability Reduced consumption of cleaning paper with Optilign Efficient utilization of print format with Optilign Multicarrier Oscillating cleaning for fast stencil cleaning with low wape consumption
