Automatic screwing machine SCRW01 for screw assemblywith automatic feed
Add to favorites
Compare this product
Characteristics
- Operating mode
- automatic
- Applications
- for screw assembly
- Other characteristics
- with automatic feed
Description
- For single profile processing.
- Automatic screwing of the reinforcement profile by means of foot pedal switch.
- Adjustable according to different profile cross sections.
- Pneumatic clamping during processing.
- Automatic screw feed.
- Automatic depth stop system independent from profile height.
- Standard equipped with profile support conveyors left and right.
TECHNICAL TABLE
• Max. profile section dimensions: 110 mm x 80 mm.
• Min. profile width: 40 mm Air pressure: 6-8 bar
• Air consumption: 200 l/min.
• Machine height: 2,150 mm
• Machine length: 400 mm (3,910 mm. incl. conveyors)
• Machine width: 750 mm
• Machine weight: 115 kg
