Transmission jack

hydraulic1.5 tonautomotive

Overview

The Autolift manual transmission jack has a 1.5 tonne capacity and is designed for use in pits or under two-post/column lifts. It is intended for removing and installing engines, gearboxes and similar drivelines with emphasis on controlled lowering and easy positioning.

Key features

• Foot-pedal operated hydraulic pump for hands-free lifting.
• Precision-engineered lowering valves for controlled descent.
• Castor wheels and side handles for straightforward positioning and movement.
• Supplied with 2× ratchet straps to secure the gearbox during lowering or transit.
• Universal square top plate with 4 adjustable quadrants and slotted plate design to allow user modifications for different gearbox shapes.
• Narrow base width (850 mm) specifically designed to fit most pit installations.

Technical specifications

• Capacity: 1.5 tonne.
• Height: Minimum 850 mm; Maximum 1945 mm.
• Base width: 850 mm.
• Depth: 800 mm.
• Top plate: Universal square plate with 4 adjustable quadrants and slots for modification to suit different gearboxes.
• Operation: Foot-pedal hydraulic pump (manual), precision lowering valves.
• Mobility: Castor wheels and side handles for movement.
• Accessories included: 2× ratchet straps.

Applications and benefits

• Designed for removal and installation of gearboxes, engines and related drivelines.
• Compact base allows access in pit environments and tight service bays.
• Controlled lowering reduces risk during descent and positioning of heavy components.
• Adjustable top plate enables adaptation to a range of gearbox shapes and mounting points.
