Band saw STO 1600

for steelhorizontalautomatic

Technical features and performance benefits Suitable for cutting large diameter exotic logs. The horizontal log band saw is built on a large supporting base in stabilized steel. The machine capacity enables you to cut or halve logs up to 1800mm dia. Flywheels made of nodular cast iron 1600 mm blade speed 32 m/sec. Effective cutting width 1800 mm Max. cutting height 900 mm Blade dimensions 260 x 1,65 x 12000 mm Hydraulic blade tension device Blade guide manual positioning Centralized diesel-oil lubrication for blades and saw pulleys Oil lubrication for sliding guides Log band saw horizntal positioning by sliding on large-sized steel columns equipped with locking devices. The movement follows by means of ball screws driven by electic motors. Electric motor 90 kW Electrical power board Electronic thickness setting device with programmable micro-processor. This device enables to select the required cutting thickness Control desk CD, including all controls
