Concrete block making machine CE 110

automaticsemi-automatic

SELF-PROPELLED CE 110 BLOCK MAKING MACHINE Technical features. Semiautomatic or automatic CE 110/S self-propelled Block Machine for the production of self-locking paving stones, blocks, curbs, chimney and all other concrete elements with height from 6 to 30 cm. ACHIEVABLE LENGTHS 30/40/50/60 Machine is equipped with : 2-Side vibrators with motors and 1-additional moto-vibrator placed on the tamper-head -double transmission with axle to guarantee a perfect forward movement of the machine. Advancing motor is self-braking and allows a perfect stopping of the machine. -devices with rack and pinion to allow a perfect Lowering of tamper-head and mould to obtain always the same height of concrete elements. -shock-resistant bar that blocks the advancing Movement of machine -safety protections Flashing light indicating the machine is not working Machine forward movement and vibrator ignition are automatic and adjustable. DAILY OUTPUT : 9000 20x40x20 blocks (8-working hours) DAILY OUTPUT : 700 square mts. H=6/8/10 concrete paving stones (8-working hours) MACHINE MUST BE SUITABLY POWERED.
