Partial discharge measuring system PDTD68

fiber opticfor cablesportable

TWO BECOM ONE To make diagnostics as easy and efficient as possible, we have developed the new PDTD68, which allows simultaneous PD and Tan Delta (TD) diagnostics with one single device. This functionality has many benefits, including providing an efficient, cost-effective, and reliable method for assessing the condition and performance of medium voltage cables. Complete system In combination with an HVA test set you get a full-featured and full-value cable test and diagnostics system for up to 68 kV. Application PD & TD diagnostics of all kinds of medium voltage cables with length up to 100 km with a quick and easy measurement setup. PD localization Precise & sensitive real time localization of PD faults in cables with 1% accuracy and a resolution of 0.1 pC and 0.1 m including the PD phase pattern of each PD event. Performance Enables simultaneous and sensitive PD & TD diagnostics up to 68 kV with simple and straight­forward wiring. Compact & portable One compact device powered by an integrated battery or via USB-C (PD 3.0). The single fiber optic interface between the PDTD system and the PC ensures an easy set up. Compliance Test setup and calibration according to IEC 60270. Additionally, TD testing according to IEEE 400.2.
