Spray cleaning machine ARM series

for the pharmaceutical industryfor bottlesrotary

The ARM container exterior cleaning and drying machine is designed for gentle and thorough cleaning of containers. It reliably removes product residues adhering to the outer surfaces of containers. At the cleaning stations, the containers are soaked with various media while rotating. Immediately after that, the containers are dried from top to bottom by concentric nozzles and by special air ducts at the container base. •Effective and thorough cleaning •Container drying from top to bottom •WIP (Washing In Place) – complete spray down, without opening machine guard •Easy and centralized operation •Pharmaceutical design •Gentle container transport •Short set-up time Optional extras •Integrated, retractable water recycling station for the recirculation, regeneration and multiple use of cleaning media with savings of up to 90 % •Preconfigured for a 3rd rinsing station (ARM 1036) •Preconfigured for an additional cleaning medium •Purging of the water lines downstream of the cycle valve •Temperature monitoring •Pressure monitoring •Vapor escape •Reject discharge •Free-standing vacuum pump •Transition and linkage to machine downstream •Service portal vision system (cleanroom compatible) •A range of checking and alarm devices and counters •Software upgrades •Qualification (IQ/OQ)
