Rubber seal F8 series
EPDMcircularcompression

Rubber seal - F8 series - Brandoni - EPDM / circular / compression

Rubber seal - F8 series - Brandoni - EPDM / circular / compression - image - 2

Rubber seal - F8 series - Brandoni - EPDM / circular / compression - image - 3

Add to favorites

Compare this product

Characteristics

Material

rubber, EPDM

Configuration

circular

Application

compression, flange, for pipes

Fluid

for water

Temperature limit

Min.: -10 °C
(14 °F)

Max.: 100 °C
(212 °F)

Pressure limit

Min.: 1 bar
(14.5 psi)

Max.: 16 bar
(232.1 psi)

Diameter

Min.: 15 mm
(0.591 in)

Max.: 600 mm
(23.622 in)

Description

Elastic joints protect the piping from extension, compression, misalignments and bending. Suitable for reducing vibrations and noise absorption, allowing the further reduction of the effects of water hammers. Available in versions: F8.1 > NBR F8.5 > EPDM F8.508 > EPDM WRAS Approved YES: for water plants, pumping stations, conditioning and heating, industrial and agricultural applications, compressed air circuits. Accessories Control rod unit
