ISDN modem card Proxima ISDN Lite series

for communication

ISDN TA ISDN Terminal Adapter with V.24 RS-232 serial interface for fast 128 Kbps ISDN connections. Highlights Desktop ISDN Terminal Adapter ISDN operation up to 128.000 bps Applications: Internet / Intranet / Dial OUT to V.110 compatible GSM devices / Dial IN with GSM data Suitable for Internet, Fax and telebanking Less demanding for your PC because of the active interface Configuration tool for MSN-numbers Supports ISDN-protocols like; MultiLink-PPP, X.75,V.110 and V.120 Specifications Housing: Bausch Datacom 'Proxima' desktop housing Dimensions: 130 x 195 x 37 mm (w x l x h) Weight: approx. 300 gr. (adapter excluded) Power Supply: 9Vac, 220mA -15%/+10% Environmental: Temperature: operating -5°C to +60°C; storage -20°C to +70°C Humidity: operating 10% to 75%; storage 5% to 95% Engine: ISDN operation up to 128.000 bps Fast connection between Proxima ISDN at ‘host’ side and Indubox GSM at ‘client’ side via V.110 GSM-data protocol Configuration tool for MSN-Numbers EURO-ISDN DSS1 with V.110, V.120, PPP, ML-PPP, X.75 Permanent memory for settings: settings may differ per protocol Full interspeeder with XON/XOFF and/or RTS/CTS flow control Softfax operation up to 14.400 bps (via RVS-COM Lite) Drivers for Windows 95/98/2000/NT4.0/XP/Mac/linux/OS/2 Software package: RVS-COM Lite with components for fax, answering machine and file transfer functions Permanent memory for settings: settings may differ per protocol Command sets: Extended 'AT' command set Remote Control through ISDN for remote configuration and tests Software upgrade through serial port (115.2 kbps). ISDN-2 interface: S0 interface according to CCITT I.430 (1TR3)
