Rotary laser laser receiver AX064000

The Rotary Laser Receiver has a laser detection diode array consisting of 40 diodes. The diode array is 190 mm in length and it can be configured to detect one or two independent rotating laser beams. It has multiple configuration options to suit a variety of machine applications. Specifications Input(s) 160° beam detection 7.5 inch (190 mm) beam detection height range Communications 1 CAN port (SAE J1939) CAN Baud Rate Auto-Baud-Rate detection Operating Voltage 12/24 VDC Nominal (8-36 VDC) Control Logic Standard embedded control logic Enclosure Plexiglass Connection(s) 1 5-pin M12 female connector (Binder P/N: 09-3458-00-05) 1 5-pin M12 male connector (Binder P/N: 09-3443-00-05) Operating Temperature -40 to 85 ºC -40 to 185 ºF Applications Off-highway equipment Construction Surveying Navigation on construction sites Aligning fences and posts Contour farming and drainage
